Installation Instructions
REV 3 04/15/20
Hardware
M6 Bolt
M8 Bolt
M10 Bolt
M12 Bolt
Torque Specifications
3 ft-lbs.
7 ft-lbs.
16 ft-lbs.
28 ft-lbs.
ATTENTION: Use correct torque settings to avoid
damaging the running boards and or mounting
brackets. Failure to do so will void your warranty.
If you have any questions please contact our technical
team at 1-866-717-6645
Part No.
1428
Product: Running Boards
Application:
GMC Acadia 2017+
Level of Difficulty: 1
2
Installation Time: 90 min
3 4 5
Advertisement
Table of Contents
Related Manuals for Romik RAL-S 60052418-G
Summary of Contents for Romik RAL-S 60052418-G
- Page 1 Part No. 1428 Product: Running Boards Application: Installation Instructions GMC Acadia 2017+ Level of Difficulty: 1 3 4 5 Installation Time: 90 min REV 3 04/15/20 Hardware Torque Specifications ATTENTION: Use correct torque settings to avoid M6 Bolt 3 ft-lbs. damaging the running boards and or mounting M8 Bolt 7 ft-lbs.
- Page 2 Video Installation Installation Instructions 1428 Bracket Kit Instruction: Note: Use of a level is recommended to adjust height. Step 1: Locate front mounting locations and hardware as per 1 page of this installation manual Step 2: Install provided HTC 243 as shown on Figure 1, attach main front bracket and use as guide to locate front extra support position Figure 2.
- Page 3 Installation Instructions 1428 Bracket Kit Step 4: Install extra support using provided M10 harware, make sure the slotted part is pointing towards the bottom this is so you can make your final adjustments Figure 5. Do not tighten Figure 4 Figure 5 Step 5: Locate rear bracket mounitng area, note the needed hole sits behind the metal skirt on your vehicle.
- Page 4 Step 8: Proceed to last page of this manual for running board install instructions and torque values For Technical support please call our team at 1-866-717-6645 and one of our experts will assist you with this installation. Thank you for choosing Romik.
- Page 5 Running Board Installation Instructions 1) Flip your Romik running boards onto a flat surface, make sure to place the running boards on a towel or cardboard in order to protect the surface Figure 1. 2) Loosen the M8 bolts on back of your running boards Figure 2. Depending on your model there Will be either 6 or 8 bolts installed per side.
