Page 1: Installation Instructions
Homeowner’s Installation Instructions & Operating Manual Model: EF16NC Please read the instructions carefully before installation or use of this electric fire, retain for future reference. -
Page 2: Appliance Data
IMPORTANT INFORMATION This heater must not be located immediately below a socket-outlet. This heater must be earthed. If in any doubt consult a suitable competent person. In order to avoid a hazard due to inadvertent resetting of the thermal cut-out, this appliance must not be supplied through an external switching device, such as a timer, or connected to a circuit that is regularly switched on and off. -
Page 3: Parts And Hardware List
PARTS AND HARDWARE LIST Part Quantity Instruction Manual 1pcs Remote Control 1pcs AAA Battery 2pcs Screw ST5×25 4pcs Drywall Anchors Φ8×40 4pcs Plastic Shelf (for alternative fret shape) Clear Beads 1set Decorative Logs 1set Washed Natural Coal 1set INSTALLATION NOTE: Do Not use this Electric Fireplace if any part has been under water. - Page 4 Installation of Insert: Keyhole Keyhole slots slots Step1: Carefully mark out the 4 fixing screw Step3: Fit 4 screws ST5×25 leaving positions as above (positions for fixing approximately 2mm between the panel screw) and the underside of the screw head. Step4: Lift the insert into position so the Step2: Fixing to masonry, drill 4pcs Φ8 holes keyhole slots locate on the screw heads.
-
Page 5: Operation
For the Other Fret Options, it may be necessary to change to Opaque Plastic shelf to suit better the fret shape：If it is needed to replace the plastic shelf do it before the installation of the insert from step1 to step5 as above. Step6.2: To change the Opaque Plastic Shelf remove the 4 screws as shown, remove shelf and replace fixing back in position with original screws Then lay the fuel bed on the opaque surface using the Decorative Logs or the Washed... - Page 6 NOTE: To use both remote and manual functions the main on/off switch must be in the ‘on’ position. Operating by Manual Button Power Button Flame Button Heater Button Main Switch NOTE：The flame will always be on when the appliance is on. Main switch The main switch supplies power to all of the functions of the fireplace.
-
Page 7: Maintenance
Multifunction Infrared Remote Handset To Reset the Heater Your heater includes a protection system that shuts off the heater if it overheats for any reason: 1) Turn unit to “off”. 2) Unplug unit wait 5 minutes. 3) Plug in and turn “on”. ICON TITLE FUNCTION... - Page 8 Resetting the Thermal Cut-out Switch The appliance is fitted with an Electronic Safety Control (E.S.). This is a safety device, which switches off the fire if, for any reason, the appliance overheats, e.g. when covered. If the heater stops operating whilst the flame effect continues normally, this indicates that the E.S.
