Lead Safe™ Remote Electronic
®
Ezy-Drink
Drinking Bubbler Tap - Battery
PRODUCT CODES:
- 170.81.11.00
SPECIFICATIONS
−
Drinking taps are designed to operate at full mains pressure.
−
The rubber mouthguard is resistant to fungal and bacterial attack and has a high resistance to sunlight.
−
Adjustable built-in flow restrictor.
IMPORTANT: All Ezy-Drink
our premises in good working order.
As 'lead free' is not currently defined by low in Australia and New Zealand, we have based our definition of Lead Safe™ on the requirements of s1417 of the USA's Safe Drinking Water Act
(SDWA) and the relevant US standards NSF61 / NSF372. The SDWA defines 'lead free' as "not more than a weighted average of 0.25% lead when used with respect to the wetted surface of
pipes, pipe fittings, plumbing fittings and fixtures".
TECHNICAL DATA
Inlet
Outlet
Headwork
Working Pressure Range (kPa)
Working Temperature Range (°C)
Nominal Flow Rate (LPM)
Solenoid
Finish
NOTE: Galvin Specialised continually strive to improve their products. Specifications may change without
notice.
®
remote bubbler taps are tested in accordance with AS/NZS 3718 and leave
Input Voltage
Power Consumption
Cable length
Connection
Pressure Range
(kPa)
Temperature
(°C)
Version 1,15
½" BSP - Female
Rubber mouthguard
Piezo Activation
Min
50
Max
500
Min
5
Max
60
1.44
6 V DC
-
3.2m
1/2" BSP - Female
Inlet
1/2" BSP - Male
Outlet
Min
50
Max
500
Min
5
Max
60
Chrome
th
March 2021, Page 1 of 4
Advertisement
Related Manuals for Galvin Specialised Ezy-Drink Lead Safe
Summary of Contents for Galvin Specialised Ezy-Drink Lead Safe
- Page 1 6 V DC Power Consumption Cable length 3.2m 1/2” BSP - Female Inlet Connection 1/2” BSP - Male Solenoid Outlet Pressure Range (kPa) Temperature (°C) Finish Chrome NOTE: Galvin Specialised continually strive to improve their products. Specifications may change without notice.
- Page 2 INSTALLATION IMPORTANT: Galvin Specialised products must be installed in accordance with these installation instructions and in accordance with AS/NZS 3500, the PCA and your local regulatory requirements. Water and/or electrical supply conditions must also comply to the applicable national and/or state standards. Failing to comply with these provisions shall void the product warranty and may affect the performance of the product.
- Page 3 Version 1,15 March 2021, Page 3 of 4 3. Fit Piezo Button 4. Connect, Solenoid and Battery − − Install piezo button and connect it to the Connect Piezo button, the solenoid and the battery to electronic control unit. the eletronic control unit. −...
- Page 4 Version 1,15 March 2021, Page 4 of 4 SET WATER FLOW DURATION Contact Galvin Specialised for information regarding changing flow duration. TROUBLESHOOTING PROBLEM CAUSE RECTIFICATION Water is not flowing from Water is turned off Turn on water Blocked flow regulating screw...
