Page 1 Unified POS Utility Manual Thermal Printers BGT-100P Printer Rev. 1.13 BGT-102P Printer SRP-Q300 / SRP-Q302 SRP-S300 SRP-380 / SRP-382 SRP-F310II SRP-F312II SRP-F313II SRP-350plusIII SRP-352plusIII SRP-350III / SRP-352III SRP-350IIOBE SRP-330 SRP-330II / SRP-332II SRP-340II / SRP-342II STP-103III SPP-100II http://www.bixolon.com...
Page 2: Table Of Contents
■ Table of Contents 1. Foreword ........................3 2. Operating System (OS) Environment ................3 3. Usage Preparation ......................4 4. Unified POS Utility Usage ..................... 5 4-1 VMSM ......................... 5 4-1-1 Getting the Memory Switch Status of the Printer .......... 5 4-1-2 Setting the memory switch status of the Printer ...........
Page 3: Foreword
This function is used to test printing-related commands and create a brief label sample for test printing. We at BIXOLON maintain ongoing efforts to enhance and upgrade the functions and quality of all our products. In following, product specifications and/or user manual content may be changed without prior notice.
Page 4: Usage Preparation
2) Unified POS Utility Program Execution. The program can be installed from the accompanying CD, and Latest file versions can be downloaded from the BIXOLON website. (http://www.bixolon.com) 3) Select the interface type and communication conditions. 4) Click on the “Connect” Button. If the conection is successful, the inactive buttons become active with the message “The printer is connected”.
Page 5: Unified Pos Utility Usage
4. Unified POS Utility Usage 4-1 VMSM This function is used to set the virtual memory switch used for the thermal printer suitable for the user’s environment. If the Communication Setting is OK, click the “VMSM” button. 4-1-1 Getting the Memory Switch Status of the Printer 1) Click the “Get Status”...
Page 6: Setting The Memory Switch Status Of The Printer
4-1-2 Setting the memory switch status of the Printer After getting the memory switch status of the printer, the status of the printer can be modified. 1) “Get Status” Pressing this button displays the current memory switch settings read from the printer. 2) “Set Status”...
Page 7 6) Code page The user may select and set the code page. 7) Cutter Depth Adjustment Supported Model : SRP-380/382, SRP-S300, SRP-Q300/Q302 You can set the paper width which is not cut when using a partial cut operation. Rev. 1.13 - 7 -...
Page 8 8) 90 Degree Rotation Mode Supported Model : SRP-S300L(Liner-free Model), SRP-S300T Texts prints with 90 degree rotation. (eg: N to Z) 9) Back-Feeding Mode Supported Model : SRP-S300L(Liner-free Model), SRP-S300T Reverse feeds the paper to the specific position before the start of printing. 10) Automatic feed in idle mode Supported Model : SRP-S300L(Liner-free Model), SRP-S300T Feeds the paper at every specified time interval when the printer is in the sleep mode.
Page 9: Paper Save Mode
4-1-3 Paper Save Mode Supported Model - SRP-350III/352III, SRP-350plusIII/352plusIII, SRP-F310II/F312II/F313II, SRP-380/382, BGT-100P/102P, SRP-330II/332II, SRP-340II/342II, SRP-S300, SRP-Q300/Q302 You can select the levels of “Paper Save” and the feature of “Cutting Position Correction” in the “Paper Save Mode” section (tab). 4-1-4 Serial communication Setting...
Page 10: Bluetooth Configuration
4-1-5 Bluetooth configuration Supported Model - SRP-350IIOBE, SRP-350plusIII/352plusIII, SRP-F310II/F312II/F313II, SRP-380/382, SRP-S300, SRP-Q300/Q302 Bluetooth setting can be changed by Bluetooth Configuration Tab. In case of Serial(Bluetooth) communication, it is not able to check Bluetooth configuration. ■ Authentication & Encryption Sets or cancels Authentication & Encryption mode when connecting via Bluetooth * If Authentication &...
Page 11: Maintenance Counter
4-1-6 Maintenance counter Supported Model : SRP-F310II/F312II/F313II, SRP-380/382, SRP-Q300/Q302 You can check the number of auto cut operation and amount of paper feed which have been performed by the printer. Rev. 1.13 - 11 -...
Page 12: Nv Image Tool
4-2 NV Image Tool This function helps you to download user-defined images to the flash memory in the printer and to recall and print those images with fast speed. If the Communication Setting is OK, click the “NV Image Tool” button. 4-2-1 NV Function Option If the Printer is supported two-color mode, mono (NV bit image) or two-color (NV graphics) mode can be selected.
Page 13: Image List Management
You can get the correction image by selecting a ‘Dither’, ‘Brightness’, ‘Grayscale’ and ‘Adjustment’ option. Supported model by ‘Adjustment’ : SRP-380/382, SRP-S300, SRP-Q300/Q302 Supported model by ‘Grayscale’ - SRP-350plusIII/352plusIII, SRP-F310II/F312II/F313II, SRP-380/382, BGT-100P/102P, SRP-330II/332II, SRP-S300, SRP-Q300/Q302 Rev. 1.13 - 13 -...
Page 14: Download The Image
4-2-4 Download the image 1) When the “Download” button is clicked, pop-up window and the steps are different based on printer model. 2) After all images stored on the corresponding printer are deleted, the image matching the selected resolution level is downloaded. The image is assigned a number according to the image list displayed on the screen.
Page 15: Print The Image
4-2-5 Print the image 1) The “Print” button in the main screen can be used on each printer model to print and test a stored image. 2) After selecting the image to print following the recall of the addresses of all currently stored images, press the “Print”...
Page 16: Using The Command Test Editor
4-3 Using the Command Test Editor 1) If the Communication Setting is OK, click the “Command Test Editor” button. 2) If the “Command Test Editor” button is pressed, the following dialog box will appear. Using this Dialog, the user can write and edit the command and send to the printer. Each button of “Printing Option”...
