SUPERSERVER 1028GR-TR/TRT Series User's Manual
3. Secure each card to the bracket using the screws that are included for this
purpose. Keplers: Remove the bracket on the end of the GPU, add a washer
(included in kit) between the plate and the PCB for each screw, then attach the
GPU to the bracket.
4. Carefullly position each bracket in the chassis as illustrated, aligning the four
mounting holes in the top and side of each bracket with the corresponding
mounting holes in the chassis. Pay attention to the airflow arrows to install each
card into the correct side of the chassis
5. Secure the bracket to the chassis by using the screws provided.
6. After a GPU card is installed, you must connect it to one of the following power
headers on the serverboard: JPW3, JPW4, JPW6, JPW7, JPW8 or JPW11.
Important Note for Kepler GPUs: Note the airflow arrows on top of the GPU card.
The card with the arrow pointing toward the Tesla logo, right to left airflow, should
go on the left side of the chassis, and the card with the arrow pointing away from
the Tesla logo, left to right airflow, should go on the right side of the chassis (when
viewed from the front of the system).
6-6
