Summary of Contents for Supermicro SUPERSERVER 1028R-WC1R

  • Page 1 ® SUPERSERVER 1028R-WC1R 1028R-WC1RT USER'S MANUAL Revision 1.0b...
  • Page 2 This product, including software and documentation, is the property of Supermicro and/or its licensors, and is supplied only under a license. Any use or reproduction of this product is not allowed, except as expressly permitted by the terms of said license.
  • Page 3 About This Manual This manual is written for professional system integrators and PC technicians. It provides information for the installation and use of the SuperServer 1028R-WC1R(T). Installation and maintenance should be performed by experienced technicians only. The SuperServer 1028R-WC1R(T) is a high-end server based on the SC116AC-R706WBP 1U rackmountable chassis and the X10DRW-i(T) dual processor serverboard.
  • Page 4 SUPERSERVER 1028R-WC1R(T) USER'S MANUAL Chapter 5: Advanced Serverboard Setup Chapter 5 provides detailed information on the X10DRW-i(T) serverboard, including the locations and functions of connections, headers and jumpers. Refer to this chapter when adding or removing processors or main memory and when reconfi...
  • Page 5 Preface Notes...

  • Page 6: Table Of Contents

    SUPERSERVER 1028R-WC1R(T) USER'S MANUAL Table of Contents Chapter 1 Introduction Overview ......................1-1 Serverboard Features ..................1-2 Processors ...................... 1-2 Memory ......................1-2 SAS/SATA......................1-2 PCI Expansion Slots ..................1-3 Rear I/O Ports ....................1-3 Server Chassis Features ................1-3 System Power ....................
  • Page 7 Table of Contents Chapter 3 System Interface Overview ......................3-1 Control Panel Buttons ..................3-1 Power ......................3-1 UID ........................3-2 Control Panel LEDs ..................3-2 Universal Information LED ................3-2 NIC1 ........................ 3-3 NIC2 ........................ 3-3 HDD ......................... 3-3 Power ......................
  • Page 8 SUPERSERVER 1028R-WC1R(T) USER'S MANUAL Installing the Processor and Heatsink ............5-7 Installing an LGA 2011 Processor ..............5-7 Installing and Removing a Passive CPU Heatsink ........5-10 Installing Memory ...................5-11 Memory Support .....................5-11 DIMM Installation ...................5-11 Serverboard Details ..................5-14 Connector Defi...
  • Page 9 Table of Contents Security ......................7-28 Save & Exit ....................7-29 Appendix A BIOS Error Beep Codes Appendix B System Specifi cations...
  • Page 10 SUPERSERVER 1028R-WC1R(T) USER'S MANUAL Notes...

  • Page 11: Chapter 1 Introduction

    Chapter 1 Introduction Overview The SuperServer 1028R-WC1R(T) is a high-end server comprised of two main subsystems: the SC116AC-R706WBP 1U chassis and the X10DRW-i(T) dual processor serverboard. Please refer to our web site for information on operating systems that have been certifi ed for use with the system (www.supermicro.com).

  • Page 12: Serverboard Features

    If you have any questions, please contact our support team at: support@supermicro.com Serverboard Features The SuperServer 1028R-WC1R(T) is built around the X10DRW-i(T), a dual processor serverboard based on the Intel PCH-C612 chipset and designed to provide maximum performance. Below are the main features of the X10DRW-i(T),.

  • Page 13: Pci Expansion Slots

    IPMI port. A UID (Unit Identifi er) button and LED are also located beside the VGA port. Server Chassis Features The SC116AC-R706WBP is Supermicro's third-generation 1U chassis and features ten (10) 2.5" hard drive bays and two high-effi ciency power supplies. The following is a general outline of the main features of the SC116AC-R706WBP chassis.

  • Page 14: Front Control Panel

    SUPERSERVER 1028R-WC1R(T) USER'S MANUAL Front Control Panel The control panel on the SC116AC-R706WBP provides important system monitoring and control information. LEDs indicate power on, network activity, hard disk drive activity and a UID (Universal Information) LED. Also present are a main power button and a UID button.
  • Page 15 Chapter 1: Introduction Figure 1-1. Intel PCH-C612 Chipset: System Block Diagram Note: This is a general block diagram. Please see Chapter 5 for details. SXB2 RIGHT SLOT PCIE 3.0 x16 SXB1B (lower) Left SLOT WIO Slots PCIE 3.0 x16 SXB1A SXB2 PCIE x16 Rear...

  • Page 16: Contacting Supermicro

    Super Micro Computer, Inc. 980 Rock Ave. San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) support@supermicro.com (Technical Support) Web Site: www.supermicro.com Europe Address: Super Micro Computer B.V. Het Sterrenbeeld 28, 5215 ML...

  • Page 17: Chapter 2 Server Installation

    Unpacking the System You should inspect the box the SuperServer 1028R-WC1R(T) was shipped in and note if it was damaged in any way. If the server itself shows damage you should fi...

  • Page 18: Warnings And Cautions

    SUPERSERVER 1028R-WC1R(T) USER'S MANUAL • This product is for installation only in a Restricted Access Location (dedicated equipment rooms, service closets and the like). • This product is not suitable for use with visual display work place devices according to §2 of the the German Ordinance for Work with Visual Display Units. Warnings and Cautions Rack Precautions •...

  • Page 19: Rack Mounting Considerations

    Chapter 2: Server Installation Rack Mounting Considerations Warning! To prevent bodily injury when mounting or servicing this unit in a rack, you must take special precautions to ensure that the system remains stable. The following guidelines are provided to ensure your safety: •...

  • Page 20: Rack Mounting Instructions

    SUPERSERVER 1028R-WC1R(T) USER'S MANUAL Rack Mounting Instructions This section provides information on installing the SC116 chassis into a rack unit with the rails provided. There are a variety of rack units on the market, which may mean the assembly procedure will differ slightly. You should also refer to the installation instructions that came with the rack unit you are using.

  • Page 21: Inner Rail Extension

    Chapter 2: Server Installation Inner Rail Extension The SC116 chassis includes a set of inner rails in two sections: inner rails and inner rail extensions. The inner rails are pre-attached and do not interfere with normal use of the chassis if you decide not to use a server rack. Attach the inner rail extension to stabilize the chassis within the rack.

  • Page 22: Outer Rails

    SUPERSERVER 1028R-WC1R(T) USER'S MANUAL Outer Rails Installing the Outer Rails to the Rack 1. Attach the shorter outer rail to the outside of the longer outer rail. You must align the pins with the slides. Both bracket ends must face the same direction. 2.
  • Page 23 Chapter 2: Server Installation Figure 2-4. Installing the Outer Rails to the Server Rack...
  • Page 24 SUPERSERVER 1028R-WC1R(T) USER'S MANUAL Installing the Chassis into a Rack 1. Confi rm that chassis includes the inner rails and inner rail extensions. Also confi rm that the outer rails are installed on the rack. 2. Align the chassis inner rails with the front of the out rails on the rack. 3.

  • Page 25: Installing The Chassis Into A Telco Rack

    Chapter 2: Server Installation Installing the Chassis into a Telco rack To install the chassis into a Telco or post-style rack, use two L-shaped brackets on either side of the chassis (four total). First, determine how far follow the server will extend out the front of the rack.
  • Page 26 SUPERSERVER 1028R-WC1R(T) USER'S MANUAL Notes 2-10...

  • Page 27: Chapter 3 System Interface

    Chapter 3: System Interface Chapter 3 System Interface Overview There are several LEDs on the control panel and on the drive carriers that provide system and component status for the 1028R-WC1R(T) server. This chapter explains the meanings of all LED indicators and the appropriate responses that need to be taken.

  • Page 28: Uid

    SUPERSERVER 1027R-73DBRF User's Manual Depressing the UID (unit identifi er) button illuminates an LED on both the front and rear of the chassis for easy system location in large stack confi gurations. The LED will remain on until the button is pushed a second time. Another UID button on the rear of the chassis serves the same function.

  • Page 29: Nic1

    Chapter 3: System Interface NIC1 Indicates network activity on GLAN1 when fl ashing. NIC2 Indicates network activity on GLAN2 when fl ashing. Indicates IDE channel activity. SAS2/SATA drive and/or DVD-ROM drive activity when fl ashing. Power Indicates power is being supplied to the system's power supply units. This LED should normally be illuminated when the system is operating.

  • Page 30: Drive Carrier Leds

    SUPERSERVER 1027R-73DBRF User's Manual Drive Carrier LEDs The chassis includes externally accessible SAS/SATA/NVMe drives. Each drive carrier displays two status LEDs on the front of the carrier. LED Color State Status Activity LED Blue Solid On SAS/NVMe drive installed Blue Blinking I/O activity Status LED...

  • Page 31: Chapter 4 Standardized Warning Statements For Ac Systems

    The following statements are industry standard warnings, provided to warn the user of situations which have the potential for bodily injury. Should you have questions or experience difficulty, contact Supermicro's Technical Support department for assistance. Only certifi ed technicians should attempt to install or confi gure components.
  • Page 32 SUPERSERVER 1028R-WC1R(T) USER'S MANUAL Warnung WICHTIGE SICHERHEITSHINWEISE Dieses Warnsymbol bedeutet Gefahr. Sie befi nden sich in einer Situation, die zu Verletzungen führen kann. Machen Sie sich vor der Arbeit mit Geräten mit den Gefahren elektrischer Schaltungen und den üblichen Verfahren zur Vorbeugung vor Unfällen vertraut.
  • Page 33 Warning Statements for AC Systems ‫ﺟﺴﺪﯾﺔ‬ ‫اﺻﺎﺑﺔ‬ ‫ﺗﺘﺴﺒﺐ ﻓﻲ‬ ‫ﺣﺎﻟﺔ ﯾﻤﻜﻦ أن‬ ‫اﻧﻚ ﻓﻲ‬ ‫ﺧﻄﺮ‬ ‫ﯾﻌﻨﻲ‬ ‫ھﺬا اﻟﺮﻣﺰ‬ !‫ﺗﺤﺬﯾﺮ‬ ‫اﻟﺪواﺋﺮ‬ ‫ﺑﺎﻟﻤﺨﺎطﺮ اﻟﻨﺎﺟﻤﺔ ﻋﻦ‬ ‫ﻦ ﻋﻠﻰ ﻋﻠﻢ‬ ، ‫ﻛ‬ ‫ﻣﻌﺪات‬ ‫ﺗﻌﻤﻞ ﻋﻠﻰ أي‬ ‫ﻗﺒﻞ أن‬ ‫اﻟﻜﮭﺮﺑﺎﺋﯿﺔ‬ ‫ﺣﻮادث‬ ‫أي‬ ‫وﻗﻮع‬ ‫ﻤﻨﻊ‬ ‫ﻟ‬ ‫اﻟﻮﻗﺎﺋﯿﺔ‬...

  • Page 34: Installation Instructions

    SUPERSERVER 1028R-WC1R(T) USER'S MANUAL Installation Instructions Warning! Read the installation instructions before connecting the system to the power source. 設置手順書 システムを電源に接続する前に、 設置手順書をお読み下さい。 警告 将此系统连接电源前,请先阅读安装说明。 警告 將系統與電源連接前，請先閱讀安裝說明。 Warnung Vor dem Anschließen des Systems an die Stromquelle die Installationsanweisungen lesen. ¡Advertencia! Lea las instrucciones de instalación antes de conectar el sistema a la red de alimentación.

  • Page 35: Circuit Breaker

    Chapter 4: Warning Statements for AC Systems Circuit Breaker Warning! This product relies on the building's installation for short-circuit (overcurrent) protection. Ensure that the protective device is rated not greater than: 250 V, 20 A. サーキッ ト ・ ブレーカー この製品は、 短絡 （過電流） 保護装置がある建物での設置を前提としています。 保護装置の定格が250 V、...

  • Page 36: Power Disconnection Warning

    SUPERSERVER 1028R-WC1R(T) USER'S MANUAL ‫ﻓﻲ‬ ‫اﻟﺘﻲ ﺗﻢ ﺗﺜﺒﯿﺘﮭﺎ‬ ‫ﻣﻦ اﻟﺪواﺋﺮاﻟﻘﺼﯿﺮة‬ ‫اﻟﺤﻤﺎﯾﺔ‬ ‫ﻣﻌﺪات‬ ‫ﯾﻌﺘﻤﺪ ﻋﻠﻰ‬ ‫ھﺬا اﻟﻤﻨﺘﺞ‬ ‫اﻟﻤﺒﻨﻰ‬ ‫أﻛﺜﺮ ﻣﻦ‬ ‫ﻟﯿﺲ‬ ‫ﻮﻗﺎﺋﻲ‬ ‫اﻟ‬ ‫اﻟﺠﮭﺎز‬ ‫ﺗﻘﯿﯿﻢ‬ ‫أن‬ ‫ﺗﺄﻛﺪ ﻣﻦ‬ 20A, 250V 경고! 이 제품은 전원의 단락(과전류)방지에 대해서 전적으로 건물의 관련 설비에 의존합니다. 보호장치의 정격이 반드시 250V(볼트), 20A(암페어)를 초과하지...
  • Page 37 Chapter 4: Warning Statements for AC Systems Warnung Das System muss von allen Quellen der Energie und vom Netzanschlusskabel getrennt sein, das von den Spg.Versorgungsteilmodulen entfernt wird, bevor es auf den Chassisinnenraum zurückgreift, um Systemsbestandteile anzubringen oder zu entfernen. ¡Advertencia! El sistema debe ser disconnected de todas las fuentes de energía y del cable eléctrico quitado de los módulos de fuente de alimentación antes de tener acceso el interior del chasis para instalar o para quitar componentes de sistema.

  • Page 38: Equipment Installation

    SUPERSERVER 1028R-WC1R(T) USER'S MANUAL Equipment Installation Warning! Only trained and qualifi ed personnel should be allowed to install, replace, or service this equipment. 機器の設置 トレーニングを受け認定された人だけがこの装置の設置、 交換、 またはサービスを許可 されています。 警告 只有经过培训且具有资格的人员才能进行此设备的安装、更换和维修。 警告 只有經過受訓且具資格人員才可安裝、更換與維修此設備。 Warnung Das Installieren, Ersetzen oder Bedienen dieser Ausrüstung sollte nur geschultem, qualifi...

  • Page 39: Restricted Area

    Chapter 4: Warning Statements for AC Systems Waarschuwing Deze apparatuur mag alleen worden geïnstalleerd, vervangen of hersteld door geschoold en gekwalifi ceerd personeel. Restricted Area Warning! This unit is intended for installation in restricted access areas. A restricted access area can be accessed only through the use of a special tool, lock and key, or other means of security.

  • Page 40: Battery Handling

    SUPERSERVER 1028R-WC1R(T) USER'S MANUAL ‫אזור עם גישה מוגבלת‬ !‫אזהרה‬ ‫יש להתקין את היחידה באזורים שיש בהם הגבלת גישה. הגישה ניתנת בעזרת‬ .('‫כלי אבטחה בלבד )מפתח, מנעול וכד‬ ‫ﻣﺤﻈﻮرة‬ ‫ﻣﻨﺎطﻖ‬ ‫ﻟﺘﺮﻛﯿﺒﮭﺎ ﻓﻲ‬ ‫ھﺬه اﻟﻮﺣﺪة‬ ‫ﺗﺨﺼﯿﺺ‬ ‫ﺗﻢ‬ ،‫أداة ﺧﺎﺻﺔ‬ ‫ﻣﻦ ﺧﻼل اﺳﺘﺨﺪام‬...
  • Page 41 Chapter 4: Warning Statements for AC Systems Warnung Bei Einsetzen einer falschen Batterie besteht Explosionsgefahr. Ersetzen Sie die Batterie nur durch den gleichen oder vom Hersteller empfohlenen Batterietyp. Entsorgen Sie die benutzten Batterien nach den Anweisungen des Herstellers. Attention Danger d'explosion si la pile n'est pas remplacée correctement. Ne la remplacer que par une pile de type semblable ou équivalent, recommandée par le fabricant.

  • Page 42: Redundant Power Supplies

    SUPERSERVER 1028R-WC1R(T) USER'S MANUAL Redundant Power Supplies Warning! This unit might have more than one power supply connection. All connections must be removed to de-energize the unit. 冗長電源装置 このユニッ トは複数の電源装置が接続されている場合があります。 ユニッ トの電源を切るためには、 すべての接続を取り外さなければなりません。 警告 此部件连接的电源可能不止一个，必须将所有电源断开才能停止给该部件供电。 警告 此裝置連接的電源可能不只一個，必須切斷所有電源才能停止對該裝置的供電。 Warnung Dieses Gerät kann mehr als eine Stromzufuhr haben. Um sicherzustellen, dass der Einheit kein trom zugeführt wird, müssen alle Verbindungen entfernt werden.

  • Page 43: Backplane Voltage

    Chapter 4: Warning Statements for AC Systems ‫اﻣﺪاد اﻟﻄﺎﻗﺔ‬ ‫ﺑﻮﺣﺪات‬ ‫ﻋﺪة اﺗﺼﺎﻻت‬ ‫ﺠﮭﺎز‬ ‫اﻟ‬ ‫ﯾﻜﻮن ﻟﮭﺬا‬ ‫ﻗﺪ‬ ‫اﻟﻜﮭﺮﺑﺎء‬ ‫ﻋﻦ‬ ‫ﻮﺣﺪة‬ ‫اﻟ‬ ‫ﻟﻌﺰل‬ ‫ﻛﺎﻓﺔ اﻻﺗﺼﺎﻻت‬ ‫ﯾﺠﺐ إزاﻟﺔ‬ 경고! 이 장치에는 한 개 이상의 전원 공급 단자가 연결되어 있을 수 있습니다. 이 장치에 전원을...

  • Page 44: Comply With Local And National Electrical Codes

    SUPERSERVER 1028R-WC1R(T) USER'S MANUAL Attention Lorsque le système est en fonctionnement, des tensions électriques circulent sur le fond de panier. Prendre des précautions lors de la maintenance. ‫מתח בפנל האחורי‬ !‫הרה‬ ‫אז‬ ‫קיימת סכנת מתח בפנל האחורי בזמן תפעול המערכת. יש להיזהר במהלך‬...

  • Page 45: Product Disposal

    Chapter 4: Warning Statements for AC Systems ¡Advertencia! La instalacion del equipo debe cumplir con las normas de electricidad locales y nacionales.Attention L'équipement doit être installé conformément aux normes électriques nationales et locales. ‫תיאום חוקי החשמל הארצי‬ !‫אזהרה‬ ‫הציוד חייבת להיות תואמת לחוקי החשמל המקומיים והארציים‬ ‫התקנת‬...

  • Page 46: Easy Swap Fan Warning

    SUPERSERVER 1028R-WC1R(T) USER'S MANUAL Warnung Die Entsorgung dieses Produkts sollte gemäß allen Bestimmungen und Gesetzen des Landes erfolgen. ¡Advertencia! Al deshacerse por completo de este producto debe seguir todas las leyes y reglamentos nacionales. Attention La mise au rebut ou le recyclage de ce produit sont généralement soumis à des lois et/ou directives de respect de l'environnement.
  • Page 47 Chapter 4: Warning Statements for AC Systems 当您从机架移除风扇装置，风扇可能仍在转动。小心不要将手指、螺丝起子和其他 物品太靠近风扇 警告 當您從機架移除風扇裝置，風扇可能仍在轉動。小心不要將手指、螺絲起子和其他 物品太靠近風扇。 Warnung Die Lüfter drehen sich u. U. noch, wenn die Lüfterbaugruppe aus dem Chassis genommen wird. Halten Sie Finger, Schraubendreher und andere Gegenstände von den Öffnungen des Lüftergehäuses entfernt. ¡Advertencia! Los ventiladores podran dar vuelta cuando usted quite ell montaje del ventilador del chasis.

  • Page 48: Power Cable And Ac Adapter

    fi re. Electrical Appliance and Material Safety Law prohibits the use of UL or CSA -certifi ed cables (that have UL/CSA shown on the code) for any other electrical devices than products designated by Supermicro only. 電源コードとACアダプター...
  • Page 49 Appareils électroménagers et de loi sur la sécurité Matériel interdit l'utilisation de UL ou CSA câbles certifi és qui ont UL ou CSA indiqué sur le code pour tous les autres appareils électriques que les produits désignés par Supermicro seulement.
  • Page 50 Elektrisch apparaat en veiligheidsinformatiebladen wet verbiedt het gebruik van UL of CSA gecertifi ceerde kabels die UL of CSA die op de code voor andere elektrische apparaten dan de producten die door Supermicro alleen.

  • Page 51: Chapter 5 Advanced Serverboard Setup

    Chapter 5: Advanced Serverboard Setup Chapter 5 Advanced Serverboard Setup This chapter covers the steps required to connect the data and power cables and install add-on cards. All serverboard jumpers and connections are also described. A layout and quick reference chart are included in this chapter for your reference. Remember to completely close the chassis when you have fi...

  • Page 52: Connecting Cables

    SUPERSERVER 1028R-WC1R(T) USER'S MANUAL Connecting Cables Now that the serverboard is installed, the next step is to connect the cables to the board. These include the data cables for the peripherals and control panel and the power cables. Connecting Data Cables The cables used to transfer data from the peripheral devices have been carefully routed to prevent them from blocking the fl...

  • Page 53: Mezzanine Card Installation

    Chapter 5: Advanced Serverboard Setup Mezzanine Card Installation For SAS 3.0 support, be sure to follow the instructions below to install the mezzanine card on the AOM PCI-E 3.0 slot located at J35. Image of the Mezzanine Card 1. After installing the motherboard in the chassis, align the mezzanine card with the AOM PCI-E 3.0 slot (J35) on the motherboard.
  • Page 54 SUPERSERVER 1028R-WC1R(T) USER'S MANUAL 3. With the mezzanine card securely placed in the slot, insert Pan Head #6 screws into the three standoff holes and tighten them with a Phillips screwdriver. Screw #2 Screw #1 Screw #3...

  • Page 55: Connecting The Control Panel

    Chapter 5: Advanced Serverboard Setup Connecting the Control Panel JF1 contains header pins for various front control panel connectors. See Figure 5-1 for the pin locations of the various front control panel buttons and LED indicators. All JF1 wires have been bundled into a single cable to simplify this connection. Make sure the red wire plugs into pin 1 as marked on the board.

  • Page 56: Rear I/O Ports

    SUPERSERVER 1028R-WC1R(T) USER'S MANUAL Rear I/O Ports The I/O ports are in conformance with the PC 99 specifi cation. See Figure 5-2 below for the locations of the various I/O ports. Figure 5-2. Rear I/O Ports Rear I/O Ports VGA Port USB 3.0 Port 0 USB 3.0 Port 1 IPMI Dedicated LAN Port...

  • Page 57: Installing The Processor And Heatsink

    CPU socket cap is in place and none of the socket pins are bent; otherwise, contact your retailer immediately. • Refer to the Supermicro web site for updates on CPU support. Installing an LGA 2011 Processor Press down on the lever labeled 'Close 1st' 1.
  • Page 58 SUPERSERVER 1028R-WC1R(T) USER'S MANUAL 3. With the lever labeled 'Close 1st' fully retracted, gently push down on the 'Open 1st' lever to open the load plate. Lift the load plate to open it completely. Gently push down to pop the load plate open.
  • Page 59 Chapter 5: Advanced Serverboard Setup Caution: You can only install the CPU to the socket in one direction. Make sure that the CPU is properly inserted into the socket before closing the load plate. If it doesn't close properly, do not force it as it may damage your CPU. Instead, open the load plate again and double-check that the CPU is aligned properly.

  • Page 60: Installing And Removing A Passive Cpu Heatsink

    SUPERSERVER 1028R-WC1R(T) USER'S MANUAL Installing and Removing a Passive CPU Heatsink 1. Do not apply any thermal grease to the heatsink or the CPU die; the required amount has already been applied. 2. Install the 1U passive CPU heatsink (SNK-P0047PSC or SNK-P0057PSC) at the CPU1 location with the air tunnel facing to the right (looking from the front).

  • Page 61: Installing Memory

    Chapter 5: Advanced Serverboard Setup Installing Memory Caution! Exercise extreme care when installing or removing DIMM modules to prevent any possible damage. Memory Support The X10DRW-i(T) supports up to 2048 GB of ECC registered (RDIMM) or ECC Load Reduced (LRDIMM) DDR4 2400/2133/1866/1600 MHz speed, 1 GB, 2 GB, 4 GB, 8 GB, 16 GB, 32 GB, 64 GB and 128 GB size @ 1.2V voltage SDRAM in sixteen (16) DIMM sockets.
  • Page 62 SUPERSERVER 1028R-WC1R(T) USER'S MANUAL DIMM Module Population Table Follow the tables below when installing memory. Processors and their Corresponding Memory Modules CPU# Corresponding DIMM Modules CPU 1 DIMMA1 DIMMB1 DIMMC1 DIMMD1 DIMMA2 DIMMB2 DIMMC2 DIMMD2 CPU2 DIMME1 DIMMF1 DIMMG1 DIMMH1 DIMME2 DIMM F2 DIMMG2...
  • Page 63 Chapter 5: Advanced Serverboard Setup Populating RDIMM/LRDIMM Memory Modules Populating RDIMM/LRDIMM DDR4 Memory Modules Speed (MT/s); Voltage (V); Slots per Channel (SPC) and DIMMs per Channel (DPC) Ranks DIMM 2 Slots per Channel Capacity DIMM Type 1 DPC 2 DPC (GB) Data E5-2600...

  • Page 64: Serverboard Details

    SUPERSERVER 1028R-WC1R(T) USER'S MANUAL Serverboard Details Figure 5-5. X10DRW-i(T) Layout LAN1 USB2/3(3.0)USB0/1(3.0) LAN2 UID-SW CTRL IPMI_LAN X10DRW-i(T) Rev. 1.01 CPU2 CLOSE 1st OPEN 1st BIOS LICENSE CPU1 IPMI CLOSE 1st Flash BIOS OPEN 1st I-SGPIO2 I-SGPIO1 JBT1 LED2 JPME2 JVR1 JSTBY1 Caution: 1) To avoid damaging the motherboard and its components, please do not use a force greater than 8 lb/inch on each mounting screw during motherboard...
  • Page 65 Chapter 5: Advanced Serverboard Setup X10DRW-i(T) Jumpers Jumper Description Default Setting JBT1 Clear CMOS See Section 5-9 later in this chapter C1/JI SMB to PCI-E slots Pins 2-3 (Disabled) JPB1 BMC Enable Pins 1-2 (Enabled) JPG1 VGA Enable Pins 1-2 (Enabled) GLAN1/GLAN2 Enable (X10DRW-i) JPL1 Pins 1-2 (Enabled)
  • Page 66 SMC-proprietary riser card (e.g. RSC-R1UW-2E16) in the slot Note 2: For SXB2 (CPU2 PCI-E 3.0X16) slot to work properly, please use the SMC- proprietary riser card (PN: RSC-R2UW-2E8R). Note 3: For the latest CPU/memory updates, please refer to our website at www. supermicro.com. 5-16...

  • Page 67: Connector Defi Nitions

    Chapter 5: Advanced Serverboard Setup Connector Defi nitions Power Connectors ATX Power 24-pin Connector Pin Defi nitions (JPWR1) A 24-pin main power supply connector Pin# Defi nition Pin # Defi nition (JPWR1), and two 8-pin CPU power +3.3V +3.3V connectors (JPWR2/JPWR3) are located on the serverboard.
  • Page 68 SUPERSERVER 1028R-WC1R(T) USER'S MANUAL Reset Button Reset Button Pin Defi nitions (JF1) The Reset Button connection is located Pin# Defi nition on pins 3 and 4 of JF1. Attach it to a Reset hardware reset switch on the computer Ground case.
  • Page 69 Chapter 5: Advanced Serverboard Setup Power LED Power LED Pin Defi nitions (JF1) The Power LED connection is located Pin# Defi nition on pins 15 and 16 of JF1. Refer to the 3.3V table on the right for pin defi nitions. PWR LED NMI Button NMI Button...
  • Page 70 SUPERSERVER 1028R-WC1R(T) USER'S MANUAL Universal Serial Bus (USB) BP USB (3.0) 0/1, 2/3 Pin Defi nitions Four USB 3.0 ports (USB 0/1, USB Pin# Description 2/3) are located on the I/O backpanel. VBUS In addition, an internal USB header, SSRX- located next to S-SATA0, also provides two USB 3.0 connections (USB 4/5) for SSRX+...
  • Page 71 Note: UID can also be triggered via IPMI on the serverboard. For more information on IPMI, please refer to the IPMI User's Guide posted on our website @ http://www.supermicro. com. Internal Speaker Internal Buzzer Pin Defi nition The Internal Speaker (SP1) provides Pin# Defi...
  • Page 72 SUPERSERVER 1028R-WC1R(T) USER'S MANUAL Power SMB (I C) Connector PWR SMB Pin Defi nitions Power System Management Bus (I Pin# Defi nition connector (JPI C1) monitors power Clock supply, fan and system temperatures. Data See the table on the right for pin defi...

  • Page 73: Jumper Settings

    Chapter 5: Advanced Serverboard Setup Jumper Settings Connector Pins Explanation of Jumpers To modify the operation of the Jumper serverboard, jumpers can be used to choose between optional settings. Jumpers create shorts between two Setting pins to change the function of the connector.
  • Page 74 SUPERSERVER 1028R-WC1R(T) USER'S MANUAL LAN Enable/Disable LAN Enable/Disable Jumper Settings (JPL1) JPL1 enables or disables Gigabit_ Jumper Setting Defi nition LAN ports 1/2 on the X10DRW-i, and Pins 1-2 Enabled (default) 10G_LAN ports 1/2 on the X10DRW- Pins 2-3 Disabled iT.
  • Page 75 Chapter 5: Advanced Serverboard Setup C Bus to PCI-E Slots C to PCI-E Jumper Setting Use Jumpers JI C1 and JI C2 to Jumper Setting Defi nition connect the System Management Bus Pins 1-2 Enabled C) to PCI-Express slots to improve PCI performance.

  • Page 76: 5-10 Onboard Led Indicators

    SUPERSERVER 1028R-WC1R(T) USER'S MANUAL 5-10 Onboard LED Indicators GLAN LEDs GLAN LED Link Speed Activity The LAN ports are located on the IO Backplane on the serverboard. Each Ethernet LAN port has two LEDs. The GLAN Activity Indicator yellow LED indicates activity. Link LED, (Right) LED Settings located on the left side of the LAN port, Color...

  • Page 77: 5-11 Sata Connections

    Parallel ATA. SATA_RXP See the table on the right for pin Ground defi nitions. Note: For more information on SATA HostRAID confi guration, please refer to the Intel SATA HostRAID User's Guide posted on our website @ ftp://ftp.supermicro. com.. 5-27...

  • Page 78: 5-12 Installing Software

    SUPERSERVER 1028R-WC1R(T) USER'S MANUAL 5-12 Installing Software The Supermicro ftp site contains drivers and utilities for your system at ftp://ftp. supermicro.com. Some of these must be installed, such as the chipset driver. After accessing the ftp site, go into the CDR_Images directory and locate the ISO fi...

  • Page 79: Superdoctor 5

    CD on it allows you to view the entire contents. SuperDoctor 5 ® The Supermicro SuperDoctor 5 is a hardware and operating system services monitoring program that functions in a command-line or web-based interface in Windows and Linux operating systems. The program monitors system health...
  • Page 80 Figure 5-8. SuperDoctor 5 Interface Display Screen (Remote Control) Note: The SuperDoctor 5 program and User’s Manual can be downloaded from the Supermicro web site at http://www.supermicro.com/products/nfo/sms_sd5.cfm. For Linux, we recommend that you use the SuperDoctor II application instead. 5-30...

  • Page 81: 5-13 Serverboard Battery

    Chapter 5: Advanced Serverboard Setup 5-13 Serverboard Battery Caution: There is a danger of explosion if the onboard battery is installed upside down, which will reverse its polarities (see Figure 5-9). This battery must be replaced only with the same or an equivalent type recommended by the manufacturer (CR2032).
  • Page 82 SUPERSERVER 1028R-WC1R(T) USER'S MANUAL Notes 5-32...

  • Page 83: Chapter 6 Advanced Chassis Setup

    Chapter 6: Advanced Chassis Setup Chapter 6 Advanced Chassis Setup This chapter covers the steps required to install components and perform maintenance on the SC116AC-R706WBP chassis. For component installation, follow the steps in the order given to eliminate the most common problems encountered.

  • Page 84: Control Panel

    SUPERSERVER 1027R-73DBRF User's Manual Figure 6-1. Front and Rear Chassis Views Control Panel Hot-Swap Drive Bays (10) Power Supplies PCI Expansion Slot (w/ Riser Card) Rear I/O Ports (see Section 5-3) Control Panel The control panel (located on the front of the chassis) must be connected to the JF1 connector on the serverboard to provide you with system status indications.
  • Page 85 Chapter 6: Advanced Chassis Setup The SC116 chassis includes four pre-installed fans. One additional open slot is available so that one more fan may be added if additional cooling is required. twenty-four (24) per system. These fans are NOT redundant, hot-plug and must be replaced when they fail.

  • Page 86: Checking The Airfl Ow

    SUPERSERVER 1027R-73DBRF User's Manual Checking the Airfl ow Check the Airfl ow 1. Make sure there are no objects obstructing the airfl ow in and out of the server. In addition, if you are using a front bezel, make sure the bezel's fi lter is replaced periodically.
  • Page 87 2. Swing the handle fully out and use it to pull the unit straight out. Note: Your operating system must have RAID support to enable the hot-plug capability of the hard drives. Note: Refer to the following FTP site for RAID setup guidelines: <ftp://ftp.supermicro. com/driver/SAS/LSI/LSI_SAS_EmbMRAID_SWUG.pdf> and Supermicro’s web site for additional information < http://www.supermicro.com/support/manuals/>.
  • Page 88 Caution: Regardless of how many hard drives are installed, all drive carriers must remain in the drive bays to maintain proper airfl ow. Warning: Enterprise level hard disk drives are recommended for use in Supermicro chassis and servers. For information on recommended HDDs, visit the Supermicro Web site at http://www.supermicro.com/products/nfo/fi les/...

  • Page 89: Power Supply

    The SC116 chassis includes a redundant power supply, which allows the server to continue running when one power supply has been removed. Replacement units can be ordered directly from Supermicro. Replacing the Power Supply (Figure 6-5) 1. Unplug the AC power cord from the failed power supply module (with the RED LED lit up).
  • Page 90 SUPERSERVER 1027R-73DBRF User's Manual Notes...

  • Page 91: Chapter 7 Bios

    Chapter 7: BIOS Chapter 7 BIOS Introduction This chapter describes the AMI BIOS Setup utility for the X10DRW-i(T) It also provides the instructions on how to navigate the AMI BIOS Setup utility screens. The AMI ROM BIOS is stored in a Flash EEPROM and can be easily updated. Starting BIOS Setup Utility To enter the AMI BIOS Setup utility screens, press the <Del>...

  • Page 92: How To Change The Confi Guration Data

    <Delete> at the appropriate time during system boot. Note: For AMI UEFI BIOS Recovery, please refer to the UEFI BIOS Recovery User Guide posted @http://www.supermicro.com/support/manuals/. Starting the Setup Utility Normally, the only visible Power-On Self-Test (POST) routine is the memory test.

  • Page 93: Advanced Setup Confi Gurations

    Chapter 7: BIOS Memory Information Total Memory This displays the amount of memory that is available in the system. Advanced Setup Confi gurations Use the arrow keys to select Advanced and press <Enter> to access the following submenu items: Boot Feature Quiet Boot Use this feature to select the bootup screen display between POST messages or the OEM logo.
  • Page 94 SUPERSERVER 1028R-WC1R(T) USER'S MANUAL Bootup Num-Lock Use this feature to set the Power-on state for the Numlock key. The options are Off and On. Wait For 'F1' If Error If this feature is set to Enabled, the system will wait until the 'F1' key is pressed when an error occurs.
  • Page 95 Chapter 7: BIOS CPU Confi guration This submenu displays the information of the CPU as detected by the BIOS. It also allows the user to confi gure the CPU settings. Socket 1 CPU Information/Socket 2 CPU Information This submenu displays the following information regarding the CPU installed in Socket 1 or Socket 2.
  • Page 96 SUPERSERVER 1028R-WC1R(T) USER'S MANUAL RTID (Record Types IDs) This feature displays the total number of Record Type IDs for local and remote pools. The options are Optimal and Alternate. Hyper-threading Select Enabled to support Intel Hyper-threading Technology to enhance CPU performance.
  • Page 97 Chapter 7: BIOS DCU Streamer Prefetcher (Available when supported by the CPU) Select Enabled to support Data Cache Unite (DCU) prefetch to speed up data accessing and processing in the DCU to enhance CPU performance. The options are Disabled and Enabled. DCU IP Prefetcher Select Enabled for DCU (Data Cache Unit) IP Prefetcher support, which will prefetch IP addresses to enhance network connectivity and system performance.
  • Page 98 SUPERSERVER 1028R-WC1R(T) USER'S MANUAL C1E Support (Available when Power Technology is set to Custom) Select Enabled to enable Enhanced C1 Power State to boost system performance. The options are Enabled and Disabled. CPU C3 Report (Available when Power Technology is set to Custom) Select Enabled to allow the BIOS to report the CPU C3 State (ACPI C2) to the operating system.
  • Page 99 Chapter 7: BIOS Long Duration Maintained This item displays the period of time (in seconds) during which long duration power is maintained. The default setting is 0. Recommended Short Duration Power Limit This item displays the short duration power settings (in watts) recommended by the manufacturer.
  • Page 100 SUPERSERVER 1028R-WC1R(T) USER'S MANUAL ® Intel I/OAT Select Enabled to enable Intel I/OAT (I/O Acceleration Technology), which will significantly reduce CPU overhead by leveraging CPU architectural improvements and freeing the system resource up for other tasks. The options are Disabled and Enabled. DCA Support Select Enabled to use Intel's DCA (Direct Cache Access) Technology to improve data transfer effi...
  • Page 101 Chapter 7: BIOS QPI (Quick Path Interconnect) Link Speed Mode Use this feature to select data transfer speed for QPI Link connections. The options are Fast and Slow. QPI Link Frequency Select Use this feature to select the desired QPI frequency. The options are Auto, 6.4 GT/s, 7.2 GT/s, and 8.0 GT/s.
  • Page 102 SUPERSERVER 1028R-WC1R(T) USER'S MANUAL Channel Interleaving This feature selects from the different channel interleaving methods. The options are Auto, 1 Way, 2 Way, 3, Way, and 4 Way. Rank Interleaving This feature allows the user to select a rank memory interleaving method. The options are Auto, 1 Way, 2 Way, 4, Way, and 8 Way.
  • Page 103 Chapter 7: BIOS South Bridge This feature allows the user to confi gure the settings for the Intel PCH chip. PCH Information This feature displays the following PCH information. Name: This item displays the name of the PCH chip. Stepping: This item displays the PCH stepping. USB Devices: This item displays the USB devices detected by the BIOS.
  • Page 104 SUPERSERVER 1028R-WC1R(T) USER'S MANUAL SATA Confi guration When this submenu is selected, the AMI BIOS automatically detects the presence of IDE or SATA devices and displays the following items. SATA Port0~SATA Port5: The AMI BIOS displays the status of each SATA port as detected by the BIOS.
  • Page 105 Chapter 7: BIOS SATA RAID Option ROM/UEFI Driver Select Enabled to boot the system from a SATA RAID device or a UEFI (Unifi ed Extensible Firmware Interface) device. The options are Enabled or Disabled. Port 0~5 Hot Plug Select Enabled to enable hot-plug support for a port specifi ed by the user. The options are Enabled and Disabled.
  • Page 106 SUPERSERVER 1028R-WC1R(T) USER'S MANUAL ASPM Support This feature allows the user to set the Active State Power Management (ASPM) level for a PCI-E device. Select Auto to allow the system BIOS to automatically set the ASPM level for the system. Select Disabled to disable ASPM support. The options are Disabled and Auto.
  • Page 107 Chapter 7: BIOS  Super IO Confi guration Super IO Chip Displays the Super IO chip type. COM 1 Confi guration Serial Port Select Enabled to enable a serial port specifi ed by the user. The options are Enabled and Disabled. Device Settings This item displays the settings of Serial Port 1.
  • Page 108 SUPERSERVER 1028R-WC1R(T) USER'S MANUAL SOL (Serial_Over_LAN) Device Mode Use this feature to select the desired mode for the SOL port. The options are Normal and High Speed. Serial Port 2 Attribute Use this feature to select the attribute for serial port 2. The options are SOL (Serial_On_LAN), and COM.
  • Page 109 Chapter 7: BIOS Data Bits Use this feature to set the data transmission size for Console Redirection. The options are 7 and 8 (Bits). Parity A parity bit can be sent along with regular data bits to detect data transmission errors.
  • Page 110 SUPERSERVER 1028R-WC1R(T) USER'S MANUAL Putty Keypad Use this feature to select function key and keypad setting on Putty. The options are VT100, LINUX, XTERMR6, SCO, ESCN, and VT400. Redirection After BIOS POST If Always Enabled is selected, Legacy Console Redirection will be enabled for Legacy OS after BIOS POST (Power-On Self Test) is completed.
  • Page 111 Chapter 7: BIOS Flow Control This feature allows the user to set the fl ow control for Console Redirection to prevent data loss caused by buffer overfl ow. Send a "Stop" signal to stop sending data when the receiving buffer is full. Send a "Start" signal to start sending data when the receiving buffer is empty.
  • Page 112 SUPERSERVER 1028R-WC1R(T) USER'S MANUAL High Precision Event Timer Select Enabled to activate the High Precision Event Timer (HPET) that produces periodic interrupts at a much higher frequency than a Real-time Clock (RTC) does in synchronizing multimedia streams, providing smooth playback, reducing the dependency on other timestamp calculation devices, such as an x86 RDTSC Instruction embedded in the CPU.

  • Page 113: Event Logs

    Chapter 7: BIOS  Intel TXT(LT-SX) Confi guration This feature indicates if the following hardware components support the Intel TXT (Trusted Execution Technology), which helps protect against software-based attacks and ensures protection, confi dentiality and integrity of data stored or created on the system.
  • Page 114 SUPERSERVER 1028R-WC1R(T) USER'S MANUAL Runtime Error Logging Support Change this item to enable or disable runtime error logging. The options are Enabled and Disabled. Memory Correction Error Threshold Change this item to defi ne the system's memory correction error threshold. Directly enter a numeric value.

  • Page 115: Ipmi

    Chapter 7: BIOS IPMI Use this menu to confi gure Intelligent Platform Management Interface (IPMI) settings. System Event Log Enabling/Disabling Options SEL Components Select Enabled for all system event logging at bootup. The options are Enabled and Disabled. Erasing Settings Erase SEL Select 'Yes, On next reset' to erase all system event logs upon next system reboot.
  • Page 116 SUPERSERVER 1028R-WC1R(T) USER'S MANUAL When SEL is Full This feature allows the user to decide what the BIOS should do when the system event log is full. Select Erase Immediately to erase all events in the log when the system event log is full. The options are Do Nothing and Erase Immediately. BMC Network Confi...

  • Page 117: Boot

    Chapter 7: BIOS Boot This menu allows the user to confi gure the following boot settings for the system. Set Boot Priorities 1st Boot Device/2nd Boot Device/3rd Boot Device/4th Boot Device/5th Boot Device/6th Boot Device Use this feature to specify the sequence of boot priority for a device specifi ed by the user.
  • Page 118 SUPERSERVER 1028R-WC1R(T) USER'S MANUAL  USB Hard Disk Drive BBS Priorities This submenu allows the user to specify the boot priority sequence of a USB hard drive. 1st Device  Network Device BBS Priorities This submenu allows the user to specify the boot priority sequence of a network device.
  • Page 119 Chapter 7: BIOS Password Check This item allows you to decide when the system should check for a password after it has been entered. Select Setup for the system to prompt for a password before the user enters the BIOS Setup utility. Select Always for the system to prompt for a password upon each system boot and before the user enters the Setup utility.
  • Page 120 SUPERSERVER 1028R-WC1R(T) USER'S MANUAL Save Changes and Reset When you have completed the system confi guration changes, select this option to save the changes and reboot the computer so that the new system confi guration settings can take effect. Select Save Changes and Exit, and press <Enter>. When the dialog box appears, asking you if you want to exit the BIOS setup without saving, select Yes to quit BIOS without saving the changes, or select No to quit the BIOS and save changes.
  • Page 121 Chapter 7: BIOS Boot Override This feature allows the user to override the Boot Option Priorities setting in the Boot menu, and instead immediately boot the system with one of the listed devices. This is a one-time override. 7-31...
  • Page 122 SUPERSERVER 1028R-WC1R(T) USER'S MANUAL Notes 7-32...
  • Page 123 Appendix A: BIOS Error Beep Codes Appendix A BIOS Error Beep Codes During the POST (Power-On Self-Test) routines, which are performed each time the system is powered on, errors may occur. Non-fatal errors are those which, in most cases, allow the system to continue the boot-up process.
  • Page 124 SUPERSERVER 1028R-WC1R(T) USER'S MANUAL Notes...
  • Page 125 Appendix B: System Specifi cations Appendix B System Specifi cations Processors Single or dual Intel® Xeon E5-2600 v3/v4 Series processors Note: If only a single processor is populated, then slot SXB1B (PCIe x16) and SXB2 (PCIe x16) will NOT be functional. Note: Please refer to our web site for a complete listing of supported processors.
  • Page 126 UPER ERVER 1027R-73DBRF User's Manual Weight 44 lbs. (20 kg.) System Cooling Five 4-cm counter-rotating fans Note: The system cooling fans are NOT redundant, hot-plug. Power Supply Input Requirements AC Input Voltage: 100V - 240V AC auto-range Rated Input Current: 700W 100-140Vac: 8-6A, 50-60Hz 750W 200-240Vac: 4.3-3.8A, 50-60Hz Power Supply Output...
  • Page 127 Appendix B: System Specifi cations Notes...
  • Page 128 ERVER 1027R-73DBRF User's Manual (continued from front) The products sold by Supermicro are not intended for and will not be used in life support systems, medical equipment, nuclear facilities or systems, aircraft, aircraft devices, aircraft/emergency com- munication devices or other critical systems whose failure to perform be reasonably expected to result in signifi...

This manual is also suitable for:

Superserver 1028r-wc1rt

Table of Contents
