TTI 1604 Service Manual page 17

PCB ASSY KEYBOARD (44812-0650)
Part No. Description
20661-0852 SPACER .56 INCH 7-SEG LED 6.5H
22226-0140 KEYSWITCH DARK GREY
22312-0242 FUSE CLIPS PCB MTG
22315-0242 FUSE 10A F HBC 20 x 5MM
22315-9401 FUSE 1A FAST BLOW HBC
23185-0000 RES ZERO OHM
23301-0438 RES NETWK SIL 82R X 4S
25061-0205 LED - INDICATOR 6.3MM X 3.7MM
25061-0519 DISPLAY 3 DIG .56 LED 9MM LEG
33562-9110 SPACER LED
35515-1510 PCB - KEYBOARD
CASE PARTS
Part No. Description
20030-0263 WASHER M3 ZPST
20030-0269 WASHER M3.5 ZPST
20037-0400 SOLDER TAG SHAKEPROOF - 6BA
20037-0401 SOLDER TAG SHAKEPROOF - 4BA
20038-9501 WASHER M3 SPRING
20038-9502 WASHER M4 SPRING
20065-0030 SCREW N0 4 X 3/8 PLASTT PNHDPZ
20205-0610 STUD M3 X 10
20210-0101 NUT M3 ZPST
20210-0102 NUT M4 ZPST
20224-0200 SCREW M3 X 8 CHHDSL NYLON
20234-0027 SCREW M3 X 6 PNHDPZ ZPST
20234-0038 SCREW M3 X 40 PNHDPZ ZPST
20236-0010 SCREW M4 X 12 TAMPERPROOF
20612-0011 WASHER FIBRE M3
20651-0008 CLAMP CABLE (P CLIP) 3.2MMD
20661-0221 SPACER Hex M3 x 20 NPBR
20661-0258 SPACER Rnd 7/32 IDx1/4 L l
20661-0273 SPACER Hex M3 x 12
22491-0120 MAINS LD 2M ST IEC/UK PLUG 5A
16
Position
FOR DISP1, 2
K1-13
FOR FS1, 2
FS2
FS1
LK1, 2
RP2
LED1-7, 9-17
DISP1, 2
FOR LED1-7, 9-17
Position
SCREEN LOWER & UPPER, P. CLIP
PCB/FRONT PANEL
EARTH
REAR PANEL EARTH
SCREEN LOWER & UPPER, PCB,
EARTH
REAR PANEL EARTH
PCB, P. CLIP
SCREEN LOWER
SCREEN LOWER, EARTH
REAR PANEL EARTH
PCB/FRONT PANEL
UPPER SCREEN
CASE LOWER/UPPER
REAR PANEL EARTH
PCB/CASE
PCB/SCREEN UPPER
PCB/CASE LOWER
PCB/FRONT PANEL
FOR UK
