Summary of Contents for Middle Atlantic Products RK-GD Series
- Page 1 Instruction Sheet RK-GDXX Glass Door THANK YOU Thank you for purchasing the RK-GDXX Glass Door. Please read these instructions thoroughly before installing this product. PRODUCT FEATURES - Locking door provides security - Smoked, tempered glass provides a clean look I-00189 Rev D...
- Page 2 HARDWARE/ITEMS SUPPLIED DESCRIPTION Self-Adhesive Hinge Plate Hinge Pivot Bushing (.347” O.D.) Pivot Bushing (.313 O.D.) 5/8" Pan Head Wood Screw Stop Pin Door Locking Bracket (QTY -1) Magnet TOOLS REQUIRED # 2 Phillips Head Screwdriver or Power Driver with Bit BEFORE BEGINNING INSTALLATION 1) Move the rackrail to the recessed set of enclosure mounting holes using existing wood screws.
- Page 3 INSTALLATION 1) Determine desired hinge side and install HINGE pivot bushings in top and bottom of rack. PIVOT (FIGURE A) BUSHING (TOP) NOTE: Two bushing sizes are provided. Use appropriate size bushing for your rack. HINGE PIVOT 2) Remove adhesive backing and install both BUSHING hinge plates on inside of glass door.
- Page 4 Voice 613-836-2501 - Fax 613-836-2690 / middleatlantic.ca - customerservicecanada@middleatlantic.ca Factory Distribution USA: NJ - CA - IL Canada: ON - BC At Middle Atlantic Products we are always listening. Your comments are welcome. Middle Atlantic Products is an ISO 9001 and ISO 14001 Registered Company.
