ACCURACY
Accuracies apply for 1 year 19°C to 25°C. Temperature coefficient outside these limits is
<0·1 x quoted range accuracy per °C.
DC Volts
Range
400mV 0·08% ± 4 dig.
4V 0·08% ± 4 dig.
40V 0.08% ± 4 dig.
400V 0·08% ± 4 dig.
1000V 0·09% ± 4 dig.
AC Volts (True RMS)
Range
400mV
4V
40V
400V
750V
Accuracies apply for readings between 400 and 4,000 counts. Additional error at crest
factor = 3 is typically 1%. Input impedance = 10MΩ nominal.
1kΩ unbalanced CMR = >60dB at DC/50Hz/60Hz
Max. input = 750V rms, 1kV pk. (265Vrms on 400mV range).
Resistance
Range
400Ω
4kΩ
40kΩ
400kΩ
4MΩ
40MΩ (up to 20MΩ)
40MΩ (up to 40MΩ)
∗ after Null
2
Accuracy Resolution
10µV
100µV
1mV
10mV
100mV
45Hz - 400Hz
0·5% ± 4 dig
1%#± 4 dig.
Accuracy
0·15% ± 6 dig.∗
0·1%#± 4 dig.
0·1%#± 4 dig.
0·15% ± 4 dig.
0·3%#± 6 dig.
1·0%#± 10 dig.
2·0%#± 10 dig
Notes
265V DC/AC rms max
Max input 1000V
DC/AC pk.
Accuracy
400Hz - 4kHz 4kHz - 20kHz
1% ± 4 dig. 2% ± 4 dig.
2% ± 4 dig 5% ± 4 dig.
-
-
†
.
Resolution
10mΩ
100mΩ
1Ω
10Ω
100Ω
1kΩ
1kΩ

Specifications

Input impedance 10MΩ nominal
NMR:>60dB @ 50/60Hz
CMR:>90dB @ DC/50Hz/60Hz
Resolution
-
-
Notes
Max. input 265V DC or ACrms any range.
Max. open circuit voltage 4V.
†
60Hz rejection is a factory option.
†
†
100µV
1mV
10mV
100mV
1V
