Charlton & Jenrick INFINITY 800HD BF UBL Instruction For User, Installation & Servicing

With under bed lighting
Hide thumbs
Table of Contents

Advertisement

Quick Links

800HD BF UBL
Instructions for user,
Installation & Servicing
With Under Bed
Lighting
Keep this booklet for service log and future reference
IMPORTANT
This appliance is guaranteed for 12 months subject to conditions. The 5 year extended parts
warranty will only be valid if the annual service recommended in this manual has been
completed and appliance has been registered online.
For use in Great Britain and Ireland.
Literature NO 8381 (ISS 01)
www.charltonandjenrick.co.uk
1
LT 8381 (ISS 01)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the INFINITY 800HD BF UBL and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Charlton & Jenrick INFINITY 800HD BF UBL

Summary of Contents for Charlton & Jenrick INFINITY 800HD BF UBL

  • Page 1 800HD BF UBL Instructions for user, Installation & Servicing With Under Bed Lighting Keep this booklet for service log and future reference IMPORTANT This appliance is guaranteed for 12 months subject to conditions. The 5 year extended parts warranty will only be valid if the annual service recommended in this manual has been completed and appliance has been registered online.

  • Page 2: Table Of Contents

    Contents Extended 5 Year Parts Warranty …………………….………. 2 EXTENDED FIVE YEAR Benchmark Scheme…………………………………………..……. 3 PARTS WARRANTY Consumer Protection Info ………………………………………. 4 Introduction ………………………………………………………..…. 5 In order to validate your extended 5 years parts warranty please read the Benchmark Scheme on the opposite page Handset set up…………………………………………………..……...

  • Page 3: Benchmark Scheme

    Benchmark Scheme Charlton and Jenrick Ltd is a licensed member of the Benchmark Scheme which aims to improve the standards of installation and commissioning of domestic heating and hot water systems in the UK and to encourage regular servicing to optimise safety, efficiency and performance. Benchmark is managed and promoted by the Heating and Hotwater Industry Council.

  • Page 4: Consumer Protection Info

    For future reference we suggest you record the following details here, and keep the receipt as proof of purchase. This information may be asked for when you contact the helpdesk. MODEL: INFINITY 800HD BF UBL Serial No. This information can be found on the label attached to the packaging and on the data badge, which is located on the base of the appliance behind the control cover.

  • Page 5: Introduction

    800 HD B.F. with UBL USERS INSTRUCTIONS Important Information (users instructions) Consumer protection information As manufacturers and suppliers of heating products, we take every care, as far as is reasonably practicable, that these products are so designed and constructed as to meet the general safety requirement when properly used and installed. To this end, our products are thoroughly tested and examined before despatch.

  • Page 6: Handset Set Up

    800 HD B.F. with UBL USERS INSTRUCTIONS Lighting the Appliance & General Operation of Control Handset set up video http://www.charltonandjenrick.co.uk/handsetguide/ When inserting the batteries, observe and position batteries according to the battery compartment graphics (see Fig 7). When the batteries are inserted the handset will attempt to pair.
  • Page 7 800 HD B.F. with UBL USERS INSTRUCTIONS Flame height adjustment Once the fire has been started (after a period of 10 minutes) the flame height can be decreased by moving your finger clock wise or decreased moving your finger anti-clock wise using the selector wheel. Once the desired flame level is set, remove your finger from the selector wheel to transmit your selection to the receiver.

  • Page 8: Auto (Thermostatic) Control

    800 HD B.F. with UBL USERS INSTRUCTIONS Note: The handset contains a sensitive temperature measurement device. To achieve the best thermostatic efficiency do not place the handset near the heat source, avoid covering, direct sunlight or near a draft or open window etc. Place the handset at a midpoint in the room or area being heated.

  • Page 9: Menu Features

    800 HD B.F. with UBL USERS INSTRUCTIONS Menu features The menu can be accessed by pressing and holding the button (approx. 5 seconds) until the menu graphic completes (see fig 6). Use the selector wheel to highlight one of the available options. Press to enter the required option.

  • Page 10: Under Bed Light Feature

    800 HD B.F. with UBL USERS INSTRUCTIONS Under Bed Light Feature The Under Bed Light feature offers multiple lighting features to enhance a flame effect or provide lighting effects whilst the appliance heat output is not required. The Under Bed Light feature can be operated whilst the fire is on or off. Press to awaken the handset from its dormant sleep mode at any time.

  • Page 11: Changing Handset Batteries

    800 HD B.F. with UBL USERS INSTRUCTION Notes: ▪ If no command is entered within 15 seconds whilst in the ‘LIGHT’ function the handset will return to the main operating screen. ▪ Brightness alternative on/off switch. 0% = lights off, any value greater than 0% will turn lights on for the effect selected.

  • Page 12: Cleaning Appliance/Glass

    800 HD B.F. with UBL USERS INSTRUCTION Cleaning & Laying the fuel bed (users instructions) Warning:-Before you clean any part of the appliance ensure that the appliance is switched off and cool. CLEANING: BLACK PAINTED SURFACES • These surfaces should be dusted regularly and any marks removed with a soft cloth. •...
  • Page 13 800 HD B.F. with UBL USERS INSTRUCTION • Carefully lift the glass panel up out off the bottom location. Lay the glass panel down on a flat working surface on top of an old opened newspaper with the side to be cleaned uppermost.

  • Page 14: Fuel Bed Layout

    800 HD B.F. with UBL USERS INSTRUCTION CLEANING AND REPLACING fuel bed shapes Important: - Refer to the ‘Health & Safety Notice located on page 3 of this booklet before cleaning or replacing any refractory material. Use only the shapes provided NO OTHER SHAPES SHOULD BE ADDED to the appliance The Fuel bed set consists of: •...
  • Page 15 800 HD B.F. with UBL USERS INSTRUCTION Place shape No. 1 on the burner tube, so that the wings on the shape fit over the burner support bracket on the left hand side pushing it to the right hand side once on the bracket, making sure it sits flat on the burner tube. •...
  • Page 16 800 HD B.F. with UBL USERS INSTRUCTION • Place shape No. 2 at the front with the small grooves on the underside going over the nuts on the Light Box Glass clamps as shown. The shape should sit flat, now some more of the glass chippings can be added on top of the glass on the light boxes.
  • Page 17 800 HD B.F. with UBL USERS INSTRUCTION • Carefully lay the Embaglow on top of shape No.1 , so it just rests on top without any of the strands touching or falling on the Pilot area, as this may cause ignition issues, please see picture. •...
  • Page 18 800 HD B.F. with UBL USERS INSTRUCTION • Place shape No.4 on top of the Left Hand burner pushing it to the Right, so it fits snug over the burner, make sure it sits flat and there are no Glass Chippings or Forge Embers underneath it. •...
  • Page 19 800 HD B.F. with UBL USERS INSTRUCTION • Place shape No.6 so it sits tight up against the front shape No.2 at the bottom so there is no gap , and rest the cut out on the underside over the end of shape No.5 •...

  • Page 20: Appliance Data

    800 HD B.F. with UBL USERS INSTRUCTION Appliance Data (installation instructions) Fire Box dimensions: Height 1022mm Width 813mm Forward Projection: 45mm Weight: 55kg Flue Length………………………………………...100mm (minimum) to 600mm (maximum) No bends or joined flue pipes should be used in the flue system. Pressure Test Point Location: Gas inlet elbow Gas Connection:...

  • Page 21: Regulations & Warnings

    800 HD B.F. with UBL INSTALLATION INSTRUCTION SECTION SIX Regulations and Warnings (installation instruction) • This appliance must only be installed in Great Britain or Ireland. • The appliance is available in natural gas only. • This appliance must be installed on a suitable outside wall. •...

  • Page 22: Siting The Appliance

    800 HD B.F. with UBL INSTALLATION INSTRUCTION Siting the Appliance (installation instructions) GENERAL REQUIREMENTS • The flue and air duct length must be between 100mm to 600mm. • The fire is supplied with a standard pipe length of 600mm. • The flue and air duct must not have any bends.

  • Page 23: Preparing The Appliance

    800 HD B.F. with UBL INSTALLATION INSTRUCTION Ensure that gas supply is suitably sited ALL DIMENSIONS IN mm • “B” Check with the supplier or manufacturer that the surround meets 150 C minimum rating (attention 820 MIN should especially be given to manmade materials 890 MAX.
  • Page 24 800 HD B.F. with UBL INSTALLATION INSTRUCTION MARK POSITION OF LINTEL MARKING OUT WALL FOR CENTRE LINE OF CAVITY RECESSED INSTALLATION INSTALLATIONS 605.00 1030 490.00 FLUE LINTEL CENTRE BASE OF OPENING HEARTH SURFACE LINE HEIGHT OR BASE LINE FOR HOLE IN WALL (150mm min. from floor) FLOOR SURFACE Using 150mm core drill cut a hole following the pilot holes.

  • Page 25: Connecting Gas & Power Supply

    800 HD B.F. with UBL INSTALLATION NSTRUCTION Connecting the Gas & Power Supply (installation instructions) TURN OFF ANY GAS APPLIANCES THAT ARE FED BY THE METER AND ISOLATE THE GAS SUPPLY BY TURNING OFF AT THE METER. • The Gas & Power supply must be assessed at this stage. •...

  • Page 26: Commissioning The Appliance

    800 HD B.F. with UBL INSTALLATION NSTRUCTION • The cable system consists of retro fitting plug sockets which offers the following options. (Please see below). Commissioning the appliance (installation instructions) CHECKING GAS SOUNDNESS AND RUNNING PRESSURE. • Turn on the supply to the appliance and check for soundness in accordance with the current codes of practice. •...

  • Page 27: Instruct & Advise Customer

    800 HD B.F. with UBL INSTALLATION INSTRUCTION Instruct and Advise the Customer (installation instructions) • Demonstrate the lighting and extinguishing procedure to the consumer/user and the removal and refitting of the trim for cleaning. • Explain that for the first few hours of the fire operating there will be an initial odour. This is due to the curing of the paint, the appliance should be operated on its high setting, and it is recommended that a window is left open until that odour has completely disappeared.

  • Page 28: Maintenance

    800 HD B.F. with UBL MAINTENANCE INSTRUCTION Maintenance Instructions General • Servicing should be carried out annually by a competent person such as a GAS SAFE-registered person in accordance with the relevant regulations, to ensure the safe and correct operation of the appliance. Warning: - Before commencing any service or replacement of parts, turn off the gas supply to the fire.
  • Page 29 800 HD B.F. with UBL MAINTENANCE INSTRUCTION Maintenance Instructions Before commencing any service or replacement of parts, turn off the gas supply to the fire. Removal of Burner Tray. ***** ***** A long Pozi Screw Driver will be required 1. Switch off the mains supply from the main supply plug socket. 2.
  • Page 30 800 HD B.F. with UBL MAINTENANCE INSTRUCTION Maintenance Instructions Replacement of the Pilot Injector. 1. Switch off the mains supply from the main supply plug socket. 2. Follow removal of Burner Tray (1 – 13). 3. Undo the pilot tube nut at the pilot bracket. 4.
  • Page 31 If the handset not pairing try breaking the power link from the transformer – then get the handset to pairing stage and then reconnect the transformer When ordering parts quote ` INFINITY 800HD BF UBL ` and the serial number of the fire, which can be found on the data badge on bottom left hand side of fire. (Refer to cleaning instructions for trim removal.

  • Page 32: Fault Finding Charts

    800 HD B.F. with UBL FAULT FINDING INSTRUCTIONS FAULT FINDING CHARTS LT 8381 (ISS 01)
  • Page 33 800 HD B.F. with UBL FAULT FINDING INSTRUCTIONS FAULT FINDING CHARTS www.charltonandjenrick.co.uk LT 8381 (ISS 01)
  • Page 34 800 HD B.F. with UBL FAULT FINDING INSTRUCTIONS FAULT FINDING CHARTS LT 8381 (ISS 01)
  • Page 35 For further information please contact the Infinity help desk on 0845 5195991 or visit our web site www.CharltonandJenrick.co.uk. Important For future reference we suggest you record the following details here, and keep the receipt as proof of purchase. This information may be asked for when you contact the helpdesk. Model 800 HD B.F.

  • Page 36: Service Log

    Service Log Details It is essential that your gas fire is serviced regularly and that the appropriate Service Interval Record is completed. Service Provider Before completing the appropriate Service Record below, please ensure you have carried out the service as described in the manufacturer’s instructions. Always use the manufacturer’s specified spare part when replacing controls.
  • Page 37 Register your appliance online today to activate your warranty www.charltonandjenrick.co.uk LT 8381 (ISS 01)

  • Page 38: Gas Fire Commissioning Checklist

    BALANCED FLUE GAS FIRE COMMISSIONING CHECKLIST This Commissioning Checklist is to be completed in full by the competent person who commissioned the gas fire as a means of demonstrating compliance with the appropriate Building Regulations and then handed to the customer to keep for future reference. Failure to install and commission according to the manufacturer’s instructions and complete this Benchmark Commissioning Checklist will invalidate the warranty.
  • Page 39 www.charltonandjenrick.co.uk LT 8381 (ISS 01)
  • Page 40 LT 8381 (ISS 01)

  • Page 41: Register Your 12 Month Warranty

    Register Your 12 Month Warranty with Us Today www.charltonandjenrick.co.uk/warranty. To register your appliance at Installer Details Name Company name Gas safe number Date of installation Your Details Name Address Post Code Telephone No Product Details Model : 800HD B.F. with UBL Serial No Date Of Purchase This information can be found on the label attached to the packaging and on the data badge.
  • Page 42 LT 8381 (ISS 01)
  • Page 43 www.charltonandjenrick.co.uk LT 8381 (ISS 01)
  • Page 44 A-0829 – Glass liners Product ID Label Serial No Prefix A-0834 – Red Brick Liners (NG) A-0835 – Vermiculite Liners Data Badge Burner Tray / Box Assembly Air Test Completed Warning Label (1409) Grommet (1406) Glass Panel Silicone Sealing Strip (4818) x 2 800 BF Log Set Fireplace Outer Frame Fireplace Inner Frame...
