User Manual For - CONTROLLER/DATA RECORDER MultiCon CMC-99/141
-ERR- state parameter set as if register ≠ value ,
•
in the -ERR- register parameter set:
◦
–
–
–
–
–
in the -HI- value parameter for the signal -HI- set the value of 0x0000,
◦
Blocks configuration mode parameter set as automatic ,
•
Max.block size parameter set as 5, because the slave device selected in this
•
example allows reading the frame (using the Modbus function 03h) with up to 5
registers,
• move
Save device template button,
in the Save device template menu, enter the template name, e.g.
◦
Temperature converter (stored template can be used to configure the
device to a different address),
using the arrows in the upper right corner of the screen, go to the Modbus
•
address : 8 ,
press the Load device template button and in the template list select the
•
template named Temperature converter , in such a fast way we can set all the
parameters for the SLAVE device 2 identical to SLAVE device 1,
exit from the SLAVE devices menu,
•
An example of a Logical channel in the Modbus mode is shown in 7.8.11.5. Application
of Logical channel in the Modbus mode.

7.15.4.2. Configuration of the Modbus Input in the MASTER mode.

See also: Appendices 8.15. COMMUNICATION MODULES.
Task:
The task is to configure the Slave device (e.g. a Flowmeter) output channel. The Slave
device address is 5. we write data to register 1, 2, 4 and 8. For communication in this task we
use the ACM module, in which the MB2 port is used.
Solution:
First we need to configure the device according to the following recommendations, then
connect the device in according with Fig. 7.155 .
Register type parameter set as HOLDING ,
in Register number parameter write 2h,
Data format parameter set as 16 bits, unsigned ,
in Data shift parameter write 0,
in Data mask parameter write 0x00C0 ,
Device
to the
templates
parameter block and press the
