7.10.5. Examples of build-in output configuration s

7.10.5.1. Application of the output for R45 modules

See also: Appendices 8.13. R45, R81, R65, R121 - RELAY MODULES and Appendices
8.7. RT4 , RT6 – RTD MEASUREMENT MODULES.
Task:
Let's say that we would like to control temperature (around 30°C) in some room by
switching ON and OFF an electric heater. The hysteresis should be 5°C. The temperature is
measured using a PT100 sensor and the RT4 input module, and let the heater is controlled
using an internal 5A relay (R45 module).
Solution:
First configure the device as described below, then connect the object and power supply
as shown in Fig. 7.98.
Fig. 7.97. Parameters of the Passive current output
173
