User Manual For - CONTROLLER/DATA RECORDER MultiCon CMC-99/141
1
2
GND
3
+24V DC ±5%
4
5
6
GND
7
B-
8
A+
Fig. 8.30. Connections for the Passive current output from GND side
1
Power supply
2
GND
3
+24V DC ±5%
4
5
6
GND
7
B-
8
A+
Fig. 8.31. Connections for the Passive current output from Power supply side
306
Power supply
(depending on version)
SERVICE
(Imax. = 200mA)
digital input
0/15..24V DC
RS-485
isolated
(depending on version)
SERVICE
(Imax. = 200mA)
digital input
0/15..24V DC
RS-485
isolated
IO4
4 current output
n01
OUT 4
n02
n03
OUT 3
n04
n05
OUT 2
n06
n07
OUT 1
n08
IO4
4 current output
n01
OUT 4
n02
n03
OUT 3
n04
n05
OUT 2
n06
n07
OUT 1
n08
