User Manual For - CONTROLLER/DATA RECORDER MultiCon CMC-99/141
Most important parameters of R45, R81, R65 and R121 modules:
Number of relays
Max. load per relay
Max. voltage switched
by relay
Isolation strength
between relays
Insulation strength
(relay to MultiCon CMC-
99/141 supply)
Weight
Tab. 8.22 Technical data for the module R45, R81, R65 and R121
R45
4 SPDP
(Switchable)
5A, cos j = 1
(resistive load)
250V AC
1 min. @
630V AC
1 min. @
1000V AC
94 g
Device
Fig. 8.28. Internal structure of the Relay outputs module
R81 R65
8 SPST (N.O.) 6 SPDP
(Switchable)
1A, cos j = 1 5A,
(resistive load) (resistive load)
250V AC 250V AC
1 min. @ 1 min. @
630V AC 630V AC
1 min. @ 1 min. @
1000V AC 1000V AC
79 g 139 g
Driver
R121
12 SPST (N.O.)
cos j = 1 1A, cos j = 1
(resistive load)
250V AC
1 min. @
630V AC
1 min. @
1000V AC
116 g
Isolation
