Placing no jumpers on the block ensures that the line is pulled low using 100K pull down resistors.
Placing the jumper pulls the pin high using a 10K resistor.
2.2.12 Push-Buttons and LED Indicators
Table 2-7 lists the push-button definitions.
Reference Use
SW1 RESET
SW2 GPIO_13
SW3 GPIO_22
SW4 Factory default
Table 2-8 lists the LED indicators.
Reference Color
D1, D2 Green and Red
D3 Yellow
D4 Red
RGB
D7 RGB
RGB
D8 Red
(1) GPIO_10 and GPIO_11 are also used as I
GPIOs.

2.3 Electrical Characteristics

For electrical characteristics of the CC3235MODx modules, see
Dual-Band Wireless MCU Module data

2.4 Antenna Characteristics

The CC3235MODSM2MOB and the CC3235MODSF12MOB reference design detail the use of an on-board
antenna. For more information on the antenna VSWR, efficiency, and electrical characteristics, see M830520.
SWRU548C – FEBRUARY 2019 – REVISED SEPTEMBER 2021
Submit Document Feedback
Note
Table 2-7. Push-Button Definitions
This is used to reset the CC3235MOD device. This signal is also output on the 20-pin connector
to reset any external BoosterPack which may be stacked. The reset can be isolated using the RST
jumper at the isolation block.
When pushed, GPIO_13 is pulled to VCC.
When pushed, GPIO_22 is pulled to VCC.
Pressing this button and toggling RESET restores the factory default image on the serial flash.
This can be used to recover a corrupted serial flash, provided the s-flash was programmed with a
recovery image.
Table 2-8. LED Indicators
Use
Debug Indicates the state of the JTAG emulator. For TI use only.
Indicates the state of the NRESET pin. If this LED is on, the device is
nRESET
functional.
Power Indicates when the 3.3-V power is supplied to the board.
GPIO_09 Glows when the GPIO is logic-1.
(1)
GPIO_10 Glows when the GPIO is logic-1.
(1)
GPIO_11 Glows when the GPIO is logic-1.
Factory Reset Indicates that the push-button for the factory reset is pressed.
2
C. Whenever the pullups are enabled, the LEDs glow by default without configuring the
sheet.
