Summary of Contents for BIXOLON SRP-S320
- Page 1 User’s Manual SRP-S320 LINERLESS PRINTER Ver. 2.00 www.bixolon.com...
-
Page 2: Copyright
It is strictly prohibited to copy, store, and transmit the whole or any part of the manual and any property of the product without the prior written approval of BIXOLON Co., Ltd. The information contained herein is designed only for use with this BIXOLON product. - Page 3 SRP-S320 Warning Hazardous moving parts Keep fingers and other body parts away Pull the print head lever can be stop all moving parts. IEC 60417-6057 (2011-05) for other moving parts. Mise en garde Les appareils électroniques, tels que les imprimantes, risquent d'être endommagés par l'électricité...
- Page 4 SRP-S320 Compliance information This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
- Page 5 SRP-S320 Waste Electrical and Electric Equipment (WEEE) This marking shown on the product or its literature, indicates that is should not be disposed with other household wastes at the end of its working life, to prevent possible harm to the environment or human health from uncontrolled waste disposal, please separate this from other types of wastes and recycle it responsibly to promote the sustainable reuse of material resources.
-
Page 6: Warning & Caution
Do not connect multiple products to a Only use authentic products from single or faulty power outlet. Use only BIXOLON. The company will not provide grounded power outlets that meet the post-sale support for damaged or other industry standard. Noncompliance may quality issues that any fake cause electric shock or fire. - Page 7 Do not place heavy product, please contact the original objects, liquids, or metals on the place of purchase or through product. This could cause damage to BIXOLON website’s product repair the product or a fire. page (www.bixolon.com). Ver. 2.00 - 7 -...
-
Page 8: Manual Introduction
SRP-S320 Manual Introduction This manual provides basic information on printers and provides ways to install, use, and check them. In order to protect the safety of users and prevent property damage, be fully familiar with this manual before using the product. Please use it. -
Page 9: Printer Introduction
Linerless printer SRP-S320 is specifically designed for Linerless media with extreme level of adhesion.Offering large media roll capacity of up to 120 mm the SRP-S320 produces 203 dpi linerless labels at 150 mm/sec. Providing 4 media width options including 40 / 58 / 62 / 80 mm. -
Page 10: Table Of Contents
SRP-S320 Table of Contents Copyright ..........................2 WARNING & CAUTION ....................... 6 Manual Introduction ......................8 Printer Introduction ......................9 1. Content Confirmation ....................11 2. Product Part Names ....................12 2-1 Printer Part Names ......................12 2-2 Interface Part Names ...................... 13 2-2-1 USB (Built-in) ...................... -
Page 11: Content Confirmation
SRP-S320 1. Content Confirmation • If there is any part missing, please contact the place of purchase. • The actual part may look different from the image. SRP-S320 Installation Guide Power cord Partition 2ea Ver. 2.00 - 11 -... -
Page 12: Product Part Names
SRP-S320 2. Product Part Names 2-1 Printer Part Names Printer Cover Cutter Cover Feed Button Manual Cutter Cover Open Lever Power Switch Ver. 2.00 - 12 -... -
Page 13: Interface Part Names
SRP-S320 2-2 Interface Part Names • Connect the printer to the host computer using the right interface cable that complies with the specifications of the interface. 2-2-1 USB (Built-in) USB Port Pin No. Signal Name Designation (Color) Function Shell Shield... -
Page 14: Ethernet (Built-In)
If power is on, your data may be lost. - Information such as IP and Mac can be found by operating the function key. - Refer to the utility and network connection manual for Interface connection information. (www.bixolon.com) Ver. 2.00 - 14 -... -
Page 15: Single Serial Interface Card (Rs-232C)
SRP-S320 2-2-3 Single Serial Interface Card (RS-232C) Serial Port Pin No. Signal Name Direction Function Frame Ground Output Transmit Data Input Receive Data Output Ready To Send Input Clear To Send Signal Ground Data Terminal Output Ready Connect or disconnect the communication cable while the printer power is off. -
Page 16: Wireless Lan Interface Card
(PDA, PC, smartphone, tablet PC, etc.). Refer to the Network Connection Manual for more detailed instructions about how to establish the connection. The Network connection manual is on the BIXOLON website (www.bixolon.com) We're offering it. Ver. 2.00 - 16 -... -
Page 17: Bluetooth Interface Card
(PDA, PC, smartphone, tablet PC, etc.) Refer to the Bluetooth Connection Manual for more detailed instructions about how to establish the connection. The Bluetooth Connection manual is on the BIXOLON website (www.bixolon.com) We're offering it. Ver. 2.00 - 17 -... -
Page 18: B-Gate Interface Card
SRP-S320 2-2-6 B-gate Interface Card USB A type: ①②③④ Pin No. Signal Name Designation (Color) Function Shell Shield Drain Cable Frame Ground VBUS Host Power WHITE Data Line (D-) GREEN Data Line (D+) BLACK Signal Ground Ethernet: ⓑ Pin No. - Page 19 SRP-S320 USB Mini TYPE: ⓐ Pin No. Signal Name Designation (Color) Function Shell Shield Drain Cable Frame Ground VBUS Host Power WHITE Data Line (D-) GREEN Data Line (D+) BLACK Signal Ground - USB A connectors ①② can be used to connect the printer to supported peripheral devices.
-
Page 20: Installation & Usage
SRP-S320 3. Installation & Usage 3-1 Printer Installation Placings - Allow sufficient space around the printer for proper ventilation. - Do not place objects close to the back or bottom of the printer, which may hinder the air circulation. - Install the printer on a flat and level surface. -
Page 21: Turn On The Power
SRP-S320 3-2 Turn on the power 1) After turning the printer off, connect the power cord jack to the printer’s power port. Power Cord Jack Power Port 2) Plug it into the power outlet on the wall. 3) Press the “ON” switch to turn on the printer. - Page 22 SRP-S320 - Check the power supply’s label to check its electronic specs. - Only use a power supply provided by BIXOLON. BIXOLON shall bear no responsibility for damage caused by using a third-party power supply. - When removing the power supply, make sure you have a firm grasp of the plug terminal of the power jack and the printer and pull horizontally.
-
Page 23: Inserting And Changing The Paper Roll
SRP-S320 3-3 Inserting and changing the paper roll Use paper roll that complies with the specifications If you use a paper roll including paper core attached to paper, the paper may not be properly recognized as paper Empty due to not proper releasing of paper. - Page 24 SRP-S320 2) Replace with a new one as shown in the image. 3) Check the orientation of the roll paper when inserting it into the printer. Ver. 2.00 - 24 -...
- Page 25 SRP-S320 4) Pull out a small amount of paper as shown in the picture, and close the Printer Cover. When closing the Printer Cover, hold down the center of printer cover firmly so that paper roll is loaded correctly. Ver. 2.00...
-
Page 26: Using Controller
SRP-S320 3-4 Using Controller Explanation POWER LED The Power LED light is on whenever the printer is on. Error LED is on when there is an error ERROR LED such as no paper roll, open cover, etc. Paper LED is on when the paper roll is almost used up or there is no paper roll inside. -
Page 27: Mounting Partition
SRP-S320 3-5 Mounting Partition • Position the partition on the front and back grooves and press the center part to fix it as shown in the picture. The position to secure the partition varies depending on the type of paper. -
Page 28: Setting Volume
SRP-S320 3-6 Setting Volume • Use a cross-head screwdriver to adjust the volume. To mute the volume, turn it counter-clockwise all the way. Ver. 2.00 - 28 -... -
Page 29: Taken Sensor Function
SRP-S320 3-7 Taken Sensor Function • When it comes to Taken Sensor, it will detect the paper not to feed next paper before user detach it. Ver. 2.00 - 29 -... -
Page 30: Printer Setting Change
SRP-S320 4. Printer Setting Change This product supports virtual memory switch change the use the virtual memory switch utility. Use virtual memory switch management function for self-diagnosis. - Turn the product power ON/OFF by using the virtual memory switch utility. -
Page 31: Self-Test
SRP-S320 5. Self-Test The self-test checks whether the printer has any problems. If the self-diagnostics reveal no error in the printer, please see other device or software. If the printer does not run normally, please contact the place of purchase. - Page 32 SRP-S320 (1) If “Continuous SELF-TEST” is selected ① Press the Feed button for less than one second to print the preset page. ② The self test ends automatically as it prints the following line and cuts the paper *** COMPLETED *** ③...
- Page 33 SRP-S320 (2) If “VMSM Selection” is selected ① The following lines will be printed when the VMSM opens. ** VMSM Selection ** 0 : Exit and reboot printer 1 : Print current settings 2 : Set Print Density 3 : Set Print Speed...
-
Page 34: Hexadecimal Dumping
SRP-S320 6. Hexadecimal Dumping This function allows experienced users to see exactly what data is coming to the printer. This can be useful in finding software problems. When you turn on the hexadecimal dump function, the printer prints all commands and data in hexadecimal format along with a guide section to help you find specific commands. -
Page 35: Maintenance
SRP-S320 7. Maintenance 7-1 Paper Jam Never force the paper out in the event of a paper jam. If paper is stuck, turn the printer ON/OFF and open the Printer Cover to remove the crumpled paper inside the printer. If the cover will not open, please follow the following instructions. -
Page 36: Cleaning Printer
SRP-S320 7-2 Cleaning Printer • The presence of dust, foreign matter, adhesive matter, or other pollutants inside the printer’s head and internal capacity may undermine printing quality. Periodic cleaning (every 3 months at minimum) is recommended to maintain print quality. It is recommended to clean after every 30 rolls when using Sticky, Re-stick, Linerless Extreme paper. -
Page 37: Specifications
SRP-S320 8. Specifications 8-1 Printer Specifications Printing Method Thermal printing Dot Density 203 dpi (8dots/mm) 80mm 72mm 62mm 60mm Paper Width / Printing Width 58mm 48mm 40mm 32mm 79.5 ±0.5mm, 61.5 ±0.5mm, Paper Width 57.5 ±0.5mm, 39.5 ±0.5mm 48(Font A), 64(Font B), 64(Font C) No. -
Page 38: Recommended Papers
- The use of papers other than those recommended above may cause damage to the printer’s TPH or degrade the printing qua lity. BIXOLON is not responsible for the damage caused by non-recommended papers. - If you have to use other products, we recommend that you use papers with a similar level of quality to the recommended ones. - Page 39 SRP-S320 Revision History Ver. Date Description 1.00 21-10-2020 1. Thermal Receipt Printer Linerless Printer 1.01 05-01-2021 2. picture correction 1.02 20-08-2021 Add Authentication Statement (Wireless Communication) 2.00 06-11-2023 New form Ver. 2.00 - 39 -...
