Safety Precaution To prevent electrical shock and risk of fire hazards, do not expose this unit to rain or moisture and only use specified power source.. CAUTION: TO REDUCE THE RISK OF ELECTICAL SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE.
VTC-THB2RFE-2 Components Video Connection Connect the BNC video connector to a BNC cable, then to a DVR. Camera Screws Monitor User Manual Drill Template Overview Video Video Output Mode Switch: This series supports AHD/TVI/CVI/CVBS video output. The video output can be changed by pressing and holding the button in the video switch cable for 5 seconds (the default video output is TVI video output).
Installation 2. Route the cables and connect the power & video cables, use the rubber plug to fill the gap of the mounting base. then secure the Before you begin, please make sure that the wall or ceiling is strong mounting base to the ceiling or wall with screws.
Page 5
VTC-THT2RFE-2 Components Video Connection Connect the BNC video connector to a BNC cable, then to a DVR. Monitor Camera Hex Wrench Manual Mounting Plate Screws Rubber Plug Overview Video Video Output Mode Switch: This series supports AHD/TVI/CVI/CVBS video output. The video output can be changed by pressing and holding the button in the video switch cable for 5 seconds (the default video output is TVI video output).
Page 6
Installation Before you begin, please make sure that the wall or ceiling is strong 4. Tighten the lock screws to secure the viewing angle adjustments. enough to withstand 3 times the weight of the camera. The mounting steps are as follows: 1.
Page 7
Video Connection VTD-THD2FE-2 Components Connect the BNC video connector to a BNC cable, then to a DVR. Monitor Camera Screws Manual Hex Wrench Drill Template Video Overview Video Output Mode Switch: This series supports AHD/TVI/CVI/CVBS video output. The video output can be changed by holding and pressing the button in the video switch cable for 5 seconds (the default video output is AHD video output).
Page 8
Installation Before beginning installation, make sure that the wall or ceiling is 4. Adjust the Three-axis camer bracket to obtain the optimium strong enough to withstand 3 times the weight of the camera. The viewing angle. mounting steps are as follows: 1.
Camera OSD Menu The Transcendent 4-in1 camera series must be connected to a DVR which supports HD-TVI/AHD video signal input and COC protocol to access the OSD setup menu. Different DVRs manufacturers may have different modes of menu operation. The Following image will pop-up when you left click once on the image when using Transcendent HDA DVR's.
Page 10
Detailed Specifications VTC-THB2RFE-2 VTC-THT2RFE-2 VTD-THD2RFE-2 1/2.9” 2.1 Megapixel Progressive Scan CMOS Sensor Image Sensor Signal System PAL/NTSC 1920(H) x 1080(V) Effective Pixels HD-TVI / HD-CVI / AHD: 1080p/720p (2.1 MegaPixel) / CVBS: 960H Resolution HD-TVI / AHD / CVI / CVBS (Selectable) Video Output Lens 2.8mm - Fixed...
Page 11
OPTIONAL MOUNTS FOR FIXED TRANSCENDENT CAMERAS VT-TJB01 VT-TJB08 VT-TWMT3 Optional Junction Optional Junction Optional Wall Mount Box for Cable Box for Cable for use with Select Management Management for Transcendent Fixed Lens Turrets and Domes. for use with Select use with Select Transcendent Bullet Transcendent and Turret Style...
Limited Product Warranty VITEK products carry a three (3) year limited warranty. VITEK warrants to the purchaser that products manufactured by VITEK are free of any rightful claim of infringement or the like, and when used in the manner intended,...
