User's Manual
SRP-S300
Thermal Printer
Rev. 1.02
http://www.bixolon.com
V10 CONSUMIBLES S.L.
Calle Llanos de Jerez 18 Nave 9 Coslada https://v10consumibles.com Tel: 910 269 309

Advertisement

Table of Contents
loading

Related Manuals for BIXOLON SRP-S300

Summary of Contents for BIXOLON SRP-S300

  • Page 1 User’s Manual SRP-S300 Thermal Printer Rev. 1.02 http://www.bixolon.com V10 CONSUMIBLES S.L. Calle Llanos de Jerez 18 Nave 9 Coslada https://v10consumibles.com Tel: 910 269 309...
  • Page 2 ■ Safety Precautions In using the present appliance, please keep the following safety regulations in order to prevent any hazard or material damage. WARNING Violating following instructions can cause serious injury or death. Do not plug several products in one multi-outlet. You must use only the supplied adapter.
  • Page 3 CAUTION Violating following instructions can cause slight wound or damage the appliance. Keep the desiccant out of children’s reach. If you observe a strange smoke, odor or noise from the printer, unplug it before taking following • If not, they may eat it. measures.
  • Page 4 ■ Warning - U.S.A This equipment has been tested and found to comply with the limits for a Class A digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
  • Page 5 ■ Introduction The SRP-S300 Roll Printer is designed for use with electronic instruments such as system ECR, POS, banking equipment, computer peripheral equipment, etc. The main features of the printer are as follows: 1. Print at a max. speed of 170mm/s(Sticky, Re-stick,Linerless Extreme), 300mm/s(Receipt).

  • Page 6: Table Of Contents

    ■ Table of Contents 1. Setting Up the Printer ....................7 1-1 Unpacking ....................... 7 1-2 Connecting the Cables .................... 8 1-2-1 USB Interface ....................8 1-2-2 Parallel Interface(IEEE1284) ................9 1-2-3 Serial Interface(RS232) ................10 1-2-4 Ethernet Interface ..................11 1-2-5 Wireless LAN Interface .................

  • Page 7: Setting Up The Printer

    1. Setting Up the Printer 1-1 Unpacking Your printer box should include these items. If any items are damaged or missing, please contact your dealer for assistance. SRP-S300 Installation Guide Power cord Partition 2ea V10 CONSUMIBLES S.L. Calle Llanos de Jerez 18 Nave 9 Coslada https://v10consumibles.com Tel: 910 269 309...

  • Page 8: Connecting The Cables

    1-2 Connecting the Cables Connect the printer to the host computer using the right interface cable that complies with the specifications of the interface. The drawer to be used with the printer should meet the specifications of the printer. ※ Caution Before connecting any of the cables, make sure that both the printer and the host are turned off.

  • Page 9: Parallel Interface(Ieee1284)

    1-2-2 Parallel Interface(IEEE1284) Drawer kick-out Parallel connector USB connector connector Power Compatibility Pin No. Source Nibble Mode Byte Mode Mode Host nStrobe HostClk HostClk Host / Printer Data 0(LSB) Data 0(LSB) Host / Printer Data 1 Data 1 Host / Printer Data 2 Data 2 Host / Printer...

  • Page 10: Serial Interface(Rs232)

    1-2-3 Serial Interface(RS232) Drawer kick-out USB connector connector Power Serial connector Pin No. Signal Name Direction Function Frame Ground Output Transmit Data Input Receive Data Output Ready To Send Input Clear To Send Input Data Set Ready Signal Ground Output Data Terminal Ready V10 CONSUMIBLES S.L.

  • Page 11: Ethernet Interface

    White Brown Brown * If you push the function key, IP and MAC information can be obtained. * Refer to the Network User Manual that is available from the BIXOLON website for more detailed information. V10 CONSUMIBLES S.L. Calle Llanos de Jerez 18 Nave 9 Coslada https://v10consumibles.com Tel: 910 269 309...

  • Page 12: Wireless Lan Interface

    1-2-5 Wireless LAN Interface Drawer kick-out connector USB connector Power Wireless LAN module 1-2-5-1 Wireless LAN Communication Specifications Item Specifications Frequency 2.412~2.484 GHz Channel Channel 1~13 Protocol 802.11b, 802.11g, 802.11n 1-2-5-2 Connecting Wireless LAN Printer can be connected to terminal devices with wireless LAN communication capability (PDA, PC, smartphone, tablet PC, etc.).

  • Page 13: Powered Usb Interface

    1-2-6 Powered USB Interface Drawer kick-out USB connector connector Powered USB connector Power Pin No. Signal Name Function Shield Shield Prevent Noise PGND Main Power Ground VPP24V Main Power Signal ground Data Line(D+) Data Line(D-) VBUS Host Power VPP24V Main Power PGND Main Power Ground * Refer to www.poweredusb.org for detailed information related to the specifications of...

  • Page 14: Bluetooth Interface

    1-2-7 Bluetooth Interface Drawer kick-out connector Power Bluetooth module USB connector 1-2-7-1 Bluetooth Communication Specifications Item Specifications Frequency 2.402 ~ 2.480 GHz Version 2.1 + EDR Module Type Class 1 1-2-7-2 Bluetooth Connection Printer can be connected to terminal devices with Bluetooth communication capability (PDA, PC, smartphone, tablet PC, etc.) * Refer to the Bluetooth Connection Manual for more detailed instructions about how to establish the connection.

  • Page 15: Drawer Cable

    1-3 Drawer Cable Connect the cash drawer connecting cable to the cash drawer connector located in the back of the printer. ※ Warning Use a cash drawer that meets the printer specifications. Using an improper cash drawer may cause faults in the cash drawer and the printer. Make sure to use a cash drawer with an internal coil resistance of 24 Ω(Ohm) or higher.

  • Page 16: Setting The Dip Switches

    1-4 Setting the Dip Switches 1-4-1 DIP Switch 1 • Serial Interface Function Default Auto Line Feed Enabled Disabled Flow Control XON/XOFF DTR/DSR Data Length 7-bit 8-bit Parity Check Parity Selection EVEN Baud Rate(bps) Refer to the following Table 1 •...

  • Page 17: Dip Switch 2

    1-4-2 DIP Switch 2 • SRP-S300L/T Function Default Reserved Black Mark Sensor Disabled Enabled Internal Bell Control Disabled Enabled Taken Sensor Disabled Enabled Printing Density Refer to the following Table 2 Auto External Buzz Enabled Disabled Dip Switch 2-4 is only valid for Taken Sensing Model (SRP-S300T). And then both taken sensing and back feeding are disabled when 2-4 is on.
  • Page 18 ※ Print Density The print density can be set to one of eighteen different levels through virtual memory switches. Density Dip Switch Density Level Light Dark 6(High Speed) Level 1 Level 2 Level 3 Speed Level 4 Level 5 1(Low Speed) Level 6 Density Memory Switch...

  • Page 19: Installing Or Replacing The Paper Roll

    1-5 Installing or Replacing the Paper Roll ※ Caution Use the paper rolls in supported sizes only. The printer may not recognize the availability of the paper correctly if the paper roll is stuck to the tube. 1-5-1 Make sure that the printer is in standby mode and that no data is sent before replacing the paper as it can lead to data loss.
  • Page 20 1-5-5 Check the orientation of the roll paper when inserting it into the printer. 1-5-6 Pull out a small amount of paper as shown in the picture, and close the cover. ※ Caution When closing the cover, hold down the center of printer cover firmly so that paper roll is loaded correctly.

  • Page 21: Recommended Papers

    1-6 Recommended Papers Sticky, Re-stick,Linerless Extreme - Iconex Sticky Media(USA): Classic: 9023-1253, 9023-1232(80mm), 9023-1823, 9023-1397(58mm), 9023-1233, 9023-1818(40mm) Classic High Tack: 9023-1254(80mm), 9023-1500(58mm), 9023-1258(40mm) Classic High Temp: 9023-1267, 9023-1463 (80mm), 9023-1269(40mm) Ultralite: 9023-1866(80mm), 9023-1410(58mm), 9023-1865(40mm) Classic High Tack Plus: 9023-1846(80mm) - Iconex Linerless Label(USA) Linerless Extreme: 9023-1873, 9023-1708(40mm) - MAX International Converters, Inc.

  • Page 22: Using The Printer

    1-7 Using the Printer 1-7-1 Control Panel ○ POWER LED The POWER light is on whenever the printer is on. ○ ERROR LED This indicates an error. ○ PAPER LED This light indicates the near end of the paper roll. Install a new paper roll and the printer will continue printing.

  • Page 23: Mounting Partition(40,58,62Mm)

    1-7-2 Mounting Partition(40,58,62mm) Position the partition on the front and back grooves and press the center part to fix it as shown in the picture. The position to secure the partition varies depending on the type of paper. (Refer to the picture below.) 1.

  • Page 24: Using Of 83Mm Paper Roll

    1-7-3 Using of 83mm Paper Roll Remove the side-mounted partition when using 83mm roll paper. Default Partition ※ Caution The default partition cannot be used in conjunction with the separately packaged partition. V10 CONSUMIBLES S.L. Calle Llanos de Jerez 18 Nave 9 Coslada https://v10consumibles.com Tel: 910 269 309...

  • Page 25: Setting Volume

    1-8 Setting Volume Open the plate at the bottom of the printer and use a cross-head screwdriver to adjust the volume. Then, close the plate. Plate Plate Decrease Increase the Volume the Volume ※ Caution To mute the volume, turn it counter-clockwise all the way. V10 CONSUMIBLES S.L.

  • Page 26: Using Of Taken Sensor Function

    1-9 Using of Taken Sensor Function When it comes to Taken Sensor, it will detect the paper not to feed next paper before user detach it. This function will be supported by SRP-S300T. Also, it’s available in Partial Cut Mode only but not in Full Cut Mode. V10 CONSUMIBLES S.L.

  • Page 27: Removing Paper Jam

    1-10 Removing Paper Jam 1-10-1 When a paper jam occurs, turn the printer OFF and then back ON, open the cover, and remove the jammed paper. ※ In case of a minor jam, it may be possible that the operating blade returns to the original position and cover can be opened simply by turning the printer OFF and then back ON.

  • Page 28: Connecting The Computer

    1-11 Connecting the computer Use the cable that comes with the printer to connect the printer to computers. 1-11-1 Plug the cable connector securely into the printer’s interface connector located in the back of the printer. 1-11-2 Tighten the screws on the cable connector.(Only Serial Interface) (Serial Cable Sample Image) 1-11-3 Connect the other end of the cable to the COM port of the PC.

  • Page 29: Self Test

    2. Self Test The self-test checks whether the printer has any problems. If the printer does not function properly, contact your dealer. The self-test procedure is as follows: 2-1 Check whether the paper is inserted correctly. 2-2 Turn on the printer while depressing the Feed button. Self-diagnostics will begin. 2-3 The printer prints the current status of the printer such as the version of the ROM and DIP switch setting.
  • Page 30 2-5-2-2 Make sure to press the FEED button to perform the above functions. 2-5-2-2-1 Step 1: The number indicates the number of times the FEED button needs to be pressed. Make sure to press it for less than 1 second. 2-5-2-2-2 Step 2: Hold down the FEED button for 1 second or longer to enter the selected item.

  • Page 31: Hexadecimal Dumping

    3. Hexadecimal Dumping This function allows experienced users to see exactly what data is coming to the printer. This can be useful in finding software problems. When you turn on the hexadecimal dump function, the printer prints all commands and data in hexadecimal format along with a guide section to help you find specific commands.

  • Page 32: Specification

    4. Specification Printing Method Thermal Line Printing Dot Density 203 dpi(8 dots/mm) 83mm 80mm or 72mm 80mm 72mm Paper Width / Printing Width 62mm 60mm 58mm 48mm 40mm 32mm 79.5 ±0.5mm, 61.5 ±0.5mm, Paper Width 57.5 ±0.5mm, 39.5 ±0.5mm, 82.5 +1,-0.5mm 48(Font A), 64(Font B), 64(Font C) Characters Per Line(Default) ※...

  • Page 33: Appendix

    5. Appendix 5-1 Cleaning Printer Paper dust inside the printer may lower the print quality. In this case clean the printer as follows: It is recommended to clean after every 30 rolls when using Sticky, Re-stick, Linerless Extreme paper. 5-1-1 Open the printer cover and remove any paper. 5-1-2 Use a cloth soaked in alcohol solvent or Cleaning Card (Pen) to clean the printer head and roller.
