Charlton & Jenrick 2000 Plus Extra Remote Owner's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Owner's Manual
INCLUDES
User, Maintenance, Service, and Installation
Instructions
2000 Plus Extra Remote
Keep this booklet for service log and future reference
IMPORTANT
This appliance is guaranteed for 12 months subject to conditions. The 5 year extended parts
warranty will only be valid if the annual service recommended in this manual has been
completed and appliance has been registered online.
For use in Great Britain and Ireland.
Literature NO 6312 (ISS 3)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2000 Plus Extra Remote and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Charlton & Jenrick 2000 Plus Extra Remote

Summary of Contents for Charlton & Jenrick 2000 Plus Extra Remote

  • Page 1 Owner’s Manual INCLUDES User, Maintenance, Service, and Installation Instructions 2000 Plus Extra Remote Keep this booklet for service log and future reference IMPORTANT This appliance is guaranteed for 12 months subject to conditions. The 5 year extended parts warranty will only be valid if the annual service recommended in this manual has been completed and appliance has been registered online.
  • Page 2 Contents EXTENDED FIVE YEAR PARTS WARRANTY ....2 Benchmark Scheme ............. 3 SECTION ONE Introduction (user instructions) ..5 EXTENDED FIVE YEAR PARTS SECTION TWO Operating the Appliance (user WARRANTY instructions) ..............8 SECTION THREE Fuel Bed Cleaning and Layout (user In order to validate your extended 5 years parts instructions) ...............

  • Page 3: Benchmark Scheme

    Benchmark Scheme Charlton and Jenrick Ltd is a licensed member of the Benchmark Scheme which aims to improve the standards of installation and commissioning of domestic heating and hot water systems in the UK and to encourage regular servicing to optimise safety, efficiency and performance. Benchmark is managed and promoted by the Heating and Hotwater Industry Council.
  • Page 4 For future reference we suggest you record the following details here, and keep the receipt as proof of purchase. This information may be asked for when you contact the helpdesk. MODEL: 2000 Plus Extra Remote Serial No. This information can be found on the label attached to the packaging and on the data badge, which is located on the base of the appliance behind the control cover.

  • Page 5: Section One Introduction (User Instructions)

    SECTION ONE Introduction (user instructions) Consumer Protection Information As manufacturers and suppliers of heating products, we take every care, as far as is reasonably practicable, that these products are so designed and constructed as to meet the general safety requirement when properly used and installed.
  • Page 6 The PARAGON 2000 Xtra Remote is battery operated; therefore no mains electrical supply is required. Power to the appliance is provided by 6 high power alkaline 1.5V batteries (AA size) (a spare set of 6 AA batteries is supplied with the appliance); these batteries can be changed to Nickel Metal Hydride rechargeable batteries providing they have a minimum capacity of 2200 mAh.
  • Page 7 Warning:- This appliance has a naked flame, has with all fires it is recommended that a fireguard should be used for the protection of children, the elderly and infirm. Fireguards should conform to BS 6539 (1984) (fireguards for use with solid fuel appliances). During the normal operation of the fire some black staining may appear on some parts of the fuel bed.

  • Page 8: Section Two Operating The Appliance (User Instructions)

    SECTION TWO Operating the Appliance (user instructions) Before attempting to operate the appliance check that nothing has been placed in front of the appliance that may interfere with the remote sensor operation. To light the appliance using the remote hand set: A.
  • Page 9 Low Battery Indication (Hand Set) If while pressing any of the buttons on the remote hand set the low battery indicator lamp either stops flashing or appreciably slows then the battery should be changed. To Replace Batteries In Hand SET (AAA 1.5 v lr3 X 2) Remove the cover from the rear of the handset and fit replacement batteries, taking care not to strain the battery connections.

  • Page 10: Section Three Fuel Bed Cleaning And Layout (User Instructions)

    SECTION THREE Fuel Bed Cleaning and Layout (user instructions) Important: - Refer to the Health & Safety Notice located on page 5 of this booklet before cleaning or replacing any refractory material. The fuel bed components are delicate and they should be handled with great care. The loose parts and moulded shapes may be removed for cleaning.
  • Page 11 Note the loose coal provided consist of :-  5 off shaped as coal "A"  9 off shaped as coal "B" Separate the coal into the two size groups  Lay first row of loose coal 4 off "B" and 2 off "A"...
  • Page 12  Lay third row of loose coals “B” and “A” shapes as shown. FUEL BED LAYOUT (PEBBLE OPTION) Pebble identification Fuel Bed Components Heart Shape  Base Matrix Oblong Shape  L & R Front Pebbles  Large Shape Number Pebbles as below:- Medium Shape Small Shape Total...
  • Page 13  Locate the LEFT HAND and RIGHT HAND FRONT PEBBLES as shown so that they sit on the front rail and lean back against the BASE MATRIX. Note it is most important that they are located in their correct positions. They are marked on the rear "L"...

  • Page 14: Section Four Important Information (User Instructions)

     Lay another row of loose pebbles as shown. SECTION FOUR Important Information (user instructions) The only user removable parts are: -   The loose coals . The base matrix   The left hand front coal shape. Cast Fret ...

  • Page 15: Section Five Specification (Installation Instructions

    SECTION FIVE Specification (installation instructions) NATURAL GAS Category of Appliance: Category Gas type: Gas Pressure: 20 mbar Gas input high: 7.00 kW Gross Gas input low: 2.40 kW Gross Injector Main: Size 460 Oxy-pilot NG9102 Battery Remote handset 1.5 V AAA LR3 X2, Appliance 6 x 1.5V AA high power alkaline or 6 x 1.5 V Rechargeable nickel metal hydride with a minimum capacity of 2200mAh.

  • Page 16: Section Six Regulations And Warnings (Installation Instructions)

    SECTION SIX Regulations and Warnings (installation instructions)  THIS APPLIANCE MUST ONLY BE INSTALLED IN THE GB OR IRELAND.  Only to be used in sufficiently ventilated room. Read instructions carefully before installation and use. The appliance must be installed by a competent person, i.e.. Gas Safe Registered Installer in accordance with the current Gas Safety (Installation and Use) Regulations 1998 (as amended).

  • Page 17: Section Seven Siting The Appliance (Installation Instructions)

    SECTION SEVEN Siting the Appliance (installation instructions) The fire can be installed in the following flues and locations: - CLASS ONE A conventional brick or stone chimney as used for a solid fuel appliance with a typical effective cross-sectional dimension of 225 x 225 mm (9 x 9 ins) or a lined flue with a minimum diameter of 125 mm (5 ins) "A"...

  • Page 18: Section Eight Fireplace Requirements (Installation Instructions)

    CLASS TWO FABRICATED METAL A double-walled or insulated metal flue box built to the requirements of BS 715 with an insulated flue having a minimum diameter of 125 mm (5 ins) and a minimum effective overall height of 3 metres (10 ft). IMPORTANT: - the flue restrictor plate must be removed when the appliance is installed in this type of flue.
  • Page 19 Consideration should be given to the location of the appliance ensuring it is very visible and it should be positioned at a height were it can clearly be seen on approach. Frets, and Fascias used for HOLE in the WALL must be compliant with Paragon Fires CE approval; these are listed at the end of this page.

  • Page 20: Section Nine To Install The Appliance (Installation Instructions)

    VENTILATION In the United Kingdom no special ventilation bricks or vents are required into the room containing the appliance, provided normal adventitious room ventilation exists. The installer must satisfy this point by carrying out a mandatory spillage test. In the Republic of Ireland permanent ventilation must comply with the rules in force SECTION NINE To Install the Appliance (installation instructions) EXAMINE FLUE / CHIMNEY Check that the flue/chimney conforms to the required specifications as previously stated.
  • Page 21 FIXING FIRE INTO OPENING Remove the paper backing from the length of foam seal and stick it around the rear flange of fire. If a spacer is going to be used stick the second length (supplied with the spacer kit) around the rear face of the spacer unit, THE FOAM SEAL MUST BE POSITIONED TO ENSURE AN AIR TIGHT SEAL WHEN THE APPLIANCE IS FITTED.
  • Page 22 CHECKING GAS SOUNDNESS *Batteries must be connected before proceeding with any soundness testing* After completing the gas connection to the appliance, check for gas soundness in accordance with current codes of practice. FUEL BED LAYOUT Important: - Refer to the Health & Safety Notice located on page 5 of this booklet before cleaning or replacing any refractory material.
  • Page 23 CHECKING OPERATION OF FIRE  Remove ash pan cover.  Remove the screw from the pressure test point on the inlet elbow and fit pressure gauge.  Turn on the gas to the appliance.  Purge the air from the appliance by operating the appliance (see Section 2). The appliance will spark for approximately 20 second at which point if no ignition is detected the appliance will go to lock out and you must repeat the ignition procedure.
  • Page 24 SECTION TEN Maintenance Instructions (maintenance instructions) Important: - Refer to the Health & Safety Notice located on page 5 of this booklet before cleaning or replacing any refractory material.  Servicing should be carried out annually by a competent person such as a Gas Safe-registered person in accordance with the relevant regulations, to ensure the safe and correct operation of the appliance.
  • Page 25 REPLACEMENT OF INJECTOR 1. Repeat operations 1-7 for removal of gas control. 2. Undo the two screws retaining the silencer bracket. 3. Lift away the silencer; noting its position the cut out slot pointing down, it must be put back in exactly the same orientation.

  • Page 26: Section Nine Wiring Diagram (Maintenance Instructions)

    SECTION NINE Wiring Diagram (maintenance instructions) Attach to the valve www.charltonandjenrick.co.uk LT6312 (ISS 3)
  • Page 27 6312 (ISS 3)
  • Page 28 www.charltonandjenrick.co.uk LT6312 (ISS 3)
  • Page 29 Register your appliance online today to active your warranty 6312 (ISS 3)

  • Page 30: Gas Fire Commissioning Checklist

    GAS FIRE COMMISSIONING CHECKLIST This Commissioning Checklist is to be completed in full by the competent person who commissioned the gas fire as a means of demonstrating compliance with the appropriate Building Regulations and then handed to the customer to keep for future reference.

  • Page 31: Service Record

    SERVICE RECORD It is essential that your gas fire is serviced regularly and that the appropriate Service Interval Record is completed. Service Provider Before completing the appropriate Service Record below, please ensure you have carried out the service as described in the manufacturer’s instructions.
  • Page 32 Serial A-0318 Product ID Label Prefix Fire Box Labels: Restrictor Plate Spillage (Text) Data Badge Fire Box Grommet Burner Tray / Box Assembly Warning Label (Fire Guard) Cable Clips(1 Alum,1 Plastic) Ceramics Set (Part no 5568) Fixing Kit (0705) Canopy (Part No 5003) Restrictor Elbow (male) AAA 1.5V LR3 Batteries x 2 Remote Control (Hand Set)
