- Page 1 Castle - Chest of Drawers 412/5819 429/9790 Width - 75cm Depth - 43cm Height - 67.5cm If you need help or have damage or missing parts, call the Customer Helpline: 03456 400 800 Issue 1 - 31/03/15...
- Page 3 1 Right side panel 2 Left side panel (67 x 41.6cm) (67 x 41.6cm) 3 Top panel (72 x 41.6cm) 4 Top front frame Unfinished bottom back frame (75 x 8cm) (72 x 8cm) Bottom front frame (75 x 8cm) 8 Drawer right side x 3 9 Drawer left side x 3 (40 x 12cm)
- Page 4 If you have damaged or missing components, 03456 400 800 call the Customer Helpline: 40mm Screw x 06 14mm Screw x 48 20mm Screw x 12 Nail x 04 Nail x 29 Wooden dowel x 40 Plastic L shaped Plastic cap x 10 bracket x 06 bracket x 12...
- Page 5 Insert dowels into the indicated parts.
- Page 6 Fixing runners. Attach right runners to the pre drilled holes on the right side panel using screws Attach left runners to the pre drilled holes on the left side panel using screws Step 3 Fitting Metal dowels. Screw metal dowels into right side panel left side panel drawer front...
- Page 7 Fixing L shaped brackets. Fix L shaped brackets in the indicated parts using screws as shown. Attention: Attention: Leave space from the edge of the bar and panels as shown. Assembling the cabinet. Fit top panel on to left side panel Insert 2 locking nuts into top panel where shown.
- Page 8 Step 6 Fixing right side panel. Fit right side panel on to cabinet. Insert 2 locking nuts into top panel where shown. Use a screwdriver to turn locking nuts clockwise to lock. Do not over tighten. After screwing locking nuts, insert plastic caps Fix unfinished bottom frame using screws...
- Page 9 Step 8 Fixing back panel. With help, carefully stand the product upright. Important: Cabinet MUST ‘square’ when back panels are attached. Attach back panel to the top side first using nails Position profile onto back panel (just attach). Carefully slot the second back panel into profile and fix it to the...
- Page 10 Step 10 Assembling the drawers: Fix drawer sides to the drawer back using screws Slide drawer bottom into slots on drawer sides. With help, fit drawer front to the drawer sides. Fix drawer sides to the drawer front using screws as shown.
- Page 11 Step 12 Correct position of the screws. Fixing runners. Attach right runners and left runners in the bottom edge of the drawers using screws as shown. Make sure runners are correctly positioned according to the diagram Step 13 Hook the wheels of the runner on the back of the drawers over the wheels of the runners on the left...
- Page 12 Step 14 Fixing to wall. Furniture must be fixed to a wall. Fix wall strap top of furniture using washer and screw wall With help, move furniture into position. If you need help or have damage or missing parts, call the Customer Helpline: 03456 400 800...
- Page 14 412/5819 429/9790...
