RIGHT SIDE VIEW
10
1
(1) Exhaust muffler
(2) Oil level dipstick
(3) Pillion step
(4) Front inner box
*Optional in LX Model
Accessories and features shown may not be part of standard fitment.
SCOOTER VIEWS
9
8
2
3
(5) Front turn signal lamp
(6) Position lamp
(7) Front luggage hook
(optional)
7
4
(8) USB charger* (inside)
(9) Center compartment (inside)
(10) Rear reflex reflector
12
6
5
