Custom Crimp CC15 Operator's Manual

Service hydraulic hose crimper
Hide thumbs Also See for CC15:
Table of Contents

Advertisement

Quick Links

Download this manual
CC15
Service Hose Crimper
The CC15 Series hose crimper with the Micrometer Style Adjustment and 33
tons of crimping force has the capability to crimp up to ½" 4SP.
UNIQUE USER FRIENDLY MICROMETER STYLE ADJUSTMENT
• Easy to use and read.
• Ideal for repetitive crimps.
• Fully adjustable micrometer for a precise crimp.
• Simple to calibrate and minimum maintenance.
• Micrometer style adjustment permits crimping a wide variety of hose and fittings.
3.7"
94mm
Max Head Opening
W/O Dies
Micrometer Style Adjustment:
Provides speed, precision
and repeatability.
CC15 HYDRAULIC CRIMPER OPERATORS MANUAL
Updated 02/2017

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CC15 and is the answer not in the manual?

Questions and answers

Related Manuals for Custom Crimp CC15

Summary of Contents for Custom Crimp CC15

  • Page 1 CC15 Service Hose Crimper The CC15 Series hose crimper with the Micrometer Style Adjustment and 33 tons of crimping force has the capability to crimp up to ½" 4SP. UNIQUE USER FRIENDLY MICROMETER STYLE ADJUSTMENT • Easy to use and read.

  • Page 2: Safety Precautions

    SAFETY PRECAUTIONS • READ INSTRUCTIONS AND IDENTIFY ALL COMPONENT PARTS BEFORE USING CRIMPER. • CRIMPER CC15 CAN PRODUCE 33 TONS OF CRIMPING FORCE. • KEEP BOTH HANDS AWAY FROM PINCH POINTS. • CONSULT HOSE AND FITTING MANUFACTURER FOR CORRECT MACHINE SETTINGS AND CRIMP MEASUREMENTS.

  • Page 3: Table Of Contents

    CC15 Service Hose Crimper TABLE OF CONTENT SAFETY PRECAUTIONS-----------------------------------------------------------------------------------------------------2 COMPONENT PARTS & TECHNICAL DATA--------------------------------------------------------------------------------------------------4 INITIAL SET UP & MAINTENANCE--------------------------------------------------------------------------------------------------------5 CRIMPING PROCEDURE---------------------------------------------------------------------------------------------6 CALIBRATION PROCEDURE---------------------------------------------------------------------------------------7 TROUBLESHOOTING-------------------------------------------------------------------------------------------------8 CC15 CRIMPER REPLACEMENT ACCESSORIES-------------------------------------------------------------------------9 COMPONENT PARTS BREAKDOWN--------------------------------------------------------------------------------------------10 CUSTOMCRIMP® “NO-NONSENSE” WARRANTY STATEMENT---------------------------------------------------------------11 CUSTOMCRIMP® CONTACT INFORMATION--------------------------------------------------------------------------------------12...

  • Page 4: Component Parts & Technical Data

    CC15 Service Hose Crimper COMPONENT PARTS & TECHNICAL DATA The 1 HP motor delivers the Technical Data power needed to get the job Electrical 33 Ton done quickly Metric Micrometer Enclosure ⅝” - 1 - 2 Wire Style Adjustment ½” - 4SP...

  • Page 5: Initial Set Up & Maintenance

    Check the tank sight glass for proper reservoir oil level. If additional oil is required fill with ISO Grade 46 hydraulic oil. Crimper Head Lubrication Lubrication passages are drilled in the CC15 die holders. This feature makes positive lubrication of the wear surfaces much easier assuring longer life and smoother crimper operation.

  • Page 6: Crimping Procedure

    CC15 Service Hose Crimper CRIMPING PROCEDURE • Select the correct die set for the combination of hose and fitting being crimped. Consult the hose and fitting manufacturer’s specifications for the correct die to use and final crimp diameter required. •...

  • Page 7: Calibration Procedure

    While the CC15 Crimper is calibrated at the factory prior to shipment, a calibration check is recommended prior to using the crimper. Select a typical hose and fitting and set the CC15 micrometer to the hose and fitting manufacturer’s recommendation. Insert the hose and fitting and press and hold the Start/Stop switch until the crimper shuts off. Measure the finished crimp.

  • Page 8: Troubleshooting

    CC15 Service Hose Crimper TROUBLESHOOTING PROBLEM: CRIMPER WILL NOT RUN AT ALL • The white rocker switch is also a circuit breaker. Check to see that the circuit breaker has not been tripped. • Check the wall outlet. Use of extension cords or outlets with inadequate power can damage the motor .

  • Page 9: Cc15 Crimper Replacement Accessories

    CC15 Service Hose Crimper CC15 REPLACEMENT ACCESSORIES Metric Dial Micrometer Pneumatic Pendent Switch Manual Back Stop Mini Grease Gun P/N:103889 P/N:102941-600 P/N:101349 P/N:103907 CRIMPX Die Lubricant 3 oz mini CRIMPX Die Lubricant 14 oz Protective Master Die Foam Pad CustomCrimp Notched Digital ®...

  • Page 10: Component Parts Breakdown

    CC15 Service Hose Crimper COMPONENT PARTS BREAKDOWN...

  • Page 11: Customcrimp® "No-Nonsense" Warranty Statement

    CC15 Service Hose Crimper CUSTOMCRIMP® “NO-NONSENSE” WARRANTY STATEMENT CustomCrimp® “No-Nonsense” Warranty Statement All CustomCrimp® Products are warranted to be free of defects in workmanship and materials for one year from the date of installation. This warranty ends when the product becomes unusable for reasons other than defects in workmanship or material.
  • Page 12 Products and services to support industry wide hose assembly needs. CustomCrimp ® Custom Machining Services, Inc. 326 N. County Rd. 400 East Valparaiso, IN 46383 Ph: (219) 462-6128 Fax: (219) 464-2773 www.customcrimp.com See the complete line of Custom Crimp Crimpers and Accessories at: ® www.customcrimp.com (219) 462-6128...
