Network Connection Manual
LINERLESS PRITNER
Ver. 1.00
SRP-S3000
http://www.bixolon.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SRP-S3000 and is the answer not in the manual?

Questions and answers

Related Manuals for BIXOLON SRP-S3000

Summary of Contents for BIXOLON SRP-S3000

  • Page 1 Network Connection Manual LINERLESS PRITNER Ver. 1.00 SRP-S3000 http://www.bixolon.com...

  • Page 2: Table Of Contents

    SRP-S3000 Table of Contents 1. Manual Information ....................3 2. Precautions ......................3 3. Specifications ......................4 4. How to Connect ...................... 5 4-1 Connecting Printer ......................5 4-1-1 USB cable ......................5 4-1-2 WLAN........................5 4-2 Checking Network Setting..................6 4-2-1 LAN and Wireless(WLAN or BLUETOOTH) ...........6 4-2-2 LAN Setting Values ..................7...

  • Page 3: Manual Information

    This manual provides information on the connection of wireless network with the printer. We, BIXOLON, are making continuous improvements to improve the function and quality of our products. As a result, the specifications of the product and the contents of the manual can be changed without prior notice.

  • Page 4: Specifications

    SRP-S3000 3. Specifications CATEGORIES FEATURE IMPLEMENTATION Interface 10/100 Base-T All in one(Auto detection) Specification Protocol DHCP Client, HTTP, ARP, ICMP, IPv4, TCP, UDP Operation Infrastructure, Soft AP, Ad-hoc, Wi-Fi Direct Mode Wireless IEEE 802.11b/g/n, IEEE 802.11a/b/g/n Standard Range Up to 100m free space (Outdoor)

  • Page 5: How To Connect

    SRP-S3000 4. How to Connect WLAN can be configured through the printer’s WLAN interface. Likewise, WLAN can also be configured though the printer’s USB interface. 4-1 Connecting Printer 4-1-1 USB cable Connect USB cable to Printer, PC device. Use the “Net Configuration Tool” to adjust the settings.

  • Page 6: Checking Network Setting

    SRP-S3000 4-2 Checking Network Setting 4-2-1 LAN and Wireless(WLAN) Cover Open Lever FEED Button With the printer power off, press the FEED button and press the printer power button to power on the printer and release both buttons to output the printer setting value.

  • Page 7: Lan Setting Values

    SRP-S3000 4-2-2 LAN Setting Values Classification Item Description Input Range Inactivity Time TCP connection hold time 0~3600 integer IP Assignment IP Assignment Method DHCP/Manual Method Network IP Address Printer IP IP Address Subnet Mask Subnet mask IP Address Gateway Default Gateway IP Address Ver.

  • Page 8: Wlan Setting Values

    SRP-S3000 4-2-3 WLAN Setting Values Classification Item Description Input Range Home WLAN setting status display Network Mode Wireless LAN operating mode Infrastructure/Adhoc Channel when creating Adhoc Adhoc Channel 1~14 network SSID ID of the AP to connect 1~32 letters Inactivity Time...

  • Page 9: Android Soft Ap Mode

    SRP-S3000 4-3 Android Soft AP mode 1) Select “Wi-Fi”. 2) Select the printer to connect. 3) Select “CONNECT”. 4) Wi-Fi communication is available Ver. 1.00 - 9 -...

  • Page 10: Ios Soft Ap Mode

    SRP-S3000 4-4 iOS Soft AP mode 1) Select “Wi-Fi”. 2) Wi-Fi ON and Select the printer to connect. 3) Wi-Fi communication is available. Ver. 1.00 - 10 -...

  • Page 11: How To Change Infrastructure Mode

    SRP-S3000 4-5 How to change Infrastructure mode 1) Enter the IP address of the printer in the address bar, and the following login window will pop up. Enter the ID and Password set for the printer, and then click [LOG IN] (Default User Name: admin, Password: password) 2) Select “Wireless”...
  • Page 12 SRP-S3000 3) Select “Infrastructure”, and set SSID, WLAN Security Type. 4) Reboot the Printer. Ver. 1.00 - 12 -...

  • Page 13: Ethernet Test By Using Windows Test Page

    Operating systems that allow you to use the Windows printer driver are Windows, XP, Server 2003, VISTA, 2008 Server, 7, 8, 10. You can download the latest version of Windows driver from Note our home page. (www.bixolon.com) 1) Double-click the Windows Driver installation file. 2) Click Install. Ver. 1.00...
  • Page 14 SRP-S3000 3) Select Installation and click Next. 4) Select Model Name and click Next. Ver. 1.00 - 14 -...
  • Page 15 SRP-S3000 5) Select Ethernet and click Add TCP/IP Port. 6) Enter the IP address and port number, and then click Next. Ver. 1.00 - 15 -...
  • Page 16 SRP-S3000 7) Click Next. 8) Click Next. Ver. 1.00 - 16 -...
  • Page 17 SRP-S3000 9) Click Next. 10) Click Finish. Ver. 1.00 - 17 -...
  • Page 18 SRP-S3000 11) Open the printer properties window in the Windows OS. (1) Installing on Windows XP / Server 2003 ※ Control Panel – Printers and Faxes. (2) Installing on Windows VISTA / Server 2008 / 7 / 8 / Server 2012 / 10 ※...
  • Page 19 SRP-S3000 14) Click Print Test Page and check printing status. Proper installation of the driver is indicated if the test page is printed normally. Ver. 1.00 - 19 -...

  • Page 20: Factory Reset

    SRP-S3000 6. Factory Reset 6-1 Initializing WLAN Setting This function changes the WLAN settings of the printer to the initial factory settings. Method Select the wireless interface on the printer's LCD screen. WLAN Factory reset is available in Interface > WLAN > WLAN Factory Reset When the printer is turned off, the wireless LAN setting is applied as the factory default.

  • Page 21: Factory Reset Values

    SRP-S3000 6-2 Factory Reset Values Inactivity time IP Assignment Network Automatic(DHCP) Method Local Port 9100 Printer Name *Printer model Printer Port Num 9100 System User ID admin User Password password Enc / Auth Encryption None/Open Network Mode Soft AP mode...

  • Page 22: Troubleshooting

    SRP-S3000 7. Troubleshooting - IP Address Check the band of the IP Address. Check whether the bands of Check network the printer and the AP (or wireless terminals) are the same. setting The first three digits of the four digit value of the IP address (Refer to must be the same.
  • Page 23 SRP-S3000 When you see “Request timed out.” as shown below, it means that there is no collision. The corresponding IP can be used. On the other hand, if there is a reply as shown below, then the corresponding IP is used by another network terminal and it cannot be used for the printer IP.
  • Page 24 BIXOLON Co., Ltd. The information contained herein is designed only for use with this BIXOLON product. BIXOLON is not responsible for any direct or indirect damages, arising from or related to use of this information.
