Related Manuals for SpectraLink RingCentral Office 84 Series
Summary of Contents for SpectraLink RingCentral Office 84 Series
- Page 1 Spectralink 84-Series Feature Phones RingCentral Office Interoperability Guide 721-0084-000 Rev: A September 2021...
- Page 2 The drawings and specifications contained herein are the property of Spectralink and shall be neither reproduced in whole or in part without the prior written approval of Spectralink, nor be implied to grant any license to make, use, or sell equipment manufactured in accordance herewith.
-
Page 3: Table Of Contents
Environment Information ....................6 RingCentral Documentation ..................6 Spectralink Documentation ..................6 Chapter 2: Configure the RingCentral Office Call Server ... 7 Assign an Existing Device to an Existing Extension ..........7 Chapter 3: Spectralink 84-Series Config Files ......11 721-0084-000_A.docx September 2021... -
Page 4: Chapter 1: About This Guide
Chapter 1: About This Guide This guide describes how to configure a Spectralink 84 Series feature phone for connecting to RingCentral Office. This guide is intended for qualified technicians and the reader is assumed to have a basic knowledge about the Spectralink 84 Series feature phones and RingCentral Office. It is also assumed that you have an installed and functioning RingCentral Office and Spectralink 84 Series feature phones ready to provision and deploy. - Page 5 Spectralink 84 Series Interoperability Guide—RingCentral Supported features Description/Setting Speed Dial Assign a number to one of the speed-dialing keys. Caller ID Display Caller ID information for incoming and outgoing calls. Call Hold and Retrieve Allows user to place active calls on hold.
-
Page 6: Environment Information
Setup & Maintenance tab Spectralink Technical Bulletins Technical Bulletins tab Release Notes Setup & Maintenance tab Spectralink Training material To gain access to the Spectralink training material, you must attend training and become Spectralink Certified Specialist. Please visit http://partneraccess.spectralink.com/training/classroom- training for more information and registration. -
Page 7: Chapter 2: Configure The Ringcentral Office Call Server
Chapter 2: Configure the RingCentral Office Call Server Assign an Existing Device to an Existing Extension To add an existing device to an existing user, do the following: Log in as an Administrator to your RingCentral Online Account. Under Admin Portal, click Users, click User List, click Users With Extensions and select the desired User. - Page 8 Spectralink 84 Series Interoperability Guide—RingCentral Select Other Phones, click Existing Phone, and then click Add. You can now see information about added devices and order summary. Assign a phone number to the device: ○ If you already have an existing number, click Existing Number to add it to the device.
- Page 9 Spectralink 84 Series Interoperability Guide—RingCentral Specify the Emergency Address for the device. Follow the steps to complete the process. Click Done when finished. When complete, the new Existing Device is displayed under the selected user account. 721-0084-000_A.docx September 2021...
- Page 10 Spectralink 84 Series Interoperability Guide—RingCentral Continue setting up new user phones if needed. 721-0084-000_A.docx September 2021...
-
Page 11: Chapter 3: Spectralink 84-Series Config Files
Enable the interop features on the 84-Series provisioning server by updating each phone’s configuration file(s). Each individual 84 Series feature phone must be assigned to a RingCentral user extension. Spectralink 84 Series feature phones are configured in RingCentral as a user's existing device. Note Settings not mentioned below should be left at their default values. - Page 12 Spectralink 84 Series Interoperability Guide—RingCentral <SIPserver> <dialplan> dialplan.removeEndOfDial="1" dialplan.digitmap="x.T" </dialplan> <voicemail> up.oneTouchVoicemail="1" up.mwiVisible="1" msg.mwi.1.callBackMode="registration" msg.mwi.1.callBack=""> </voicemail> </SIPserver> </openSIP> </TelephonyParameters> *****END OF DOCUMENT***** 721-0084-000_A.docx September 2021...
