SUPERSERVER
1028TR-T
1028TR-TF
USER'S MANUAL
Revision 1.0

Advertisement

Table of Contents
loading

Related Manuals for Supermicro SUPERSERVER 1028TR-T

Summary of Contents for Supermicro SUPERSERVER 1028TR-T

  • Page 1 Проконсультироваться и купить данное оборудование вы можете в компании «АНД-Системс» адрес: 125480, г.Москва, ул.Туристская, д.33/1; site: https://andpro.ru тел: +7 (495) 545-4870 email: info@andpro.ru При обращении используйте промокод AND-PDF и получите скидку. ® SUPERSERVER 1028TR-T 1028TR-TF USER’S MANUAL Revision 1.0...
  • Page 2 This product, including software and documentation, is the property of Supermicro and/or its licensors, and is supplied only under a license. Any use or reproduction of this product is not allowed, except as expressly permitted by the terms of said license.

  • Page 3: About This Manual

    IPMI LAN port and two serverboard nodes with four hot-swap 2.5" SATA3 Hard Disk Drives (HDD) each per node. Each of the various models of the SuperServer 1028TR-T/TF servers and their associated serverboards for each of their unique options are listed in the table below:...
  • Page 4 SUPERSERVER 1028TR-T/TF User's Manual Chapter 4: System Safety You should thoroughly familiarize yourself with this chapter for a general overview of safety precautions that should be followed when installing and servicing the SUPERSERVER 1028TR-T/TF. Chapter 5: Advanced Serverboard Setup Chapter 5 provides detailed information on the X10DRT-L/LIBF serverboard, including the locations and functions of connections, headers and jumpers.
  • Page 5 SUPERSERVER 1028TR-T/TF User's Manual Notes...

  • Page 6: Table Of Contents

    SUPERSERVER 1028TR-T/TF User's Manual Table of Contents Chapter 1 Introduction Overview ......................1-1 Serverboard Features ..................1-2 Processors ...................... 1-2 Memory ......................1-2 Serial ATA ....................... 1-2 PCI Expansion Slots ..................1-2 Onboard Controllers/Ports ................1-3 Graphics Controller ..................1-3 Infi...
  • Page 7 Table of Contents Rack Mounting Considerations ............... 2-3 Ambient Operating Temperature ..............2-3 Reduced Airfl ow ..................2-3 Mechanical Loading ................... 2-3 Circuit Overloading ..................2-3 Reliable Ground ..................2-3 Rack Mounting Instructions ................2-4 Identifying the Sections of the Rack Rails ............2-5 Installing the Inner Rail Extensions ..............
  • Page 8 SUPERSERVER 1028TR-T/TF User's Manual Chapter 5 Advanced Motherboard Setup Handling the Motherboard ................5-1 Precautions ..................... 5-1 Unpacking ....................... 5-1 Connecting Cables ..................5-2 Connecting Data Cables ................. 5-2 Control Panel Connectors and I/O Ports ............5-2 Connecting the Control Panel ................. 5-3 Processor and Heatsink Installation..............
  • Page 9 Table of Contents Motherboard Installation .................. 6-9 I/O Shield ......................6-9 Permanent and Optional Standoffs ..............6-9 Installing the Motherboards ................6-9 Expansion Slot Setup ..................6-11 Power Supply ....................6-12 Power Supply Replacement ................6-12 Chapter 7 BIOS Introduction ...................... 7-1 Starting BIOS Setup Utility ................
  • Page 10 SUPERSERVER 1028TR-T/TF User's Manual Notes...

  • Page 11: Chapter 1 Introduction

    Chapter 1 Introduction Overview The SuperServer 1028TR-T/TF is a high-end server comprised of two main subsystems: the SC809TS-1K03BP 1U server chassis and the X10DRT-L/LIBF dual processor serverboard in two hot-swap nodes. Please refer to our web site for information on operating systems that have been certifi ed for use with the system (www.supermicro.com).

  • Page 12: Serverboard Features

    RAID function of the SATA drives. Note: S-SATA2/S-SATA3: can be used as Supermicro SuperDOM (Disk-on-Module) with built-in power connectors. PCI Expansion Slots The SuperServer 1028TR-T/TF has for each node One (1) PCI-Express 3.0 x16 slot available for use with a riser card.

  • Page 13: Onboard Controllers/Ports

    IO back panel. Note: For IPMI Confi guration Instructions, please refer to the Embedded BMC Configuration User's Guide available @ http://www.supermicro.com/support/ manuals/. Graphics Controller The X10DRT-L/LIBF features an integrated ASpeed 2400 BMC Video Controller.

  • Page 14: Sata Subsystem

    SUPERSERVER 1028TR-T/TF User's Manual SATA Subsystem The SC809 supports two nodes with up to four (4) 2.5" hot-swap SATA drives in trays for each node for a total of eight drives. These drives are hot-swappable units and are connected to a backplane that provides power and control. Hard drives must be purchased separately.

  • Page 15: Mounting Rails

    Chapter 1: Introduction Mounting Rails The SC809 includes a set of rails, and can be placed in a rack for secure storage and use. To setup your rack, follow the step-by-step instructions included in this manual. Advanced Power Management Intel® Intelligent Power Node Manager (NM) The Intel®...

  • Page 16: System Block Diagram

    SUPERSERVER 1028TR-T/TF User's Manual Figure 1-1. AMD C612 Chipset: System Block Diagram X10DRT-L/LIBQ/LIBF Rev. 1.00 VR12.5 VR12.5 #2-4 #1-4 5 PHASE 5 PHASE #2-3 #1-3 145W 145W #2-2 #1-2 #2-1 #1-1 CPU2 CPU1 9.6G SNB CORE SNB CORE DDR4 DDR4...

  • Page 17: Contacting Supermicro

    Super Micro Computer, Inc. 980 Rock Ave. San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) support@supermicro.com (Technical Support) Website: www.supermicro.com Europe Address: Super Micro Computer B.V. Het Sterrenbeeld 28, 5215 ML...

  • Page 18: Twin 2 : System Notes

    SATA Backplane/Drives As a system, the SuperServer 1028TR-T/TF supports the use of eight 2.5" SATA drives. A single SATA backplane works to apply system-based control for power and fan speed functions, yet at the same time logically connects a set of four SATA drives to each serverboard.

  • Page 19: Chapter 2 Server Installation

    Unpacking the System You should inspect the box the SuperServer 1028TR-T/TF was shipped in and note if it was damaged in any way. If the server itself shows damage you should fi le a damage claim with the carrier who delivered it.

  • Page 20: Warnings And Cautions

    SUPERSERVER 1028TR-T/TF User's Manual Warnings and Cautions! Choosing a Setup Location • Leave enough clearance in front of the rack to enable you to open the front door completely (~25 inches) and approximately 30 inches of clearance in the back of the rack to allow for suffi...

  • Page 21: Rack Mounting Considerations

    Chapter 2: Server Installation Rack Mounting Considerations Ambient Operating Temperature If installed in a closed or multi-unit rack assembly, the ambient operating temperature of the rack environment may be greater than the ambient temperature of the room. Therefore, consideration should be given to installing the equipment in an environment compatible with the manufacturer’s maximum rated ambient temperature (Tmra).

  • Page 22: Rack Mounting Instructions

    SUPERSERVER 1028TR-T/TF User's Manual Warning! To prevent bodily injury when mounting or servicing this unit in a rack, you must take special precautions to ensure that the system remains stable. The following guidelines are provided to ensure your safety: •...

  • Page 23: Identifying The Sections Of The Rack Rails

    Chapter 2: Server Installation Identifying the Sections of the Rack Rails The chassis package includes two rack rail assemblies in the rack mounting kit. Each assembly consists of two sections: an inner fi xed chassis rail that secures directly to the server chassis and an outer fi...

  • Page 24: Installing The Inner Rail Extensions

    SUPERSERVER 1028TR-T/TF User's Manual Installing the Inner Rail Extensions The chassis includes a set of inner rack rails in two sections: inner rails (A) and inner rail extensions (B). The inner rails are preattached and do not interfere with normal use of the chassis if you decide not to use a server rack. Attach the inner rail extensions to to the inner rails, to stabilize the chassis within the rack.

  • Page 25: Installing The Outer Rails

    Chapter 2: Server Installation Installing the Outer Rails Installing the Outer Rails to the Rack 1. Attach the short bracket to the outside of the long bracket. You must align the pins with the slides. Also, both bracket ends must face the same direction. 2.

  • Page 26: Installing The Chassis Into A Rack

    SUPERSERVER 1028TR-T/TF User's Manual Installing the Chassis into a Rack Rack Installation 1. Confi rm that chassis includes the inner rails (A) and rail extensions (B). Also, confi rm that the outer rails (C) are installed on the rack. 2. Align the chassis rails extentions (B), with the front of the rack rails (C).

  • Page 27: Checking The Serverboard Setup

    Chapter 2: Server Installation Checking the Serverboard Setup After you install the SuperServer 1028TR-T/TF in the rack, you will need to open the unit to make sure the serverboard is properly installed and all the connections have been made. Accessing the inside of the System Before operating the server for the fi...

  • Page 28: Checking The Drive Bay Setup

    Each processor needs its own heat sink. See Chapter 5 for instructions on processor and heat sink installation. 2. Your SuperServer 1028TR-T/TF server system may have come with system memory already installed. Make sure all DIMMs are fully seated in their slots.

  • Page 29: Chapter 3 System Interface

    Chapter 3: System Interface Chapter 3 System Interface Overview There are several LEDs on the control panel and on the drive carriers to keep you constantly informed of the overall status of the system. SC809 models include four front panels on the handles of the chassis which control each of the systems. This chapter explains the meanings of all LED indicators and the appropriate response you may need to take.

  • Page 30: Control Panel Buttons

    SUPERSERVER 1028TR-T/TF User's Manual Control Panel Buttons The chassis includes two push-buttons that control power to the system. Reset: The reset button is used to reboot the system. Power: The main power switch is used to apply or remove power from the power supply to the server system.

  • Page 31: Overheating

    Some backplanes allow the overheat temperature to be set at 45°, 50°, or 55° C by changing a jumper setting. For more information, consult the backplane user manual at www.supermicro.com. (Click Support, then the Manuals link.) Responses If the server overheats: 1.

  • Page 32: Drive Carrier Leds

    SUPERSERVER 1028TR-T/TF User's Manual Drive Carrier LEDs The chassis includes externally accessible SAS/SATA drives. Each drive carrier displays two status LEDs on the front of the carrier. LED Color State Status Activity LED Green Solid On SAS drive installed Green...

  • Page 33: Chapter 4 Standardized Warning Statements For Ac Systems

    Only certifi ed technicians should attempt to install or confi gure components. Read this appendix in its entirety before installing or confi guring components in the Supermicro chassis. These warnings may also be found on our web site at http://www.supermicro.com/ about/policies/safety_information.cfm. Warning Defi nition Warning! This warning symbol means danger.
  • Page 34 SUPERSERVER 1028TR-T/TF User's Manual Warnung WICHTIGE SICHERHEITSHINWEISE Dieses Warnsymbol bedeutet Gefahr. Sie befi nden sich in einer Situation, die zu Verletzungen führen kann. Machen Sie sich vor der Arbeit mit Geräten mit den Gefahren elektrischer Schaltungen und den üblichen Verfahren zur Vorbeugung vor Unfällen vertraut.
  • Page 35 Warning Statements for AC Systems ‫ﺟﺴﺪﻳﺔ‬ ‫ﺍﺻﺎﺑﺔ‬ ‫ﺗﺘﺴﺒﺐ ﻓﻲ‬ ‫ﺣﺎﻟﺔ ﻳﻤﻜﻦ ﺃﻥ‬ ‫ﺍﻧﻚ ﻓﻲ‬ ‫ﺧﻄﺮ‬ ‫ﻳﻌﻨﻲ‬ ‫ﻫﺬﺍ ﺍﻟﺮﻣﺰ‬ !‫ﺗﺤﺬﻳﺮ‬ ‫ﺍﻟﺪﻭﺍﺋﺮ‬ ‫ﺑﺎﻟﻤﺨﺎﻁﺮ ﺍﻟﻨﺎﺟﻤﺔ ﻋﻦ‬ ‫ﻦ ﻋﻠﻰ ﻋﻠﻢ‬ ، ‫ﻛ‬ ‫ﻣﻌﺪﺍﺕ‬ ‫ﺗﻌﻤﻞ ﻋﻠﻰ ﺃﻱ‬ ‫ﻗﺒﻞ ﺃﻥ‬ ‫ﺍﻟﻜﻬﺮﺑﺎﺋﻴﺔ‬ ‫ﺣﻮﺍﺩﺙ‬ ‫ﺃﻱ‬ ‫ﻭﻗﻮﻉ‬ ‫ﻤﻨﻊ‬ ‫ﻟ‬ ‫ﺍﻟﻮﻗﺎﺋﻴﺔ‬...

  • Page 36: Installation Instructions

    SUPERSERVER 1028TR-T/TF User's Manual Installation Instructions Warning! Read the installation instructions before connecting the system to the power source. 設置手順書 システムを電源に接続する前に、 設置手順書をお読み下さい。 警告 将此系统连接电源前,请先阅读安装说明。 警告 將系統與電源連接前，請先閱讀安裝說明。 Warnung Vor dem Anschließen des Systems an die Stromquelle die Installationsanweisungen lesen. ¡Advertencia! Lea las instrucciones de instalación antes de conectar el sistema a la red de alimentación.

  • Page 37: Circuit Breaker

    Chapter 4: Warning Statements for AC Systems Circuit Breaker Warning! This product relies on the building's installation for short-circuit (overcurrent) protection. Ensure that the protective device is rated not greater than: 250 V, 20 A. サーキッ ト ・ ブレーカー この製品は、 短絡 （過電流） 保護装置がある建物での設置を前提としています。 保護装置の定格が250 V、...

  • Page 38: Power Disconnection Warning

    SUPERSERVER 1028TR-T/TF User's Manual ‫ﻓﻲ‬ ‫ﺍﻟﺘﻲ ﺗﻢ ﺗﺜﺒﻴﺘﻬﺎ‬ ‫ﻣﻦ ﺍﻟﺪﻭﺍﺋﺮﺍﻟﻘﺼﻴﺮﺓ‬ ‫ﺍﻟﺤﻤﺎﻳﺔ‬ ‫ﻣﻌﺪﺍﺕ‬ ‫ﻳﻌﺘﻤﺪ ﻋﻠﻰ‬ ‫ﻫﺬﺍ ﺍﻟﻤﻨﺘﺞ‬ ‫ﺍﻟﻤﺒﻨﻰ‬ ‫ﺃﻛﺜﺮ ﻣﻦ‬ ‫ﻟﻴﺲ‬ ‫ﻮﻗﺎﺋﻲ‬ ‫ﺍﻟ‬ ‫ﺍﻟﺠﻬﺎﺯ‬ ‫ﺗﻘﻴﻴﻢ‬ ‫ﺃﻥ‬ ‫ﺗﺄﻛﺪ ﻣﻦ‬ 20A, 250V 경고! 이 제품은 전원의 단락(과전류)방지에 대해서 전적으로 건물의 관련 설비에 의존합니다. 보호장치의 정격이 반드시 250V(볼트), 20A(암페어)를 초과하지...
  • Page 39 Chapter 4: Warning Statements for AC Systems Warnung Das System muss von allen Quellen der Energie und vom Netzanschlusskabel getrennt sein, das von den Spg.Versorgungsteilmodulen entfernt wird, bevor es auf den Chassisinnenraum zurückgreift, um Systemsbestandteile anzubringen oder zu entfernen. ¡Advertencia! El sistema debe ser disconnected de todas las fuentes de energía y del cable eléctrico quitado de los módulos de fuente de alimentación antes de tener acceso el interior del chasis para instalar o para quitar componentes de sistema.

  • Page 40: Equipment Installation

    SUPERSERVER 1028TR-T/TF User's Manual Equipment Installation Warning! Only trained and qualifi ed personnel should be allowed to install, replace, or service this equipment. 機器の設置 トレーニングを受け認定された人だけがこの装置の設置、 交換、 またはサービスを許可 されています。 警告 只有经过培训且具有资格的人员才能进行此设备的安装、更换和维修。 警告 只有經過受訓且具資格人員才可安裝、更換與維修此設備。 Warnung Das Installieren, Ersetzen oder Bedienen dieser Ausrüstung sollte nur geschultem, qualifi...

  • Page 41: Restricted Area

    Chapter 4: Warning Statements for AC Systems Waarschuwing Deze apparatuur mag alleen worden geïnstalleerd, vervangen of hersteld door geschoold en gekwalifi ceerd personeel. Restricted Area Warning! This unit is intended for installation in restricted access areas. A restricted access area can be accessed only through the use of a special tool, lock and key, or other means of security.

  • Page 42: Battery Handling

    SUPERSERVER 1028TR-T/TF User's Manual ‫אזור עם גישה מוגבלת‬ !‫אזהרה‬ ‫יש להתקין את היחידה באזורים שיש בהם הגבלת גישה. הגישה ניתנת בעזרת‬ .('‫כלי אבטחה בלבד )מפתח, מנעול וכד‬ ‫ﻣﺤﻈﻮﺭﺓ‬ ‫ﻣﻨﺎﻁﻖ‬ ‫ﻟﺘﺮﻛﻴﺒﻬﺎ ﻓﻲ‬ ‫ﻫﺬﻩ ﺍﻟﻮﺣﺪﺓ‬ ‫ﺗﺨﺼﻴﺺ‬ ‫ﺗﻢ‬ ،‫ﺃﺩﺍﺓ ﺧﺎﺻﺔ‬ ‫ﻣﻦ ﺧﻼﻝ ﺍﺳﺘﺨﺪﺍﻡ‬...
  • Page 43 Chapter 4: Warning Statements for AC Systems Warnung Bei Einsetzen einer falschen Batterie besteht Explosionsgefahr. Ersetzen Sie die Batterie nur durch den gleichen oder vom Hersteller empfohlenen Batterietyp. Entsorgen Sie die benutzten Batterien nach den Anweisungen des Herstellers. Attention Danger d'explosion si la pile n'est pas remplacée correctement. Ne la remplacer que par une pile de type semblable ou équivalent, recommandée par le fabricant.

  • Page 44: Redundant Power Supplies

    SUPERSERVER 1028TR-T/TF User's Manual Redundant Power Supplies Warning! This unit might have more than one power supply connection. All connections must be removed to de-energize the unit. 冗長電源装置 このユニッ トは複数の電源装置が接続されている場合があります。 ユニッ トの電源を切るためには、 すべての接続を取り外さなければなりません。 警告 此部件连接的电源可能不止一个，必须将所有电源断开才能停止给该部件供电。 警告 此裝置連接的電源可能不只一個，必須切斷所有電源才能停止對該裝置的供電。 Warnung Dieses Gerät kann mehr als eine Stromzufuhr haben. Um sicherzustellen, dass der Einheit kein trom zugeführt wird, müssen alle Verbindungen entfernt werden.

  • Page 45: Backplane Voltage

    Chapter 4: Warning Statements for AC Systems ‫ﺍﻣﺪﺍﺩ ﺍﻟﻄﺎﻗﺔ‬ ‫ﺑﻮﺣﺪﺍﺕ‬ ‫ﻋﺪﺓ ﺍﺗﺼﺎﻻﺕ‬ ‫ﺠﻬﺎﺯ‬ ‫ﺍﻟ‬ ‫ﻳﻜﻮﻥ ﻟﻬﺬﺍ‬ ‫ﻗﺪ‬ ‫ﺍﻟﻜﻬﺮﺑﺎء‬ ‫ﻋﻦ‬ ‫ﻮﺣﺪﺓ‬ ‫ﺍﻟ‬ ‫ﻟﻌﺰﻝ‬ ‫ﻛﺎﻓﺔ ﺍﻻﺗﺼﺎﻻﺕ‬ ‫ﻳﺠﺐ ﺇﺯﺍﻟﺔ‬ 경고! 이 장치에는 한 개 이상의 전원 공급 단자가 연결되어 있을 수 있습니다. 이 장치에 전원을...

  • Page 46: Comply With Local And National Electrical Codes

    SUPERSERVER 1028TR-T/TF User's Manual Attention Lorsque le système est en fonctionnement, des tensions électriques circulent sur le fond de panier. Prendre des précautions lors de la maintenance. ‫מתח בפנל האחורי‬ !‫הרה‬ ‫אז‬ ‫קיימת סכנת מתח בפנל האחורי בזמן תפעול המערכת. יש להיזהר במהלך‬...

  • Page 47: Product Disposal

    Chapter 4: Warning Statements for AC Systems ¡Advertencia! La instalacion del equipo debe cumplir con las normas de electricidad locales y nacionales.Attention L'équipement doit être installé conformément aux normes électriques nationales et locales. ‫תיאום חוקי החשמל הארצי‬ !‫אזהרה‬ ‫הציוד חייבת להיות תואמת לחוקי החשמל המקומיים והארציים‬ ‫התקנת‬...

  • Page 48: Easy Swap Fan Warning

    SUPERSERVER 1028TR-T/TF User's Manual Warnung Die Entsorgung dieses Produkts sollte gemäß allen Bestimmungen und Gesetzen des Landes erfolgen. ¡Advertencia! Al deshacerse por completo de este producto debe seguir todas las leyes y reglamentos nacionales. Attention La mise au rebut ou le recyclage de ce produit sont généralement soumis à des lois et/ou directives de respect de l'environnement.
  • Page 49 Chapter 4: Warning Statements for AC Systems 当您从机架移除风扇装置，风扇可能仍在转动。小心不要将手指、螺丝起子和其他 物品太靠近风扇 警告 當您從機架移除風扇裝置，風扇可能仍在轉動。小心不要將手指、螺絲起子和其他 物品太靠近風扇。 Warnung Die Lüfter drehen sich u. U. noch, wenn die Lüfterbaugruppe aus dem Chassis genommen wird. Halten Sie Finger, Schraubendreher und andere Gegenstände von den Öffnungen des Lüftergehäuses entfernt. ¡Advertencia! Los ventiladores podran dar vuelta cuando usted quite ell montaje del ventilador del chasis.

  • Page 50: Power Cable And Ac Adapter

    fi re. Electrical Appliance and Material Safety Law prohibits the use of UL or CSA -certifi ed cables (that have UL/CSA shown on the code) for any other electrical devices than products designated by Supermicro only. 電源コードとACアダプター...
  • Page 51 Appareils électroménagers et de loi sur la sécurité Matériel interdit l'utilisation de UL ou CSA câbles certifi és qui ont UL ou CSA indiqué sur le code pour tous les autres appareils électriques que les produits désignés par Supermicro seulement.
  • Page 52 Elektrisch apparaat en veiligheidsinformatiebladen wet verbiedt het gebruik van UL of CSA gecertifi ceerde kabels die UL of CSA die op de code voor andere elektrische apparaten dan de producten die door Supermicro alleen.

  • Page 53: Chapter 5 Advanced Motherboard Setup

    Chapter 5: Advanced Motherboard Setup Chapter 5 Advanced Motherboard Setup This chapter covers the steps required to install the X10DRT-L/LIBF motherboard into the chassis, connect the data and power cables and install add-on cards. All motherboard jumpers and connections are also described. A layout and quick reference chart are included in this chapter for your reference.

  • Page 54: Connecting Cables

    SUPERSERVER 1028TR-T/TF User's Manual Connecting Cables Now that the processors are installed, the next step is to connect the cables to the serverboard. Connecting Data Cables The cables used to transfer data from the peripheral devices have been carefully routed in preconfi gured systems to prevent them from blocking the fl ow of cooling air that moves through the system from front to back.

  • Page 55: Connecting The Control Panel

    Chapter 5: Advanced Motherboard Setup Connecting the Control Panel JF1 contains header pins for various front control panel connectors. See Figure 5-1 for the pin locations of the various front control panel buttons and LED indicators. Even and odd numbered pins are on opposite sides of each header. All JF1 wires have been bundled into single keyed ribbon cable to simplify their connection.

  • Page 56: Processor And Heatsink Installation

    CPU socket cap is in place and none of the socket pins are bent; otherwise, contact your retailer immediately. Note: Refer to the Supermicro website for updates on CPU support. Note: When one CPU is installed, be sure to installed on CPU Socket 1 fi rst.
  • Page 57 Chapter 5: Advanced Motherboard Setup 2. Press the second load lever labeled 'Close 1st' to release the load plate that covers the CPU socket from its locking position. Press down on Load the Lever Pull lever away labeled 'Close 1st' from the socket 3.
  • Page 58 SUPERSERVER 1028TR-T/TF User's Manual 5. Use your thumb and index fi nger to hold the CPU on its edges. Align the CPU keys, which are semi-circle cutouts, against the socket keys. Socket Keys CPU Keys 6. Once they are aligned, carefully lower the CPU straight down into the socket.
  • Page 59 Chapter 5: Advanced Motherboard Setup 7. With the CPU inside the socket, inspect the four corners of the CPU to make sure that the CPU is properly installed. 8. Close the load plate with the CPU inside the socket. Lock the lever labeled 'Close 1st' fi...

  • Page 60: Installing A Passive Cpu Heatsink

    SUPERSERVER 1028TR-T/TF User's Manual Installing a Passive CPU Heatsink 1. Do not apply any thermal grease to the heatsink or the CPU die -- the required amount has already been applied. 2. Place the heatsink on top of the CPU so that the four mounting holes are aligned with those on the motherboard and the heatsink bracket underneath.

  • Page 61: Removing The Heatsink

    Chapter 5: Advanced Motherboard Setup Removing the Heatsink Caution: We do not recommend that the CPU or the heatsink be removed. However, if you do need to uninstall the CPU or the heatsink, please follow the instructions below to uninstall the heatsink to avoid damaging the CPU or the motherboard. 1.

  • Page 62: Installing Memory

    SUPERSERVER 1028TR-T/TF User's Manual Installing Memory Caution: Exercise extreme care when installing or removing DIMM modules to prevent any possible damage. Installing Memory 1. Insert the desired number of DIMMs into the memory slots, starting with P1- DIMMA1. For best performance, please use DIMM modules of the same type and speed in the same bank.

  • Page 63: Memory Support

    SDRAM in 512 MB, 1 GB, 2 GB, 4 GB, 8 GB, 16 GB, 32 GB or 64 GB sizes at 1.2V voltages. See Chapter 5 for details. Note: Check the Supermicro website (www.supermicro.com) for the latest memory support information.

  • Page 64: Adding Pci Expansion Cards

    SUPERSERVER 1028TR-T/TF User's Manual Populating RDIMM/LRDIMM ECC Memory Modules RDIMM/LRDIMM DDR4 ECC Type Ranks Per Memory DIMM Max Speed (Ghz); DIMM & Capacity (GB) Voltage (V) Data Width (See the Note Below) Slots per Channel (SPC) and DIMM per Channel (DPC)

  • Page 65: Motherboard Details

    Chapter 5: Advanced Motherboard Setup Motherboard Details Figure 5-4. X10DRT-L/LIBF Motherboard Layout (not drawn to scale) LAN2 LAN1 USB0/1(2.0) InfiniBand COM1 JIB1 JPME2 LEDPWR JWD1 InfiniBand Chip IPMI_LAN LEDBMC CTRL I-SGPIO2 BIOS JBT1 X10DRT-L Rev. 1.00 CPU1 IPMI CODE IPMI CODE CLOSE 1st CPU2 OPEN 1st...
  • Page 66 SUPERSERVER 1028TR-T/TF User's Manual Notes: 1. For the latest CPU/Memory updates, please refer to our website at http:// www.supermicro.com/products/motherboard/ for details. 2. Use only the correct type of onboard CMOS battery as specifi ed by the manufacturer. Do not install the onboard battery upside down to avoid possible explosion.
  • Page 67 SATA 3.0 connections supported by Intel PCH (I-SATA 0-5) S-SATA0-3 SATA 3.0 connections (S-SATA0-3) supported by Intel SCU (Note: S-SATA2/S- SATA3: can be used as Supermicro SuperDOMs (-Disks-on-Module) with built-in power connectors) I-SGPIO1/2 Serial General-Purpose Input/Out connector headers for I-SATA 0-5 (I-SGPIO1:...

  • Page 68: Connector Defi Nitions

    SUPERSERVER 1028TR-T/TF User's Manual Connector Defi nitions Power Connectors 20-pin Main Connector Pin Defi nitions (J4/J6) Two 20-pin power supply connectors and Pin# Defi nition Pin# Defi nition a 4-pin power connector are located on PS_ON# Ground the motherboard. The two 20-pin power...
  • Page 69 Chapter 5: Advanced Motherboard Setup PW_ON Connector Power Button Pin Defi nitions The Power Button connection is located (JF1) on pins 1 and 2 of JF1. Momentarily Pin# Defi nition contacting both pins will power on/off Signal the system. To turn on or off the system Ground power, press the button for 4 seconds or longer.
  • Page 70 SUPERSERVER 1028TR-T/TF User's Manual NIC1/NIC2 LED Indicators NIC1 LED Pin Defi nitions (JF1) The NIC (Network Interface Controller) Pin# Defi nition LED connection for LAN port 1 is located NIC 2 Activity LED on pins 11 and 12 of JF1, and the LED...
  • Page 71 Chapter 5: Advanced Motherboard Setup Universal Serial Bus (USB) Back Panel USB 0/1 (2.0) Pin Defi nitions Two USB 2.0 ports (USB 0/1) are located Pin# Defi nition Pin# Defi nition on the I/O back panel. In addition, a Type-A connector is also located on the motherboard to provide front USB USB_PN1 USB_PN0...
  • Page 72 SUPERSERVER 1028TR-T/TF User's Manual Unit Identifi er Switches/UID LED UID Switch Indicators Pin# Defi nition A rear Unit Identifi er (UID) switch and Ground rear UID LED (LE1) are located next Ground to the InfiniBand connector on the Button In motherboard.
  • Page 73 Chapter 5: Advanced Motherboard Setup DOM Power Connectors DOM PWR (JSD1/2) Two power connectors for SATA DOM Pin Defi nitions (Disk_On_Module) devices are located Pin# Defi nition at JSD1/JSD2. Connect appropriate cables here to provide power support for Ground your Serial Link DOM devices. Ground Standby Power Header Standby PWR...
  • Page 74 SUPERSERVER 1028TR-T/TF User's Manual I-SGPIO1/2 & S-SGPIO1 Headers SGPIO Header Pin Defi nitions (T-SGPIO1/T-SGPIO2) Three SGPIO (Serial Link General Pin# Defi nition Pin # Defi nition Purpose Input/Output) headers are Data located on the motherboard. I-SGPIO1/2 support onboard I-SATA ports 0-5,...

  • Page 75: Jumper Settings

    Chapter 5: Advanced Motherboard Setup Jumper Settings Connector Pins Explanation of Jumpers To modify the operation of the motherboard, Jumper jumpers can be used to choose between optional settings. Jumpers create shorts between two pins to change the function Setting of the connector.
  • Page 76 SUPERSERVER 1028TR-T/TF User's Manual Watch Dog Enable/Disable Watch Dog (JWD1) Jumper Settings The Watch Dog (JWD1) is a system Jumper Setting Defi nition monitor that will reboot the system when Pins 1-2 Reset (default) a software application hangs. Close pins 1-2 to reset the system if an appli- Pins 2-3 cation hangs.

  • Page 77: 5-10 Onboard Indicators

    Chapter 5: Advanced Motherboard Setup Manufacturer Mode Select ME Mode Select Jumper Settings Close pin 2 and pin 3 of Jumper JPME2 Jumper Setting Defi nition to bypass SPI fl ash security and force the Pins 1-2 Normal (Default) system to operate in the manufacturer Pins 2-3 Manufacture mode, which will allow the user to fl...
  • Page 78 SUPERSERVER 1028TR-T/TF User's Manual IPMI Dedicated LAN LEDs IPMI LAN Link LED Activity LED In addition to the LAN Port 1, an IPMI Dedicated LAN is also located on the I/O Backplane. The amber LED on the right indicates connection and activity; while...

  • Page 79: 5-11 Pci-Express And Serial Ata Connections

    (I-SATA 0-5) are supported by the Intel PCH C612, and four S-SATA 3.0 connections (S-SATA0-3) are supported by the Intel SCU. Please note that S-SATA2/S-SATA3 can be used as Supermicro SuperDOMs (Disks-on-Module) with built-in power connectors. These SATA ports provide serial-link signal connections, which are faster than the connections of Parallel ATA.

  • Page 80: 5-12 Installing Drivers

    SUPERSERVER 1028TR-T/TF User's Manual 5-12 Installing Drivers The CD that came bundled with the system contains drivers, some of which must be installed, such as the chipset driver. After inserting this CD into your CD-ROM drive, the display shown in Figure 5-5 should appear. (If this display does not appear, click on the My Computer icon and then on the icon representing your CD-ROM drive.

  • Page 81: Superdoctor 5

    Chapter 5: Advanced Motherboard Setup SuperDoctor 5 ® The Supermicro SuperDoctor 5 is a hardware and operating system services monitoring program that functions in a command-line or web-based interface in Windows and Linux operating systems. The program monitors system health...
  • Page 82 Figure 5-7. SuperDoctor 5 Interface Display Screen (Remote Control) Note: The SuperDoctor 5 program and User’s Manual can be downloaded from the Supermicro web site at http://www.supermicro.com/products/nfo/sms_sd5.cfm. For Linux, we recommend that you use the SuperDoctor II application instead. 5-30...

  • Page 83: 5-13 Serverboard Battery

    Chapter 5: Advanced Motherboard Setup 5-13 Serverboard Battery Caution: There is a danger of explosion if the onboard battery is installed upside down, which will reverse its polarites (see Figure 5-8). This battery must be replaced only with the same or an equivalent type recommended by the manufacturer (CR2032).
  • Page 84 SUPERSERVER 1028TR-T/TF User's Manual Notes 5-32...

  • Page 85: Chapter 6 Advanced Chassis Setup

    Chapter 6: Advanced Chassis Setup Chapter 6 Advanced Chassis Setup This chapter covers the steps required to install components and perform maintenance on the SC809TS-1K03BP chassis. For component installation, follow the steps in the order given to eliminate the most common problems encountered. If some steps are unnecessary, skip ahead to the step that follows.

  • Page 86: Control Panel

    SUPERSERVER 1028TR-T/TF User's Manual Figure 6-1. Front and Rear Chassis Views Control Panel Control Panel SATA Drives (8) COM1 Port VGA Port USB Ports Infi niband Port IPMI LAN Port Ethernet Ports Control Panel The control panel is located on the front of the chassis. The LEDs inform you of system status.

  • Page 87: Chassis Cover

    Chapter 6: Advanced Chassis Setup Chassis Cover Before operating the SC809 chassis for the fi rst time, it is important to remove the protective fi lm covering the top of the chassis, in order to allow for proper ventilation and cooling. Opening the Chassis Cover (Figure 6-2)) Removing the Chassis Cover 1.

  • Page 88: Installing The Air Shrouds

    SUPERSERVER 1028TR-T/TF User's Manual Installing the Air Shrouds Air Shrouds Air shrouds concentrate airfl ow to maximize fan effi ciency. The SC809 chassis requires two identical air shrouds. They do not require screws to install. Installing the Air Shrouds 1. Confi rm that all six fans are in place and working properly. (See the end of this chapter for details on the system fans).

  • Page 89: System Fans

    Chapter 6: Advanced Chassis Setup System Fans Six fans provide cooling for the SC809 chassis. These fans circulate air through the chassis as a means of lowering the chassis internal temperature. The SC809 system fans are hot-swappable. There is no need to power down the system when switching fans.

  • Page 90: Installing Hard Drives

    SUPERSERVER 1028TR-T/TF User's Manual Figure 6-5. System Fan Placement Installing Hard Drives The SC809 has two sets of four hard disk drives (eight total) which are mounted in drive carriers and reside within the the hard drive bays. These drives are hot- swappable and can be removed or replaced without powering down the chassis.
  • Page 91 Chapter 6: Advanced Chassis Setup Figure 6-6. Removing Hard Drive...
  • Page 92 Figure 6-7. Removing Dummy Drive from Tray Dummy Drive Drive Tray Warning: Enterprise level hard disk drives are recommended for use in Supermicro chassis and servers. For information on recommended HDDs, visit the Supermicro Web site at http://www.supermicro.com/products/nfo/fi les/ storage/SAS-CompList.pdf...

  • Page 93: Motherboard Installation

    Chapter 6: Advanced Chassis Setup Motherboard Installation I/O Shield The I/O shield holds the motherboard ports in place. The I/O shield does not require installation. However, you must confi rm that the motherboard matches the I/O shield. Figure 6-8. I/O Shield Placement I/O Shields Permanent and Optional Standoffs Standoffs prevent short circuits by securing space between the motherboard and...
  • Page 94 SUPERSERVER 1028TR-T/TF User's Manual 5. Secure the motherboard to the chassis using the rounded, Phillips head screws. Each motherboard requires fi ve screws. 6. Repeat steps 3 - 5 for the second side of the chassis. 7. Secure the CPUs, heatsinks, and other components to the motherboards as described in the motherboard documentation.

  • Page 95: Expansion Slot Setup

    Chapter 6: Advanced Chassis Setup Expansion Slot Setup The SC809 chassis includes I/O slots for expansion cards. Each side supports one low profi le/half-length card, for a total of two per system. Installing Extension Cards 1. Disconnect the power supply, lay the chassis on a fl at surface, and open the chassis cover.

  • Page 96: Power Supply

    The SC809 chassis utilizes one power supply. In the unlikely event that the power supply unit must be replaced, the system will shut down. Replacement units can be ordered directly from Supermicro. (See the Contact Information section in the Preface of this manual).
  • Page 97 Chapter 6: Advanced Chassis Setup Changing The Power Supply: 1. Power down the server and unplug the power cord. 2. Push the release tab (on the back of the power supply) as illustrated. 3. Pull the power supply out using the handle provided. 4.
  • Page 98 SUPERSERVER 1028TR-T/TF User's Manual Notes 6-14...

  • Page 99: Chapter 7 Bios

    When an option is selected in the left frame, it is highlighted in white. Often a text message will accompany it. (Note: the AMI BIOS has default text messages built in. Supermicro retains the option to include, omit, or change any of these text messages.) The AMI BIOS Setup Utility uses a key-based navigation system called "hot keys".

  • Page 100: Starting The Setup Utility

    Flashing the wrong BIOS can cause irreparable damage to the system. In no event shall Supermicro be liable for direct, indirect, special, incidental, or consequential damages arising from a BIOS update. If you have to update the BIOS, do not shut down or reset the system while the BIOS is updating.
  • Page 101 Day MM/DD/YYYY format. The time is entered in HH:MM:SS format. Note: The time is in the 24-hour format. For example, 5:30 P.M. appears as 17:30:00. Supermicro X10DRT-L Series BIOS Version: This item displays the version of the BIOS ROM used in the system.

  • Page 102: Advanced Settings Menu

    SUPERSERVER 1028TR-T/TF User's Manual Advanced Settings Menu Use the arrow keys to select Advanced setup and press <Enter> to access the submenu items: Warning: Take Caution when changing the Advanced settings. An incorrect value, a very high DRAM frequency or an incorrect BIOS timing setting may cause the system to malfunction.
  • Page 103 Chapter 7: BIOS Bootup Num-Lock State Use this feature to set the Power-on state for the Numlock key. The options are Off and On. Wait For 'F1' If Error Select Enabled to force the system to wait until the 'F1' key is pressed if an error occurs.
  • Page 104 SUPERSERVER 1028TR-T/TF User's Manual Restore on AC Power Loss Use this feature to set the power state after a power outage. Select Power-Off for the system power to remain off after a power loss. Select Power-On for the system power to be turned on after a power loss. Select Last State to allow the system to resume its last power state before a power loss.
  • Page 105 Chapter 7: BIOS Execute Disable Bit (Available if supported by the OS & the CPU) Select Enable for Execute Disable Bit Technology support, which will allow the processor to designate areas in the system memory where an application code can execute and where it cannot, thus preventing a worm or a virus from fl...
  • Page 106 SUPERSERVER 1028TR-T/TF User's Manual X2APIC (Advanced Programmable Interrupt Controller) Based on Intel's Hyper-Threading architecture, each logical processor (thread) is assigned 256 APIC IDs (APIDs) in 8-bit bandwidth. When this feature is set to Enable, the APIC ID will be expanded (X2) from 8 bits to 16 bits to provide 512 APIDs to each thread to enhance CPU performance.
  • Page 107 Chapter 7: BIOS  CPU P State Control (Available when Power Technology is set to Custom) EIST (P-states) EIST (Enhanced Intel SpeedStep Technology) allows the system to automatically adjust processor voltage and core frequency to reduce power consumption and heat dissipation. The options are Disable and Enable. Turbo Mode Select Enabled to use the Turbo Mode to boost system performance.

  • Page 108: North Bridge

    SUPERSERVER 1028TR-T/TF User's Manual  CPU T State Control (Available when Power Technology is set to Custom) ACPI (Advanced Confi guration Power Interface) T-States Select Enable to support CPU throttling by the operating system to reduce power consumption. The options are Enable and Disable.
  • Page 109 Chapter 7: BIOS No Snoop Select Enable to support no-snoop mode for each CB device. The options are Disable and Enable. Relaxed Ordering Select Enable to enable Relaxed Ordering support which will allow certain transactions to violate the strict-ordering rules of PCI bus for a transaction to be completed prior to other transactions that have already been enqueued.
  • Page 110 SUPERSERVER 1028TR-T/TF User's Manual Link Frequency Select Use this item to select the desired frequency for QPI Link connections. The options are 6.4GB/s, 8.0GB/s, 9.6GB/s, Auto, and Auto Limited. Link L0p Enable Select Enable for Link L0p support. The options are Enable and Disable.

  • Page 111: Dimm Information

    Chapter 7: BIOS Set Throttling Mode Throttling improves reliability and reduces power consumption in the processor via automatic voltage control during processor idle states. The options are Disabled and CLTT (Closed Loop Thermal Throttling). A7 Mode Select Enable to support the A7 (Addressing) mode to improve memory performance.

  • Page 112: South Bridge

    SUPERSERVER 1028TR-T/TF User's Manual Patrol Scrub Interval This feature allows you to decide how many hours the system should wait before the next complete patrol scrub is performed. Use the keyboard to enter a value from 0-24. The Default setting is 24.
  • Page 113 Chapter 7: BIOS Port 60/64 Emulation Select Enabled to support I/O port 60h/64h emulation, which will provide complete legacy USB keyboard support for the operating systems that do not support legacy USB devices. The options are Disabled and Enabled. USB 3.0 Support Select Enabled for USB 3.0 support.
  • Page 114 SUPERSERVER 1028TR-T/TF User's Manual Support Aggressive Link Power Management When this item is set to Enabled, the SATA AHCI controller manages the power usage of the SATA link. The controller will put the link to a low power state when the I/O is inactive for an extended period of time, and the power state will return to normal when the I/O becomes active.
  • Page 115 Chapter 7: BIOS *If the item above "Confi gure SATA as" is set to RAID, the following items will display: Support Aggressive Link Power Management When this item is set to Enabled, the SATA AHCI controller manages the power usage of the SATA link. The controller will put the link to a low power state when the I/O is inactive for an extended period of time, and the power state will return to normal when the I/O becomes active.
  • Page 116 SUPERSERVER 1028TR-T/TF User's Manual  sSATA Confi guration When this submenu is selected, AMI BIOS automatically detects the presence of the SATA devices that are supported by the PCH-sSATA controller and displays the following items: sSATA Controller This item enables or disables the onboard SATA controller supported by the Intel PCH-sSATA controller.
  • Page 117 Chapter 7: BIOS Port 0 ~ Port 3 sSATA Device Type Use this item to specify if the sSATA port specifi ed by the user should be connected to a Solid State drive or a Hard Disk Drive. The options are Hard Disk Drive and Solid State Drive.
  • Page 118 SUPERSERVER 1028TR-T/TF User's Manual sSATA Port 0~ Port 3 Select Enabled to enable an sSATA port specifi ed by the user. The options are Disabled and Enabled. sSATA Port 0 ~ Port 3 Hot Plug This feature designates this port for hot plugging. Set this item to Enabled for hot-plugging support, which will allow the user to replace an sSATA drive without shutting down the system.
  • Page 119 Chapter 7: BIOS Above 4G Decoding (Available if the system supports 64-bit PCI decoding) Select Enabled to decode a PCI device that supports 64-bit in the space above 4G Address. The options are Enabled and Disabled. SR-IOV (Available if the system supports Single-Root Virtualization) Select Enabled for Single-Root IO Virtualization support.
  • Page 120 SUPERSERVER 1028TR-T/TF User's Manual Onboard LAN1 Option ROM/Onboard LAN2 Option ROM/Onboard Video Option ROM Use this option to select the type of device installed in LAN Port1, LAN Port2 or the onboard video device used for system boot. The default setting for LAN1 Option ROM is PXE, for LAN2 Option ROM is Disabled and for Onboard Video Option ROM is Legacy.

  • Page 121: Serial Port Console Redirection

    Chapter 7: BIOS Serial Port 2 Attribute Select SOL to use COM Port 2 as a Serial_Over_LAN (SOL) port for console redirection. The options are COM and SOL.  Serial Port Console Redirection COM 1 COM 1 Console Redirection Select Enabled to enable COM Port 1 Console Redirection, which will allow a client machine to be connected to a host machine at a remote site for networking.
  • Page 122 SUPERSERVER 1028TR-T/TF User's Manual Parity A parity bit can be sent along with regular data bits to detect data transmission errors. Select Even if the parity bit is set to 0, and the number of 1's in data bits is even. Select Odd if the parity bit is set to 0, and the number of 1's in data bits is odd.
  • Page 123 Chapter 7: BIOS Redirection After BIOS Post Use this feature to enable or disable legacy Console Redirection after BIOS POST. When the option-Bootloader is selected, legacy Console Redirection is disabled before booting the OS. When the option- Always Enable is selected, legacy Console Redirection remains enabled upon OS bootup.
  • Page 124 SUPERSERVER 1028TR-T/TF User's Manual Parity A parity bit can be sent along with regular data bits to detect data transmission errors. Select Even if the parity bit is set to 0, and the number of 1's in data bits is even. Select Odd if the parity bit is set to 0, and the number of 1's in data bits is odd.
  • Page 125 Chapter 7: BIOS Redirection After BIOS Post Use this feature to enable or disable legacy Console Redirection after BIOS POST (Power-On Self-Test). When this feature is set to Bootloader, legacy Console Redirection is disabled before booting the OS. When this feature is set to Always Enable, legacy Console Redirection remains enabled upon OS boot.
  • Page 126 SUPERSERVER 1028TR-T/TF User's Manual Flow Control Use this item to set the fl ow control for Console Redirection to prevent data loss caused by buffer overfl ow. Send a "Stop" signal to stop data-sending when the receiving buffer is full. Send a "Start" signal to start data-sending when the receiving buffer is empty.

  • Page 127: Acpi Settings

    Chapter 7: BIOS  ACPI Settings WHEA Support Select Enabled to support the Windows Hardware Error Architecture (WHEA) platform and provide a common infrastructure for the system to handle hardware errors within the Windows OS environment to reduce system crashes and to enhance system recovery and health monitoring.

  • Page 128: Event Logs

    SUPERSERVER 1028TR-T/TF User's Manual Event Logs Use this feature to confi gure Event Log settings.  Change SMBIOS Event Log Settings This feature allows the user to confi gure SMBIOS Event settings. Enabling/Disabling Options SMBIOS Event Log Select Enabled to enable SMBIOS (System Management BIOS) Event Logging during system boot.

  • Page 129: View Smbios Event Log

    Chapter 7: BIOS Erasing Settings Erase Event Log Select Yes to erase all error events in the SMBIOS (System Management BIOS) log before an event logging is initialized at bootup. The options are No and Yes. When Log is Full Select Erase Immediately to immediately erase all errors in the SMBIOS event log when the event log is full.

  • Page 130: Ipmi

    SUPERSERVER 1028TR-T/TF User's Manual IPMI Use this feature to confi gure Intelligent Platform Management Interface (IPMI) settings. BMC (BaseBoard Management Controller) Firmware Revision This item indicates the BMC fi rmware revision used in your system. IPMI Status This item indicates the status of the IPMI fi rmware installed in your system.
  • Page 131 Chapter 7: BIOS Erase SEL Select Yes, On next reset to erase all system event logs upon next system reboot. Select Yes, On every reset to erase all system event logs upon each system reboot. Select No to keep all system event logs after each system reboot. The options are No, Yes, On next reset, and Yes, On every reset.

  • Page 132: Security Settings

    SUPERSERVER 1028TR-T/TF User's Manual Gateway IP Address This item displays the Gateway IP address for this computer. This should be in decimal and in dotted quad form (i.e., 192.168.10.253). Security Settings This menu allows the user to confi gure the following security settings for the system.

  • Page 133: Secure Boot Menu

    Chapter 7: BIOS User Password Use this feature to set the user password which is required to enter the BIOS setup utility. The length of the password should be from 3 characters to 20 characters long.  Secure Boot Menu The following items will be displayed: •...
  • Page 134 SUPERSERVER 1028TR-T/TF User's Manual Key Exchange Key  Delete KEK  Set New KEK Press "Yes" to load "KEK" from factory defaults or select "No" to load from a fi le.  Append KEK Press "Yes" to load "KEK" from factory defaults or select "No" to load from a fi le.

  • Page 135: Boot Settings

    Chapter 7: BIOS Boot Settings Use this feature to confi gure Boot Settings: Boot Confi guration Setup Prompt Timeout Use this item to indicate how many seconds the system shall wait for the BIOS setup activation key to respond before the system starts to boot. The default setting is 1. Boot Mode Select Use this item to select the type of device to be used for system boot.
  • Page 136 SUPERSERVER 1028TR-T/TF User's Manual Fixed Boot Order Priorities This option prioritizes the order of bootable devices from which the system will boot. Press <Enter> on each entry from top to bottom to select devices. • Dual Boot Order #1 •...

  • Page 137: Save & Exit

    Chapter 7: BIOS Save & Exit Select the Save & Exit tab from the BIOS setup screen to confi gure the settings below. Discard Changes and Exit Select this option to quit the BIOS setup without making any permanent changes to the system confi...
  • Page 138 SUPERSERVER 1028TR-T/TF User's Manual Discard Changes Select this option and press <Enter> to discard all the changes and return to the AMI BIOS setup utility. Restore Optimized Defaults To set this feature, select Restore Optimized Defaults from the Exit menu and press <Enter>.

  • Page 139: Appendix A Bios Error Beep Codes

    Appendix A: BIOS Error Beep Codes Appendix A BIOS Error Beep Codes During the POST (Power-On Self-Test) routines, which are performed each time the system is powered on, errors may occur. Non-fatal errors are those which, in most cases, allow the system to continue the boot-up process.
  • Page 140 SUPERSERVER 1028TR-T/TF User's Manual Notes...

  • Page 141: Appendix B System Specifi Cations

    Note: Check the Supermicro website (www.supermicro.com) for the latest memory support information. SATA Drive Bays The SuperServer 1028TR-T/TF contains four (4) hot-swap drive bays per node to house four standard SATA drives, eight total. PCI Expansion The SuperServer 1028TR-T/TF has one (1) PCI-Express 3.0 x16 slot available...
  • Page 142 SUPERSERVER 1028TR-T/TF User's Manual Serverboard X10DRT-L/LIBF serverboard (proprietary form factor) Dimensions: (LxW) 6.50" (L) x 16.64" (W) (165.10 mm x 422.66 mm) Chassis SC809TS-1K03BP (1U rackmount) Dimensions: (WxHxD) 17.2 x 1.7 x 27.75 in. (437 x 43 x 705 mm) Weight Gross (Bare Bone): 29 lbs.
  • Page 143 Appendix B: System Specifi cations Regulatory Compliance Electromagnetic Emissions: FCC Class A, EN 55022 Class A, EN 61000-3-2/-3- 3, CISPR 22 Class A Electromagnetic Immunity: EN 55024/CISPR 24, (EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 61000-4-11) Safety: CSA/EN/IEC/UL 60950-1 Compliant, UL or CSA Listed (USA and Canada), CE Marking (Europe) California Best Management Practices Regulations for Perchlorate Materials:...
  • Page 144 SUPERSERVER 1028TR-T/TF User's Manual (continued from front) The products sold by Supermicro are not intended for and will not be used in life support systems, medical equipment, nuclear facilities or systems, aircraft, aircraft devices, aircraft/emergency communication devices or other critical systems whose failure to perform be reasonably expected to result in signifi...

This manual is also suitable for:

Superserver 1028tr-tf

Table of Contents
