BRONKHORST ES-FLOW 1 C Series Instruction Manual page 26

Alarm Mode
Type
Unsigned char
Available modes:
Value Description
0 Alarm off
1 Alarm on absolute limits
2 Alarm on limits related to setpoint (response alarm)
3 Alarm at power-up(e.g. after power-down)
(On DeviceNet™ instruments, only modes 0 and 1 are available)
Alarm Info
Type
Unsigned char
This parameter provides information about the event type(s) that triggered an alarm situation. The value is a bitwise
summation of the issued alarm types; convert the value to binary to see which types are issued. The following alarm types
can be issued:
Bit Value Type
0 1 Error
1 2 Warning
2 4 Minimum alarm
3 8 Maximum alarm
4 16 Batch counter alarm
5 32
·
·
6 64 Master/slave alarm
7 128 Hardware alarm
Alarm Delay Time
Type
Unsigned char
This value represents the time in seconds the alarm action will be delayed when an alarm limit has been exceeded. This
value also delays the alarm off action if an alarm limit is no longer exceeded.
Default value = 0.
Alarm Maximum Limit
Type
Unsigned int
Maximum limit for Measure to activate the maximum alarm situation (after Alarm Delay Time). Range 0...32000 represents 0...
100% signal. Alarm Maximum Limit must be greater than Alarm Minimum Limit.
Default value: 0.
Alarm Minimum Limit
Type
Unsigned int
Minimum limit for Measure to activate the minimum alarm situation (after Alarm Delay Time). Range 0...32000 represents 0...
100% signal. Alarm Minimum Limit must be smaller than Alarm Maximum Limit.
Default value: 0.
26
Access Range
RW 0...3
Access Range
R 0...255
This bit only: Power-up alarm
If combined with bit 2 or 3:
Response alarm
Access Range
RW 0...255
Access Range
RW 0...32000
Access Range
RW 0...32000
Instruction Manual ES-FLOW™ 1xxC
Bronkhorst®
FlowDDE FLOW-BUS
118 97/3
FlowDDE FLOW-BUS
28 1/20
Description
Error flag raised
Warning flag raised
Measure < Alarm minimum limit
Measure > Alarm maximum limit
Batch counter reached its limit
Alarm possibly caused by a power dip
Difference between Measure and Setpoint too big
Setpoint out of limits (caused by Slave factor)
Hardware error
FlowDDE FLOW-BUS
182 97/7
FlowDDE FLOW-BUS
116 97/1
FlowDDE FLOW-BUS
117 97/2
Modbus
0x0C23/3108
Modbus
0x0034/53
Modbus
0x0C27/3112
Modbus
0x0C21/3106
Modbus
0x0C22/3107
