User Manual For - CONTROLLER/DATA RECORDER MultiCon CMC-99/141
Example 2:
Task:
The user's task is to set a blinking highlight on the temperature channel, which will be
activated on three different levels.
Solution:
After connecting all measuring devices and configuring them in MultiCon, we can start to
configure the highlights.
To complete the task, we will need to configure 7 logical channels:
a) Channel with first level.
b) Channel with second level .
c) Channel with third level.
d) Channel to inform us when first alarm will appear.
e) Channel to inform us when second alarm will appear.
f) Channel to inform us when third alarm will appear.
g) Channel where the temperature is measured, and the alarms will appear.
Logical channel 1: First level:
–
In Name parameter write: First level,
–
Mode parameter set as: Set point value ,
–
Edit button parameter set as: enabled,
–
In Unit parameter write: °C ,
–
Precision parameter set as: 0.0 ,
–
In Graph low parameter write: -50 ,
–
In Graph high parameter write: 85,
–
All other parameters should be set as default,
Logical channel 2: Second level:
–
In Name parameter write: Second level ,
–
Mode parameter set as: Set point value,
–
Edit button parameter set as: enabled ,
–
In Unit parameter write: °C,
–
Precision parameter set as: 0.0 ,
–
In Graph low parameter write: -50,
–
In Graph high parameter write: 85 ,
–
All other parameters should be set as default,
Logical channel 3: Third level:
–
In Name parameter write: Third level,
–
Mode parameter set as: Set point value ,
–
Edit button parameter set as: enabled,
–
In Unit parameter write: °C ,
–
Precision parameter set as: 0.0 ,
–
In Graph low parameter write: -50 ,
–
In Graph high parameter write: 85,
–
All other parameters should be set as default,
Logical channel 4: Calculating the time of the first alarm,
–
In Name parameter write: Calc. First level ,
–
Mode parameter set as: Math function,
–
Click on the Function button,
