  • Page 1 User’s Manual SRP-S3000 LINERLESS PRINTER Ver. 2.00 www.bixolon.com...

  • Page 2: Copyright

    It is strictly prohibited to copy, store, and transmit the whole or any part of the manual and any property of the product without the prior written approval of BIXOLON Co., Ltd. The information contained herein is designed only for use with this BIXOLON product.
  • Page 3 SRP-S3000 Warning Hazardous moving parts Keep fingers and other body parts away Pull the print head lever can be stop all moving parts. IEC 60417-6057 (2011-05) for other moving parts. Mise en garde Les appareils électroniques, tels que les imprimantes, risquent d'être endommagés par l'électricité...
  • Page 4 SRP-S3000 Compliance information This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
  • Page 5 SRP-S3000 Waste Electrical and Electric Equipment (WEEE) This marking shown on the product or its literature, indicates that is should not be disposed with other household wastes at the end of its working life, To prevent possible harm to the environment or human health from uncontrolled waste disposal, please separate this from other types of wastes and recycle it responsibly to promote the sustainable reuse of material resources.

  • Page 6: Warning & Caution

    Do not connect multiple products to a Only use authentic products from single or faulty power outlet. Use only BIXOLON. The company will not provide grounded power outlets that meet the post-sale support for damaged or other industry standard. Noncompliance may quality issues that any fake cause electric shock or fire.
  • Page 7 Do not place heavy product, please contact the original objects, liquids, or metals on the place of purchase or through product. This could cause damage to BIXOLON website’s product repair the product or a fire. page (www.bixolon.com). Ver. 2.00 - 7 -...

  • Page 8: Manual Introduction

    SRP-S3000 Manual Introduction This manual provides basic information on printers and provides ways to install, use, and check them. In order to protect the safety of users and prevent property damage, be fully familiar with this manual before using the product. Please use it.

  • Page 9: Printer Introduction

    SRP-S3000 Printer Introduction The SRP-S3000 is a premium 3-inch(80 mm) Linerless Printer built with LinerlessPro™ technology. Supporting multiple programming languages including BXL / POS, SLCS™, BPL-Z™ and BPL-C™. The SRP-S3000 provides stable printing for Linerless Extreme, Restick and Liner Label (Gap, Black Mark, Notch, Continuous) media. The standard colour LCD helps users to change the printer setting alongside count pending orders so they can optimise processing operations proactively.

  • Page 10: Table Of Contents

    SRP-S3000 Table of Contents Copyright ..........................2 WARNING & CAUTION ....................... 6 Manual Introduction ......................8 Printer Introduction ......................9 1. Content Confirmation ....................11 2. Product Part Names ....................12 2-1 Printer Part Names ......................12 2-2 Interface Part Names ...................... 13 2-2-1 USB Interface (Device Function, USB B Type Connector) ........

  • Page 11: Content Confirmation

    SRP-S3000 1. Content Confirmation • If there is any part missing, please contact the place of purchase. • The actual part may look different from the image. SRP-S3000 Standard Components Installation Guide AC/DC Adapter Power Cord USB A-B Cable Partition 2ea...

  • Page 12: Product Part Names

    SRP-S3000 2. Product Part Names 2-1 Printer Part Names Controller Power Button Manual Cutter Cutter Cover Cover Open Lever Printer Cover Ver. 2.00 - 12 -...

  • Page 13: Interface Part Names

    SRP-S3000 2-2 Interface Part Names • Connect the printer to the host computer using the right interface cable that complies with the specifications of the interface. 2-2-1 USB Interface (Device Function, USB B Type Connector) USB B Port (Device Function) Pin No.

  • Page 14: Usb Interface (Host Function, Usb A Type Connector)

    SRP-S3000 2-2-2 USB Interface (HOST Function, USB A Type Connector) USB A Port (HOST Function) Pin No. Signal Name Designation (Color) Function Shell Shield Drain Cable Frame Ground VBUS Host Power WHITE Data Line (D-) GREEN Data Line (D+) BLACK...

  • Page 15: Ethernet Interface

    If power is on, your data may be lost. Refer to the Network Connection Manual for more detailed instructions about how to establish the connection. The Network connection manual is on the BIXOLON website (www.bixolon.com) We're offering it. Ver. 2.00...

  • Page 16: Serial Interface (Rs-232C)

    SRP-S3000 2-2-4 Serial Interface (RS-232C) Serial Port Pin No. Signal Name Direction Function Output Transmit Data Input Receive Data Output Ready To Send Input Clear To Send Signal Ground Connect or disconnect the communication cable while the printer power is off. If power is on, your data may be lost.

  • Page 17: Wireless Lan Interface (Option)

    Capability. (PDA, PC, smartphone, tablet PC, etc.) Refer to the Network Connection Manual for more detailed instructions about how to establish the connection. The Network connection manual is on the BIXOLON website (www.bixolon.com) We're offering it. 2-2-6 Bluetooth Interface (Option)

  • Page 18: Drawer Kick-Out Port

    SRP-S3000 2-2-7 Drawer Kick-out Port Connect the Drawer Kick-out cable to the drawer kick-out port on the rear side of the printer. Drawer Kick-out Port Pin No. Signal Name Direction Frame Ground Drawer Kick-out Drive Signal 1 Output Drawer Open/Close Signal...
  • Page 19 SRP-S3000 - Use a cash drawer that meets the printer specifications. Using a cash drawer that is inappropriate to the specs or Using it as a power supply for a separate device may result in damage to the product - Do not connect a telephone line to the drawer kick-out port.

  • Page 20: Installation & Usage

    SRP-S3000 3. Installation & Usage 3-1 Printer Installation Placings - Allow sufficient space around the printer for proper ventilation. - Do not place objects close to the back or bottom of the printer, which may hinder the air circulation. - Install the printer on a flat and level surface.

  • Page 21: Power On

    SRP-S3000 3-2 Power on 1) After turning the printer off, connect the Power cord jack to the printer’s power port. Power Port Power Cord Jack 2) When connecting the power cord jack, ensure that it is inserted in the correct direction.
  • Page 22 4) Press the “ON” switch to turn on the printer. - Check the power supply’s label to check its electronic specs. - Only use a power supply provided by BIXOLON. BIXOLON shall bear no responsibility for damage caused by using a third-party power supply.

  • Page 23: Inserting And Changing The Paper Roll

    SRP-S3000 3-3 Inserting and changing the paper roll Use paper roll that complies with the specifications If you use a paper roll including paper core attached to paper, the paper may not be properly recognized as paper Empty due to not proper releasing of paper.
  • Page 24 SRP-S3000 2) Replace with a new one as shown in the image. 3) Check the orientation of the roll paper when inserting it into the printer. Ver. 2.00 - 24 -...
  • Page 25 SRP-S3000 4) Pull out a small amount of paper as shown in the picture, and close the Printer Cover. When closing the Printer Cover, hold down the center of printer cover firmly so that paper roll is loaded correctly. Ver. 2.00...

  • Page 26: Using Controller

    SRP-S3000 3-4 Using Controller Explanation Navigate the LCD menu Menu - Press the button to navigate from the top-left to Navigation the bottom-right corner. Select an item in the LCD menu Menu Select - Press the button to select an LCD menu item or save the settings to the printer.

  • Page 27: Mounting Partition

    SRP-S3000 3-5 Mounting Partition • The Partition shape is the same and is used separately for each paper size (40,58mm). The position to secure the partition varies depending on the type of paper. 1. 58mm (2-inch) roll paper: mount 1 partition at Position #1.

  • Page 28: Printer Setting Change

    SRP-S3000 4. Printer Setting Change Use the Unified Utility or LCD to change the virtual memory switch settings. - Turn the product power ON/OFF by using the virtual memory switch utility. - For more details, please refer to Utility and [6. LCD Menu].

  • Page 29: Self-Test

    SRP-S3000 5. Self-Test The self-test checks whether the printer has any problems. If the self-diagnostics reveal no error in the printer, please see other device or software. If the printer does not run normally, please contact the place of purchase.
  • Page 30 SRP-S3000 • Self-test print page sample BIXOLON SRP-S3000 CONFIGURATION FIRMWARE VERSION : V01.00 STD 010118 EMULATION : SLCS & BPL-Z & BPL-C PRINT DARKNESS : 0/30 PRINT SPEED : 5 IPS TEAR OFF VALUE : +000 DOT TEAR OPTION : TEAR-OFF...
  • Page 31 RF INTERFACE STATUS (BT) RF INTERFACE STATUS (WLAN) BLUETOOTH F/W VER : 2.0.4 WLAN F/W VER : 02.02(4002) MAC ADDRESS MAC ADDRESS FRIENDLY NAME : SRP-S3000 SYSTEM NAME : SRP-S3000 MODE : CLASSIC NETWORK MODE : SOFT AP AUTH & ENCRYPT : ENABLED FREQUENTY : (PRIORITY)2.4GHZ/5GHZ...

  • Page 32: Lcd Menu

    SRP-S3000 6. LCD Menu You can check the printer’s status and settings on the LCD screen. • Icons on top Icon Description Bluetooth enabled, host device not connected Bluetooth enabled, host device connected Wireless LAN enabled, wireless LAN signal strength...
  • Page 33 SRP-S3000 • Main menu icons Icon Description View/change printer settings 1) Communication 2) Media 3) Sensor 4) Language 5) Sound 6) Brightness Media settings 1) Print speed 2) Print density 3) Headlock 4) Position - Cut - Printing position - Orientation...
  • Page 34 SRP-S3000 Icon Description Taken sensor settings 1) Turn ON/OFF Taken sensor 2) Set Taken sensor operation pages Printer information 1) Version - Printer, WLAN, Bluetooth 2) Bluetooth 3) Wireless LAN 4) Wired LAN 5) Serial 6) Use 7) Repair View/change sensor settings...

  • Page 35: Maintenance

    SRP-S3000 7. Maintenance 7-1 Paper Jam • If paper is stuck, turn the printer ON/OFF and open the Printer Cover to remove the crumpled paper inside the printer. If the cover will not open, please follow the following instructions. 1) Turn the printer OFF.

  • Page 36: Cleaning Printer

    SRP-S3000 7-2 Cleaning Printer • The presence of dust, foreign matter, adhesive matter, or other pollutants inside the printer’s head and internal capacity may undermine printing quality. Periodic cleaning (every 3 months at minimum) is recommended to maintain print quality. It is recommended to clean after every 30 rolls when using Sticky, Re-stick, Linerless Extreme paper.

  • Page 37: Specifications

    SRP-S3000 8. Specifications 8-1 Printer Specifications Printing Method Thermal printing Dot Density 203 dpi (8dots/mm) Paper Width 72mm, 48mm, 32mm Printing Width 80mm, 58mm, 40mm Application BXL/POS SLCS, BPL-Z™, BPL-C™ 10 SLCS Resident Bitmap Fonts One SLCS Resident Scalable Font 16 BPL-Z™...
  • Page 38 SRP-S3000 S3000K: Serial, USB, Ethernet S3000BaK: Serial, USB, Ethernet, Bluetooth 5.2 Interface S3000WDaK: Serial, USB, Ethernet, WLAN (2.4GHz, 5GHz) Drawer Kick-out Port 2ports (with Y-type cable) Input Voltage 100~240 VAC AC/DC Adapter Frequency 50/60 Hz Output Voltage 24 VDC Operating: 0 ~ 40 ℃...

  • Page 39: Recommended Papers

    - The use of papers other than those recommended above may cause damage to the printer’s TPH or degrade the printing qua lity. BIXOLON is not responsible for the damage caused by non-recommended papers. - If you have to use other products, we recommend that you use papers with a similar level of quality to the recommended ones.
  • Page 40 SRP-S3000 Revision history Ver. Date Description 1.00 28-01-2021 Add Authentication Statement 1.01 20-08-2021 (Wireless Communication) 2.00 06-11-2023 New Form Ver. 2.00 - 40 -...
