Introduction

1.2 LAUNCHCC3235MOD Key Features

The LAUNCHCC3235MOD SimpleLink LaunchPad includes the following features:
• CC3235MODSF, SimpleLink
– Integrated MCU
– 40.0-MHz crystal
– 32.768-kHz crystal (RTC)
– 32-Mbit SPI serial flash
– RF and full power-management components
• 40-pin LaunchPad kit standard that leverages the BoosterPack ecosystem
• TI standard, XDS110-based JTAG emulation with serial port for flash programming
• Supports 4-wire JTAG and 2-wire SWD
• Two buttons and one RGB LED for user interaction
• Back-channel universal asynchronous receiver/transmitter (UART) through USB to PC
• Onboard chip antenna with U.FL for conducted testing selectable using 0-Ω resistors
• Onboard accelerometer and temperature sensor for out-of-box demo with option to isolate the sensors from
the inter-integrated circuit (I
• Micro-USB connector for power and debug connections
• Headers for current measurement and external JTAG connection (option to use the onboard XDS110 to
debug customer platforms)
• Bus-powered device with no external power required for Wi-Fi
• Long-range transmission with highly optimized antenna (200 m typical in open air using an access point with
6-dBi antenna AP)
• Can be powered externally, with two AA or two AAA alkaline batteries working down to 2.3-V typical
• Dimensions: 106.1 mm (L) × 58.42 mm (W)

1.3 What's Included

1.3.1 Kit Contents
• CC3235MODSF LaunchPad development kit (LAUNCHCC3235MOD)
• Micro USB cable
• Quick start guide
1.3.2 Software Examples
• Out-of-box experience (OOBE) software

1.4 REACH Compliance

In compliance with the Article 33 provision of the EU REACH regulation we are notifying you that this EVM
includes component(s) containing at least one Substance of Very High Concern (SVHC) above 0.1%. These
uses from Texas Instruments do not exceed 1 ton per year. The SVHCs are:
Component
Component Type
Manufacturer
Abracon
Abracon

1.5 Regulatory Compliance

The SimpleLink CC3235MODx Wi-Fi LaunchPad kits are tested for and found to be in compliance with FCC and
ISED regulations regarding unlicensed intentional radiators. Hereby, Texas Instruments Inc. declares that the
radio equipment type LAUNCHCC3235MOD are in compliance with Directive 2014/53/EU. The full text of the EU
declaration of conformity is available at the following internet address:
• LAUNCHCC3235MOD Certification of Documents
• LAUNCHCC3235MOD Declaration of Conformity
8 CC3235MODSF SimpleLink™ Wi-Fi
LaunchPad™ Hardware
TM
Dual-Band Wi-Fi
2
C) bus
Component Part Number
Crystal ABM3-16.000MHZ-D2Y-T
Crystal ABM3-16.000MHZ-D2Y-T
®
and IoT Solution With MCU
Copyright © 2021 Texas Instruments Incorporated
®
module solution
SVHC Substance
Diboron Trioxide
Lead Oxide
SWRU548C – FEBRUARY 2019 – REVISED SEPTEMBER 2021
www.ti.com
SVHC CAS (When
Available)
1303-86-2
1317-36-8
