- Page 1 blueLOGiC® hands-free kit BT-AU02 for Audi MMI high 2G navigation systems Bluetooth®-hands-free phone kit fully integrated in the vehicle infotainment Version 08.12.2015...
- Page 2 Contents 1. Prior to installation 1.1. Delivery contents 1.2. Checking the compatibility of vehicle and accessories 2. Installation 2.1. Place of installation 2.2. Connections 2.3. Activation of the interface 3. Interface operation 3.1. Pairing the blueLOGiC® interface with a mobile phone 3.2. Loading of phone book 3.3. Setup, factory defaults, update 3.4. A2DP audio streaming through CD-changer emulation 4. Specifications 5. Technical support Information Changes of the vehicle software can cause malfunctions of the interface. We offer free software-updates for interfaces for one year after purchase. To receive a free update, the interface must be sent in at own cost. Labor cost for and other expenses involved with the software-updates will not be refunded. Product features • Integration in and controls through the telephone port of the factory infotainment • Updatable Parrot chipset with best audio quality and high phone compatibility • Automatic radio mute •...
- Page 3 1. Prior to installation Read the manual prior to installation. Technical knowledge is necessary for installation. The place of installation must be free of moisture and away from heat sources. 1.1. Delivery contents HW ________ SW ________ Take down the SW-version and HW-version of the interface and store this manual for support purposes. 1.2. Checking the compatibility of vehicle and accessories Requirements Vehicle Audi A4, A5, A6, A8, Q7 Navigation MMI high 2 Generation Limitations Factory telephone kit must be removed if installed Factory CD-changer if A2DP shall be used, ONE factory CD-changer can be installed Version 08.12.2015...
- Page 4 2. Installation Switch off ignition and disconnect the vehicle’s battery! The interface needs a permanent 12V source. If according to factory rules disconnecting the battery is to be avoided, it is usually sufficient to put the vehicle is sleep-mode. In case the sleep-mode does not show success, disconnect the battery with a resistor lead.
- Page 5 Install the microphone close to the driver. Connect the microphones 3.5 mm jack to the 3.5mm jack bush of the blueLOGiC® harness. 2.3. Activation of the Interface After first installation the vehicle must go into sleep-mode in order to recognize the newly attached hardware. After re-connecting the battery, lock the vehicle and wait for 5 -10 minutes. 3. Interface operation The interface enables the telephone bus of the factory navigation system. Therefore in principal, the operation is analogue as described in the manual of the navigation system. 3.1. Pairing the blueLOGiC® interface with a mobile phone Up to 5 mobile phones can simultaneously be paired with the blueLOGiC® interface. If a sixth phone is paired, the oldest entry is automatically deleted. In some cases, it becomes necessary to put the vehicle in sleep mode to enable correct function of the 6 phone. For pairing, enable the pairing mode of the mobile phone (see manual of the mobile phone). Search with the mobile phone for „blueLOGiC“ and connect with activation code „1234“. If a mobile phone had been paired to the blueLOGiC® interface (requirement is an occurred pairing with a mobile phone, see above), a connection will be automatically established as soon as the mobile phone is in reach. If multiple paired mobile phones are simultaneously in reach, the blueLOGiC® interface will be connected to the first phone. Version 08.12.2015...
- Page 6 3.2. Loading of phone book After each establishment of connection to the mobile phone, the phone book of the mobile phone will be loaded to the vehicle infotainment. Depending on the mobile phone either it will be loaded from the phone’s memory or the SIM card. This process can take a few minutes. If the phone book is no or not completely loaded, it might be necessary to copy the contacts from the SIM-card to the mobile phone memory! Some mobile phones do not automatically load the phone book to the infotainment, but the sending must be manually initiated (the procedure varies depending on the mobile phone, z.B. “send phone book to Bluetooth”). The manual procedure must be repeated for refreshment if the mobile phone’s contacts have been edited. The memory of blueLOGiC® interface can save about 1000 call numbers. 3.3. Setup, factory defaults, update Settings of the blueLOGiC® interface can be changed by dialing certain codes in the vehicle telephone mode. Caller audio volume, Ringing tone volume and microphone sensitivity can be adjusted separately. The interface can be reset to factory defaults and updates of the Parrot chipset can be initiated. To execute a function, just dial the corresponding code from the below table like a phone number and confirm with “pick-up”. Function Code no. Min Max Microphone sensitivity +001xx 01 Caller audio volume +0021xx 01 Ringing tone volume +0022xx 01 Factory defaults +009 Parrot Update Mode +000 To the codes for volume and sensitivity it is necessary to add two digits for the desired value (01 min. to 15 max.). For example dial “+002112” to set the caller audio volume to level 12. After dialing a code, the navigation will confirm with “call failed”.
- Page 7 If the vehicle CD-changer mode of the vehicle’s navigation/radio system is activated, the A2DP playback is automatically started (while a virtual CD 1 with 4 tracks is shown). When the CD-changer mode is exited, the A2DP playback is stopped. The playback is paused during phone call activity. The 4 tracks on the virtual CD are “play”, “stop”, “next” and “prev”. Just confirm a track to execute the corresponding function. Track skipping is also possible with the “next” and “back” keys of the steering wheel or the MMI controls. The volume level of the A2DP can be adjusted in the mobile phones settings. 4. Specifications Integrated Bluetooth® Chip Parrot CK5050 Operation voltage 10.5 – 14.8V DC Stand-by power drain <1mA Operation power drain 120mA Power consumption 1.8W Temperature range -30°C to +80°C Weight 95g Dimensions (box only) B x H x T 106 x 30 x 71 mm 5. Technical Support Caraudio-Systems Vertriebs GmbH manufacturer/distribution In den Fuchslöchern 3 D-67240 Bobenheim-Roxheim email support@caraudio-systems.de Legal disclaimer: Mentioned company and trademarks, as well as product names/codes are registered trademarks ® of their corresponding legal owners. Version 08.12.2015...
