CONTENTS GENERAL INSTRUCTIONS ..............................3 PLACING THE APPLIANCE ..............................3 Preparation and placement ........................3 Connection to the gas supply pipes ......................3 INSTALLATION OF THE CERAMIC WOOD SET AND DISPERSION MEDIUM ............6 TECHNICAL DETAILS MAXITROL GV60 ..........................8 INSTRUCTIONS FOR MAXITROL GV60........................10 GAS-TECHNICAL SPECIFICATIONS ..........................11 CONCENTRIC PATHWAYS ..............................13 CONCENTRIC FLUE SYSTEM ............................14 Components of the concentric flue system ..................14...
GENERAL INSTRUCTIONS NOTE • Ignite the appliance according to the user manual and check The installation may only be carried out by an authorised the flame is burning evenly. After the appliance has been person. used for the first time, any deposits resulting from curing must be removed from the glass panel using a glass cleaner •...
Page 4
Remove the glass panel Put the appliance in its place taking into account the distances from (non-)combustible materials described in Chapter • Remove the cover frame. Slide the cover frame upwards 1 General instructions. and remove the cover frame from the appliance forwards. 1 1 2 1 The concentric flue system can then be fitted, see Chapter •...
Page 5
• Remove these 4 screws and remove the glass panel frame. • The glass panel can now be removed. • Place the glass panel in a safe place so that it does not fall and/or become damaged. NOTE Hold the glass panel to make sure it cannot fall forward. Refitting the glass panel Refitting the glass panel is done in the reverse order.
INSTALLATION OF THE CERAMIC WOOD SET AND DISPERSION MEDIUM First, distribute the glow granules evenly over the central Place the charred log trunk in front of the pilot flame. burner. Ensure it is correctly put in place . NOTE Handle the logs carefully, the ceramic material is very fragile •...
Page 7
Restrictor and baffle plate The restrictor and/or baffle plate can be mounted inside the appliance, at the location of the flue gas duct. Chapter 7 Concentric pathways contains a table describing if a baffle plate and/or restrictor must be fitted. This is important to ensure the appliance works correctly.
TECHNICAL DETAILS MAXITROL GV60 Gas valve type Maxitrol GV60 M1 Automatic ignition control type B6R-R8P (Wifi Ready) Ignition Remote control operation and piezo ignition 3/8″ (External) = Gas inlet = Gas outlet = Thermocouple connection Gas connection = Pilot burner connection Appliance category C11-C31-C91 Pilot flame...
Page 9
Pilot flame connection Thermocouple connection Gas inlet Gas outlet Supply pressure Burner pressure Installation instruction Trimline Zircon...
INSTRUCTIONS FOR MAXITROL GV60 WARNING NOTE • Ensure the fuel supplied to the appliance is clean and free • Do not tighten the contact breaker and the thermocouple from particles and moisture. connection too tightly on the gas valve. • The appliance must not be turned on if the glass pane(s) is •...
GAS-TECHNICAL SPECIFICATIONS Type of indication(s) 1120 - Free Standing Appliance type C11, C31, C91 closed combustion Concentric extraction system Holetherm CC 100-150 Gas type G25,3 G20/25 G20D25 Supply pressure in mbar 20D25 Country AT/CH/CZ/DE/DK/ BE/FR EE/ES/FI/GB/GR/ HR/IE/IT/LT/LU/ LV/ NO/PL/PT/RO/SE/ SI/SK/TR Category (43,46-45,3 MJ/m Primary air per burner...
Page 12
Type of indication(s) Trimline Zircon 1024 Appliance type C11, C31, C91 closed combustion Concentric extraction system Holetherm CC 100-150 Gas type G30/31 Supply pressure in mbar (28-30)-37 30/50 Country BE/CH/CY/CZ/ES/FR/GB/GR/IE/IT/LT/PT/ NL/AT/CH/CY/CZ/DE/DK/EE/FI/GR/HR/ SI/TR HU/IT/LT/NO/PL/RO/SE/SI/TR Category Primary air per burner L=4xØ7,5 M=3xØ16 R=4xØ7,5 L=4xØ7,5 M=3xØ16 R=4xØ7,5...
X total in metres Y total in metres Restriction x = vertical and y = horizontal Min* Max* Min* Max* Trimline Zircon 1024 Indirect façade outlet G20/25 – Indirect façade outlet G30/G31 – Roof pass-through without slope From 3 meter –...
CONCENTRIC FLUE SYSTEM The concentric flue system is composed of an inner flue and • The flue should be encased if necessary. Even if the flue an outer flue. These flues have been set up concentrically so is to be installed along non-refractory materials, sufficient the combustion gases will be discharged via the internal flue fire-resistant measures must be taken.
8.4 Parts Check all parts for damage before commencing the installation. For the conversion of a brick flue to concentric flue, connected to CC flue system, you need the components described in appendix 2. NOTE The renovation/sanitation set consists of parts: 3 Interior mounting plate 4 Sliding element 7 Chimney mounting plate...
PASS-THROUGH POSITIONS AND FUNCTION CORRECTLY Roof pass-through External extension pipe Plot boundary Dimensions Outlet positions Distance mm Distance to ventilation openings Room* Distance to ventilation openings Room* Distance to ventilation openings Room* Lower gutter bottom pipes or exhaust lines Under the eaves Under a carport, roof or balcony, inside and outside corners From ground level and rainwater drainage pipes Inside and outside a corner...
10 CLEANING AND MAINTENANCE This appliance must be inspected and maintained at least 5 The pressure release mechanism is located at the front 2, once a year by a qualified, licensed and registered person. at the top of the combustion chamber. Proceed as follows As a minimum, the inspection and maintenance must be to remove the gasket: carried out to ensure the appliance works correctly and safely.
Page 18
Glass cleaning instructions Important Do not use any of the following cleaning agents: • Hard or abrasive sponges, steel wool, abrasives • Cleaning agents with ammonia or acid (even citric acid) • Paper towels, ceramic hob cleaner. Only use Water or a suitable detergent surfactant. We recommend our thermCet Cleaner set.
11 QUICK REFERENCE GUIDE FOR FAULTSSEARCH FOR ENCLOSED APPLIANCES USING MAXITROL GV60 GASCONTROL Function Possible cause Solution 1. Acoustic signals Set switch to (I) 1 long beep reset switch OFF (0) 1 long beep connections not complete Check connections in thermocouple circuit Check connections in connector/replace 1 long beep ...
Page 20
Function Possible cause Solution 7. Pilot light goes out when the False air along pilot flame holder/gasket Check pilot flame holder and gasket for leaks appliance is closed False air hatches Check pressure hatches/gasket is completely closed Main flame causes pilot flame to go out Check restrictor/baffle in accordance with regulations 8.
Appendix 2 CONSTRUCTION DIAGRAM DOUBLE-WALL CONCENTRIC Material: Stainless steel AISI 316 L - Allow number 1.4404 Application: for the discharge of flue gases and the supply of combustion air from gas-fired appliances or stoves with a closed combustion system Roof pass-through Roof pass-through Storm collar Lead flashing Roof mounting bracket...
