DISPLAY
Display Type:
Scale Length:
Annunciators:
Reading Rate:
Overrange:
GENERAL
Power:
RS232 Interface:
Operating Range:
Storage Range:
Environmental:
Safety:
EMC:
Size:
Weight:
4
High brightness LED. Height 0·56" (14mm).
4¾ digits (40,000 counts); AC ranges 4,000 counts.
For all ranges, functions and program modes.
2·5 readings/sec.
Display shows OFL if input too great for range.
115/230 Volts AC nominal 50Hz, adjustable internally; operating range
±14% of nominal; 3VA max. Installation Category II. 60Hz operation is a
factory option.
Baud Rate 9600. Permits remote control and data-logging to disk using
optional Windows software.
+5°C to + 40°C, 20% to 80% RH.
-40°C to + 70°C.
Indoor use at altitudes up to 2000m, Pollution Degree 1.
Complies with EN61010-1.
Complies with EN50081-1 and EN50082-1.
260(W) x 88(H) x 235(D)mm, excl. handle and feet.
2·0kg.
