  • Page 1 THURLBY THANDAR INSTRUMENTS PSA-T Series PSA1301T & PSA2701T INSTRUCTION MANUAL 1.3GHz & 2.7GHz RF Spectrum Analyzers...

  • Page 2: Table Of Contents

    Table of Contents 1.Supplied Items 2.Using This Manual & Meaning of Terms 3.Initial Operations 3.1. Charging the Batteries 3.2. Initialising the Palm T|X 3.3. Software provided by Palm on CD 3.4. Linking to a Personal Computer 4.First Use of the Spectrum Analyzer 4.1.
  • Page 3 14.Re-initialising the Palm T|X 14.1. Procedure for Re-Initialising 14.2. Technical Note about the OFF state 15.Language Choice for the Palm T|X 16.Turning On and Turning Off 16.1. Palm T|X On/Off 16.2. PSA1301/2701 On/Off Control 16.3. Operation Delay after Turning On 17.Battery and AC Power 17.1.
  • Page 4 20.3. Performing Sweeps 20.4. Level Measurements 20.5. The PRESET Key 20.6. Using Markers 20.7. Reference Trace 20.8. Store, Recall and Copy 20.9. Creating and Displaying Limit Lines 20.10. Screen Resolution and Trace Thickness 20.11. Changing the Palm Input Area type 20.12.

  • Page 5: Supplied Items

    1. Supplied Items The PSA1301T or PSA2701T portable spectrum analyzer is made up of three main items: The PSA1301/PSA2701 spectrum analyzer unit manufactured by TTi and incorporating a Palm T|X handheld computer. The PSAnalyzer software application created by TTi to run on the Palm T...

  • Page 6: Software Provided By Palm On Cd

    CD software immediately as part of the initial set up. Users of the PSA1301/2701T do not need to do this unless they choose to. TTi recommends that users read the relevant sections of the Palm documentation and consider their own use of the product before deciding whether to install to Palm software.

  • Page 7: Detailed Operating Guide

    2700MHz (PSA2701T). The span can be set anywhere between 0.320 MHz and 1299.850 MHz (PSA1301T) or 2699.000 MHz (PSA2701T) with a resolution of 1kHz. Start, stop or centre frequencies can be set to the same resolution. The resolution bandwidth is selectable as 280 kHz or 15 kHz...
  • Page 8 The on-screen amplitude range is 80 dB with a reference level of -20dBm or 0dBm. Amplitudes can alternatively be displayed in dBµV. Vertical magnification to 5dB/div can be selected. Average noise floor is better than -90dBm at -20dBm reference level and 15 kHz RBW. Sweeps can be continuous, single shot, peak hold or average (2 to 256 sweeps).

  • Page 9: Specification

    6. Specification 6.1. Frequency Measurement Frequency Span Frequency Range: 150 kHz to 1300 MHz in one range (PSA1301) 1 MHz to 2700 MHz in one range (PSA2701) Setting Modes: Centre frequency plus Span, or Start frequency plus Stop frequency Maximum Span: 1299.85 MHz [150 kHz to 1300 MHz] (PSA1301) 2699 MHz [1 MHz to 2700 MHz] (PSA2701) Minimum Span:...

  • Page 10: Sweep

    Amplitude Accuracy Ref. Level Accuracy: Better than ± 1 dB at 50MHz at 10dB below reference level (20 C ± 5 Level Flatness: Better than ± 1.5 dB relative to 50MHz over 500kHz to 1300MHz (PSA1301) Better than ± 1.5 dB relative to 50MHz over 1MHz to 2700MHz (PSA2701) Amplitude Linearity: Better than ±...

  • Page 11: Signal Input

    6.4. Signal Input Input Connector: SMA connector, 50 Ohms VSWR: 1.5:1 typical Absolute Maximum + 20 dBm or +127 dBµV (2.2V rms) or 15V dc Input Level: 6.5. Demodulation (Zero Span mode) Demod. Modes: AM or FM Display: Carrier amplitude only (horizontal line). Audio Out: 30 mW into 32 Ohms mono or stereo headphones, adjustable volume, 3.5mm jack socket ( marked...

  • Page 12: Connectors

    3.5 mm jack socket for demodulated audio out (accepts mono or stereo plugs). 6.9. Power Sources AC Line Operation/Charging The PSA1301/2701T can be operated from mains power using the AC power adaptor provided by TTi. This powers and recharges both the Spectrum Analyzer and the Palm T X simultaneously.

  • Page 13: Mechanical

    6.10. Mechanical Size: 170mm high x 97mm wide x 47mm deep (including feet) Weight: 495 grms total including Palm T|X. Tilt Stand: Built-in tilt stand for bench use which angles the unit at approximately 25 degrees to the horizontal and can alternatively be used as a hook mount. 6.11.

  • Page 14: Declaration Of Conformity

    Cambridgeshire PE29 7DR England declare that the PSA1301T and PSA2701T Portable RF Spectrum Analyzers meet the intent of the EMC Directive 2004/108/EC and the Low Voltage Directive 2006/95/EC. Compliance was demonstrated by conformance to the following specifications which have been listed in the Official Journal of the European Communities.

  • Page 15: Emc

    8. EMC Spectrum Analyzer This instrument has been designed to meet the requirements of the EMC Directive 2004/108/EC. Compliance was demonstrated by meeting the test limits of the following standards: Emissions EN61326 (2006) EMC product standard for Electrical Equipment for Measurement, Control and Laboratory Use.

  • Page 16: Safety

    Safety Spectrum Analyzer This instrument is Safety Class III according to IEC classification and has been designed to meet the requirements of EN61010-1 (Safety Requirements for Electrical Equipment for Measurement, Control and Laboratory Use). This instrument has been tested in accordance with EN61010-1 and has been supplied in a safe condition.

  • Page 17: Connections

    DC power to operate and/or recharge the instrument is connected via a 1.3mm power socket mounted on the side of the instrument. Use ONLY the mains adaptor provided by TTi with the unit. Use of any other power source will void the warranty.

  • Page 18: Stylus

    Note that the maximum card size useable with the Palm T|X is 2GB. Note: The original card should be retained as it contains an important utility and a backup of the PSAnalyzer application. This card is labelled with the TTi logo and with the version number of the supplied PSAnalyzer software.

  • Page 19: Card Storage Capacity

    12.3. Card Storage Capacity The size of the memory card supplied by TTi may vary from time to time, but will be in the range 512MB to 2GB. The size if the files stored by PSAnalyzer are very small in comparison. Set-up files are a few hundred bytes each, trace files are around six kilobytes each, and screen bitmap files are 120 kilobytes each.

  • Page 20: Re-Initialising The Palm T|X

    14. Re-initialising the Palm T|X Whenever the battery of the Palm T X has been allowed to completely discharge (as is normally the case when it is first received) it will be necessary to re-initialise it. 14.1. Procedure for Re-Initialising Charge the Palm T X in the normal way.

  • Page 21: Turning On And Turning Off

    16. Turning On and Turning Off 16.1. Palm T|X On/Off General The Palm T X can be turned ON in either of two ways: by pressing the green button on the top edge, or by pressing any of the four keys below the display. Using the green button returns to the application in use when it was turned off.

  • Page 22: Battery And Ac Power

    PSA1301/2701T. If the batteries require re-charging, this will be done automatically and charging terminated at the appropriate point. Use only the AC power adaptor provided by TTi. Use of any other power source could cause damage and will void the warranty.

  • Page 23: Extended Periods Without Use

    17.3. Extended Periods Without Use If the unit is left unused for extended periods, the batteries of both the Palm T|X and PSA1301/2701 will gradually discharge. If the internal battery of the Palm T | X discharges beyond a certain point, re- initialisation will be necessary, see section 14 .

  • Page 24: The Psanalyzer Screen

    Hard Key Only Operation Some users may prefer never to use the touch screen. PSAnalyzer allows all functions ** to be operated using only the hard keys. Each function is selected from the on-screen menus by scrolling through the keys using the 5-way navigator and pressing the central button. The currently selected key is shown by either a darker colour, or by a coloured outline.

  • Page 25: Turning Off / Power Saving

    18.6. Turning Off / Power Saving When operating from batteries the unit should be turned off when not in use. Press and hold the Back (Home) key. The display will go off, the status of the instrument is not lost and all data is retained apart from any running sweep.

  • Page 26: Mode Menu

    Level: set reference level (by turning attenuator on or off); select display units (dBm or dBµV); select vertical zoom and pan. Markrs: set marker(s) on/off and position markers manually or automatically. Sweep: select sweep mode (Single, Normal (continuous), Peak Hold or Average), set RBW (resolution bandwidth).

  • Page 27: Step Value Sub Menu

    Set C = M1: sets the centre frequency equal to the frequency at the position of Marker One, and moves the marker to the centre of the graticule. Set by Keybd: this opens a 0 to 9 numeric entry keypad. Keys can be pressed directly (with finger tip or stylus) or operated with the five way navigator.

  • Page 28: Start Frequency Menu

    Span = M delta: sets the span equal to the absolute value of frequency difference between the two marker positions.. Set by Keyboard: Set by Tab/Jog: These two keys operate in the same manner as described for the Centre menu, see section 19.4. To exit this menu and return to the home menu press the Back (Home) hard key, or the grey area at the top left of the menu.

  • Page 29: Am/Fm Menu

    19.9. AM/FM Menu This menu controls the settings for demodulated audio in Zero Span mode, which can be Off, AM, or FM. The demodulated audio is outputted from the 3.5mm stereo/mono jack socket. Audio Volume: to change the volume press the Audio Volume key and use the up and down keys of the five way navigator to change the volume level (range 1 to 16).

  • Page 30: Sweep Menu

    Move Markers Left or Right - press the left and right navigator keys to scroll the selected marker. Auto speed-up is provided. Alternatively press the screen at the point that you want the selected marker to move to. Find next Peak - press the up or down navigator keys to move the selected marker to the next higher or next lower amplitude peak.

  • Page 31: Traces Menu

    19.13. Traces Menu This menu allows the live trace and the reference trace to be turned on and off and the live trace to be copied to the reference trace. It also allows the screen resolution for the trace area to be changed, and the video filter function to be turned on or off.

  • Page 32: System Menu

    Calib.: press to enter instrument calibration mode. Re-calibration can only be undertaken with specialised equipment and in conjunction with the Service Manual which is available from TTi. To exit this menu and return to the home menu press the Back (Home) hard key, or the grey area at...

  • Page 33: Exit Menu

    19.16. Exit Menu This menu allows you to exit from the PSAnalyzer application or suspend the application (sleep mode); and to view information about the application Info.: Read a summary of the capabilities and specifications of the spectrum analyzer. About: view information about this application (e.g. version number) Sleep: turn off the application to save power - all current settings and data are retained.

  • Page 34: Psanalyzer Operating Techniques

    RBW: toggle the resolution bandwidth between 280 kHz and 15 kHz (PSA1301T) or between 1 MHz, 280 kHz and 15 kHz (PSA2701T). The value is displayed at the top right of the graticule area. Atten. On/Off: toggle the attenuator between On (reference level = 0dBm) and Off (reference level = - 20dBm).
  • Page 35 20.2.2. Centre Menu Shortcuts Set Centre to Marker: To re-centre the sweep to a new position within the currently visible sweep, move the marker (M1) to the desired position and press Set C = M1. Step Up / Step Down: The centre frequency can be moved in fixed steps (settable between 1kHz and 100MHz) by these two keys.

  • Page 36: Performing Sweeps

    20.3. Performing Sweeps Frequency sweeps are started and stopped using the hard keys Run and Stop. The Sweep menu permits four different sweep types to be selected, and allows the resolution bandwidth to be changed, see section 19.12. The Stop key halts the sweep at any time and holds the trace. The Run key initiates a new sweep and also resets Averaging and Peak Hold sweep modes.

  • Page 37: The Preset Key

    An overload indicator is provided to show this condition. The indicator is a red upwards pointing arrow near the top of the graticule. The absolute maximum signal level that can be applied without damage is specified as +20dBm or 127dBµV (approx. 2.2V rms). The display can be vertically expanded using the Zoom/Pan function.

  • Page 38: Reference Trace

    20.7. Reference Trace A reference trace (in purple) is available in addition to the live trace. See Traces menu, section 19.13. The reference trace can be copied directly from the live trace, or recalled from a memory store. Both the reference trace and the live trace can be toggled on or off from within the traces menu. Note: If the sweep parameters (start/stop or centre/span) are different from their values when the reference trace was captured, the trace is automatically shifted and scaled so as to correctly represent the stored trace for the new frequency span.

  • Page 39: Creating And Displaying Limit Lines

    20.9. Creating and Displaying Limit Lines Limit lines are created by defining a list of frequency & amplitude points (minimum 2). Straight lines are drawn between these points. Where a frequency is repeated with different amplitudes, the line becomes vertical representing a step change.

  • Page 40: Screen Resolution And Trace Thickness

    Displaying Limit Lines To turn a limit line on or off on the display, go to the Traces menu. The Limit Lines key in the traces menu cycles though four states: Off > L1 > L2 > L1+L2 > Off. If no limit lines have been defined, the key will have no effect.

  • Page 41: Functions Outside Of Psanalyzer

    For some sub-menus (Set by Keyboard, Store/Recall, Limit Line Editor), the help screen is accessed from the i symbol at the top right of the screen and not by using the Help hard key. Note: Help screens should be closed by pressing Done as soon as they have been read. When a Help screen is open, the PSAnalyzer application will turn off after the standard delay set within the Palm preferences (adjustable 30 secs to 3 mins).

  • Page 42: Psanalyzer Files And Defaults

    22.3.1. Using the Memory Card Reader TTi provides a USB linked memory card reader to allow PSAnalyzer user files to be transferred to and from a personal computer. The type of card reader supplied may vary from time to time. It may be a single card type (SD and MMC cards only) or a multi-card type.

  • Page 43: File Locations For Psanalyzer Data Files

    23.2. File Locations for PSAnalyzer data files The PSAnalyzer application is stored within the internal program memory of the handheld computer. The initialisation file that stores the “last used” settings when the application is terminated is also stored within the internal memory. However, files created by the user (stored traces, set-ups and screens) are stored on a plug-in memory card.

  • Page 44: Cleaning

    In dirty environments or when using a finger to press the screen, it may be advisable to use a Screen Protector to prevent grease or other contaminants from damaging the screen. A Screen Protector reduces the quality of the display somewhat, although this can be minimised by careful application. Some people generate a considerable level of grease from their finger tips, and may find that the screen quickly becomes smeared when regularly touched.

  • Page 45: Resetting The Palm T|X

    Reinstalling or updating the application may require the original memory card supplied with the PSA1301/2701T by TTi. Should this have been lost or erased, it will be necessary to create a duplicate from the support CD supplied by TTi with the product.

  • Page 46: Optional Accessories

    The memory card supplied with the PSA1301/2701T includes a backup copy of the application and an Installer program. Remove and re-insert the memory card supplied with the PSA1301/2701T by TTi. The Applications screen will appear showing the utility program PSAInstaller. Select this program and follow the on- screen instructions.
  • Page 47 Glebe Road • Huntingdon • Cambridgeshire • PE29 7DR • England (United Kingdom) Telephone: +44 (0)1480 412451 • Fax: +44 (0)1480 450409 tti-test.com tti.co.uk International web site: www. • UK web site: www. Email: info@tti-test.com Aim Instruments and Thurlby Thandar Instruments Book Part No. 48511-1060 Issue 7...
