- Page 1 Doc No. KF∗-OM00002 PRODUCT NAME EHEDG Compliant Fittings MODEL/ Series/ Product Number KFG2H*-E series...
-
Page 2: Table Of Contents
Contents 1. Safety Instructions 2. Specific Product Precautions 3. Specifications 4. Troubleshooting 5. Construction - 2 -... -
Page 3: Safety Instructions
EHEDG Compliant Fittings Safety Instructions These safety instructions are intended to prevent hazardous situations and/or equipment damage. These instructions indicate the level of potential hazard with the labels of “Caution,” “Warning” or “Danger.” They are all important notes for safety and must be followed in addition to International Standards (ISO/IEC) , and other safety regulations. - Page 4 EHEDG Compliant Fittings Safety Instructions Caution 1. The product is provided for use in manufacturing industries. The product herein described is basically provided for peaceful use in manufacturing industries. If considering using the product in other industries, consult SMC beforehand and exchange specifications or a contract if necessary.
-
Page 5: Specific Product Precautions
2. Specific Product Precautions (1) (4) When it is used with water, the fittings or Design/Selection tubing may be damaged depending on the surge pressure. Warning (5) Surge pressure must be under the maximum operating pressure. If the surge pressure (1) Check the specifications. - Page 6 2. Specific Product Precautions (2) Mounting/ Piping (2) Insert the tube into the union nut with the union nut removed. Grab the tube and gently (3) When connecting the tubing, take pressure or push it throughly into the fitting. possible changes to the tubing length into account, and allow a sufficient margin.
- Page 7 2. Specific Product Precautions (3) Piping Method (3) Drain flushing If condensate in the drain bowl is not emptied on a (5) Fix the body with a tightening tool. Tighten the regular basis, the bowl will overflow and this may union nut to the end surface of the body using cause the malfunction of pneumatic equipment.
- Page 8 2. Specific Product Precautions (4) Operating Environment (4) After operation at a high temperature, leakage may occur due to time dependent change of (6)Take note that if nylon tubing, soft nylon tubing the tube material. If leakage occurs, remove and antistatic tubing are used in a clean room. the tube, cut off the connecting part of the tube, The antioxidant on the surface of the soft nylon and connect to the piping again.
-
Page 9: Specifications
3. Specifications Note1) Note3) Fluid Air, Water ,Steam ） Note2) Note 4 Operating pressure range -100 kPa to 1 MPa Note 4) Ambient and fluid temperature C (No freezing) -5 to 150 Note 1) DI water is not recommended.DI water affects the materials used in the fitting,which may lead to a deterioration of water quality. - Page 10 Revision history 4-14-1, Sotokanda, Chiyoda-ku, Tokyo 101-0021 JAPAN Tel: + 81 3 5207 8249 Fax: +81 3 5298 5362 https://www.smcworld.com Note: Specifications are subject to change without prior notice and any obligation on the part of the manufacturer. © 2019 SMC Corporation All Rights Reserved - 10 -...
