User's Manual
SRP-S300II
LINERLESS PRINTER
Ver. 1.00
www.bixolon.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SRP-S300II and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for BIXOLON SRP-S300II

Summary of Contents for BIXOLON SRP-S300II

  • Page 1 User’s Manual SRP-S300II LINERLESS PRINTER Ver. 1.00 www.bixolon.com...

  • Page 2: Copyright

    It is strictly prohibited to copy, store, and transmit the whole or any part of the manual and any property of the product without the prior written approval of BIXOLON Co., Ltd. The information contained herein is designed only for use with this BIXOLON product.
  • Page 3 SRP-S300II Warning Hazardous moving parts Keep fingers and other body parts away Pull the print head lever can be stop all moving parts. IEC 60417-6057 (2011-05) for other moving parts. Mise en garde Les appareils électroniques, tels que les imprimantes, risquent d'être endommagés par l'électricité...

  • Page 4: Compliance Information

    SRP-S300II Compliance information This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
  • Page 5 SRP-S300II Waste Electrical and Electric Equipment (WEEE) This marking shown on the product or its literature, indicates that is should not be disposed with other household wastes at the end of its working life, To prevent possible harm to the environment or human health from uncontrolled waste disposal, please separate this from other types of wastes and recycle it responsibly to promote the sustainable reuse of material resources.

  • Page 6: Warning & Caution

    Do not connect multiple products to a Only use authentic products from single or faulty power outlet. Use only BIXOLON. The company will not provide grounded power outlets that meet the post-sale support for damaged or other industry standard. Noncompliance may quality issues that any fake cause electric shock or fire.
  • Page 7 Do not place heavy product, please contact the original objects, liquids, or metals on the place of purchase or through product. This could cause damage to BIXOLON website’s product repair the product or a fire. page (www.bixolon.com). - 7 - Ver. 1.00...

  • Page 8: Manual Introduction

    SRP-S300II Manual Introduction This manual provides basic information on printers and provides ways to install, use, and check them. In order to protect the safety of users and prevent property damage, be fully familiar with this manual before using the product. Please use it.

  • Page 9: Printer Introduction

    SRP-S300II Printer Introduction The SRP-S300II series is a 3-inch (80 mm) linerless printer designed with BIXOLON's eco- friendly technology and supports 180 mm/sec print speed. It supports up to three paper widths via partitions and can accommodate paper rolls up to 103 mm in diameter.

  • Page 10: Table Of Contents

    SRP-S300II Table of Contents Copyright ..........................2 WARNING & CAUTION ......................6 Manual Introduction ....................... 8 Printer Introduction ........................ 9 1. Preparation ........................12 2. Product Part Names......................13 2-1 Printer Part Names ......................13 2-2 Interface Part Names ...................... 14 2-2-1 USB (Built-in) ......................
  • Page 11 SRP-S300II 7. Specifications ........................47 7-1 Printer Specifications ...................... 47 7-2 Recommended Papers ....................48 - 11 - Ver. 1.00...

  • Page 12: Preparation

    SRP-S300II 1. Preparation • If there is any part missing, please contact the place of purchase. • The actual part may look different from the image. SRP-S300II Standard Components Installation Guide Power Cord USB A-B Cable Optional Components Powered USB Cable...

  • Page 13: Product Part Names

    SRP-S300II 2. Product Part Names 2-1 Printer Part Names Cutter Cover Indicator Light Functional Buttons Feed Button Cover Open Lever Power Switch Printer Cover - 13 - Ver. 1.00...

  • Page 14: Interface Part Names

    SRP-S300II 2-2 Interface Part Names • Connect the printer to the host computer using the right interface cable that complies with the specifications of the interface. 2-2-1 USB (Built-in) USB Port Pin No. Signal Name Function Shell Shield Frame Ground...

  • Page 15: Ethernet Interface (Built-In)

    If power is on, your data may be lost. - Refer to the utility and network connection manual for Interface connection information. The network connection manual is on the BIXOLON website (www.bixolon.com) We're offering it. - 15 - Ver. 1.00...

  • Page 16: Serial Interface Card (Rs232)

    SRP-S300II 2-2-3 Serial Interface Card (RS232) Serial Port Pin No. Signal Name Direction Function Frame Ground Output Transmit Data Input Receive Data Output Ready To Send Input Clear To Send Signal Ground Output Data Terminal Ready Output Data Terminal Ready Connect or disconnect the communication cable while the printer power is off.

  • Page 17: Wireless Lan Interface Card

    Capability (PDA, PC, smartphone, tablet PC, etc.). Refer to the Network Connection Manual for more detailed instructions about how to establish the connection. The Network connection manual is on the BIXOLON website (www.bixolon.com) We're offering it. - 17 - Ver. 1.00...

  • Page 18: Bluetooth Interface Card

    (PDA, PC, smartphone, tablet PC, etc.) Refer to the Bluetooth Connection Manual for more detailed instructions about how to establish the connection. The Bluetooth Connection manual is on the BIXOLON website (www.bixolon.com) We're offering it. - 18 - Ver. 1.00...

  • Page 19: Powered Usb Interface Card

    SRP-S300II 2-2-6 Powered USB Interface Card Powered USB Port Pin No. Signal Name Function Shield Shield Prevent Noise PGND Main Power Ground VPP24V Main Power Signal ground Data Line(D+) Data Line(D-) VBUS Host Power VPP24V Main Power PGND Main Power Ground - Refer to www.powered.org...

  • Page 20: Drawer Kick-Out Port

    SRP-S300II 2-2-7 Drawer Kick-out Port Connect the Drawer Kick-out connecting cable to the Drawer Kick-out connector located in the back of the printer. Drawer Kick-out Port Pin No. Signal Name Direction Frame Ground Drawer Kick-out Drive Signal 1 Output Drawer Open/Close Signal...

  • Page 21: Installation & Usage

    SRP-S300II 3. Installation & Usage 3-1 Printer Installation Placings - Allow sufficient space around the printer for proper ventilation. - Do not place objects close to the back or bottom of the printer, which may hinder the air circulation. - Install the printer on a flat and level surface.

  • Page 22: Turn On The Power

    Power Cord Power Switch - Be sure to turn off the printer and connect or disconnect the cable. - Only use a power supply provided by BIXOLON. BIXOLON shall bear no responsibility for damage caused by using a third-party power supply.

  • Page 23: Inserting And Changing The Paper Roll

    SRP-S300II 3-3 Inserting and changing the paper roll Use paper roll that complies with the specifications If you use a paper roll including paper core attached to paper, the paper may not be properly recognized as paper Empty due to not proper releasing of paper.
  • Page 24 SRP-S300II 2) Replace with a new one as shown in the image. 3) Check the orientation of the roll paper when inserting it into the printer. - 24 - Ver. 1.00...
  • Page 25 SRP-S300II 4) Pull out a small amount of paper as shown in the picture, and close the Pinter Cover. When closing the cover, hold down the center of printer cover firmly so that paper roll is loaded correctly. - 25 -...

  • Page 26: Using Controller

    SRP-S300II 3-4 Using Controller Explanation POWER The Power LED light is on whenever the printer is on. Error LED is on when there is an error such as no paper roll, ERROR open cover, etc. Paper LED is on when the paper roll is almost used up or there PAPER is no paper roll inside.

  • Page 27: Stacking Vertically In Two Tiers

    SRP-S300II 3-5 Stacking vertically in two tiers 1) Stack two products vertically, aligning them with the grooves on the top of the product. - 27 - Ver. 1.00...
  • Page 28 SRP-S300II 2) Mount the Stack-Plate to the back of the Product with the two included screws. - 28 - Ver. 1.00...

  • Page 29: Using Of Taken Sensor Function

    SRP-S300II 3-6 Using of Taken Sensor Function • When it comes to Taken Sensor, it will detect the paper not to feed next paper before user detach it. - 29 - Ver. 1.00...

  • Page 30: Changing Paper Width

    SRP-S300II 3-7 Changing Paper Width • Adjust the position of the partition according to the paper width (Paper width: 40mm, 58mm, 80mm). Align the arrow on the partition with the position for use as shown in the image. 1) Open the printer cover and pull the partition lever.
  • Page 31 SRP-S300II 2) While pulling the lever, move the partition left or right to align the mark with the desired paper width. <80mm> <58mm> <40mm> 3) Once aligned, release the partition lever to secure the partition in place. 4) Set the desired paper size in the LCD setting menu.

  • Page 32: Self-Test

    SRP-S300II 4. Self-Test The self-test checks whether the printer has any problems. If the self-diagnostics reveal no error in the printer, please see other device or software. If the printer does not run normally, please contact the place of purchase.
  • Page 33 SRP-S300II 3) Select the TOOLS menu. 4) Enter the Self-Test menu. 5) Press the select button to run the self-test, and the self-test page will be printed. - 33 - Ver. 1.00...

  • Page 34: Self-Test Using The Feed Button

    SRP-S300II 4-2 Self-Test Using the Feed Button 1) After the printer boots up, open the printer cover. 2) Self-test is started when paper is loaded, the FEED button is pressed, and the printer cover is closed. 3) The printer stops after printing the version information and setting status as shown below.

  • Page 35: If "Exit Self-Test" Is Selected

    SRP-S300II 4-2-1 If “Exit SELF-TEST” is selected ① The Self-Test ends automatically as it prints the following line and cuts the paper. - COMPLETED - ② The printer goes into normal print mode upon completion of the Self-Test. 4-2-2 If “Mode Selection” is selected ①...

  • Page 36: If "Vmsm Selection" Is Selected

    SRP-S300II 4-2-3 If “VMSM Selection” is selected ① The following lines will be printed when the VMSM opens. ** VMSM Selection ** 0 : Save Setting and exit 1 : Print current settings 2 : Set Print Density 3 : Set Print Speed...

  • Page 37: Lcd Menu

    SRP-S300II 5. LCD Menu You can check the printer’s status and settings on the LCD screen. • Icons on top Icon Description Bluetooth enabled, host device not connected Bluetooth enabled, host device connected Wireless LAN enabled, wireless LAN signal strength...
  • Page 38 SRP-S300II • Main menu icons Icon Description LCD brightness Setting 1) 100% 2) 75% 3) 50% 4) 25% Volume Setting 1) 100% 2) 66% 3) 33% 4) 0%(Mute) Settings (Default Password: 0000) 1) Tools 2) Media 3) Cutter 4) Sensor...
  • Page 39 SRP-S300II 80mm Paper Width 58mm 40mm Enable Back Feed Disable Partial Cut Full Cut Type Program Cut Cutter No Cut Disable When Cover Close Enable Normal Type BlackMark Sensor Enable Taken Disable Taken Counter [1 ~ 5] Disable Level 1...
  • Page 40 SRP-S300II PC866(Cyrillic) PC852(Latin2) PC858(Euro) PC862(Israel) PC864(Arabic) THAI42(Thai) WPC1253(Greek) WPC1254(Turkish) WPC1257(Baltic) Farsi WPC1251(Cyrillic) PC737(Greek) PC775(Baltic) THAI14(Thai) Hebrew Old Code WPC1255(Hebrew) THAI11(Thai) THAI18(Thai) PC855(Cyrillic) PC857(Turkish) PC928(Greek) THAI16(Thai) WPC1256(Arabic) WPC1258(Vietnamese) Khmer(Cambodia) PC852e(Modifications) PC864e(Modifications) PC865e(Modifications) PC866e(DTKII) WPC1250(Czech) PC866eII(Modifications) TCVN-3(Vietnamese) TCVN-3 Capital(Vietnamese) VISCII(Vietnamese) PC912(Albanian) Single Byte...
  • Page 41 SRP-S300II SHIFT-JIS 24 x 24 Double Byte Size 18 x 24 1 PASS THAI Font 3 PASS Disable Zero Charcter Enable 9 x 17 Swap Font B/C 9 x 24 U.S.A France Germany Denmark I Sweden Italy Spain I Japan...
  • Page 42 SRP-S300II 5GHz 2.4GHz/5GHz 5GHz/2.4GHz Open Shared WPA1-PSK Authentication WPA2-PSK WPA1-EAP WPA2-EAP None Encrption WEP64/128 ESSID BIXOLON_AP Static IP Alloc. Method DHCP IP Address [0.0.0.0] ~ [255.255.255.255] Subnet Mask [0.0.0.0] ~ [255.255.255.255] GateWay [0.0.0.0] ~ [255.255.255.255] Inact. Time [0 ~ 3600]...
  • Page 43 SRP-S300II Device Addr. 00:15:94:00:00:00 9600 19200 38400 Baud Rate 57600 115200 2400 4800 Serial 8bits Data bits 7bits NONE Parity bits EVEN DTR/DSR Flow Control XON/XOFF - 43 - Ver. 1.00...

  • Page 44: Maintenance

    SRP-S300II 6. Maintenance 6-1 Paper Jam • Never force the paper out in the event of a paper jam. If paper is stuck, turn the printer ON/OFF and open the cover to remove the crumpled paper inside the printer. If the Printer Cover will not open, please follow the following instructions.
  • Page 45 SRP-S300II 6) Reassemble the removed cutter cover by engaging the protrusions on both sides of the cutter cover into the lower case protrusions as shown in the arrows. 7) Turn the printer ON and use it If the cover does not open, do not forcibly open it.

  • Page 46: Cleaning Printer

    SRP-S300II 6-2 Cleaning Printer • The presence of dust, foreign matter, adhesive matter, or other pollutants inside the printer’s head and internal capacity may undermine printing quality. It is recommended to clean printer at every paper roll change. Periodic cleaning (every 3 months at minimum) is recommended to maintain print quality.

  • Page 47: Specifications

    SRP-S300II 7. Specifications 7-1 Printer Specifications Printing Method Thermal Line Printing Dot Density 203 dpi (8 dots/mm) 80mm 72mm Print Width 58mm 48mm 40mm 32mm Paper Width 79.5 ±0.5mm, 57.5 ±0.5mm, 39.5 ±0.5mm, 48(Font A), 64(Font B), 64(Font C) Characters Per Line (Default) ※...
  • Page 48 SRP-S300II 7-2 Recommended Papers Sticky, Restick, Linerless Extreme - Ricoh BL-RP040-10 (40mm), BL-RP058-10 (58mm), BL-RP080-10 (80mm) - StickyPOS 40MMRL90-9000(40mm), 2CR-11 58X350(58mm) 2CR-11 80X350(80mm) - MAXStick 2GO: MS2142402GO3S(58mm), MS3182402GO4S(80mm) PLUSD: MS1732290PLUSD HVHR (40mm), MS214170PLUSD (58mm), MS318170PLUSD (80mm), MS3183752GOPLUSD (80mm) X2: MS11732270X2HRHT (40mm), MS214150X2(58mm)
  • Page 49 - The use of papers other than those recommended above may Cause damage to the printer’s TPH or degrade the printing quality. BIXOLON is not responsible for the damage caused by non-recommended papers. - If you have to use other products, we recommend that you use papers with a similar level of quality to the recommended ones.

  • Page 50: Revision History

    SRP-S300II Revision history Ver. Date Description 1.00 23-12-2024 - 50 - Ver. 1.00...
