Reference
Use
J23
I2C SCL
J24
I2C SDA
SWRU548C – FEBRUARY 2019 – REVISED SEPTEMBER 2021
Submit Document Feedback
2
Table 2-4. I
C Jumper Definitions
Comments
Populated: CC3235MOD SCL connected to onboard sensors with pullup
Open: CC3235MOD SCL disconnected from onboard sensors
Populated: CC3235MOD SDA connected to onboard sensors with pullup
Open: CC3235MOD SDA disconnected from onboard sensors
CC3235MODSF SimpleLink™ Wi-Fi
Copyright © 2021 Texas Instruments Incorporated
Hardware
®
and IoT Solution With MCU
25
LaunchPad™ Hardware
