2.3.2 Mounting the Device to a Panel
To mount the device to a panel, do the following:
1.
2.
3.
4.
5.
2.4

Connecting Power

The RUGGEDCOM RMC40 supports a single integrated high AC/DC or low DC power
supply
RUGGEDCOM RMC40
Installation Manual, 04/2021, C79000-G8976-1009-09
Disassemble the device and panel adapter.
a. Remove the screw at the bottom of the adapter.
b. Pull the device out of the adapter.
1
RUGGEDCOM RMC40
1
Panel Adapter
2
Mounting Holes
3
Screw
4
Metal Clips
5
Figure 2.3 Panel Mounting
Place the panel adapter against the panel and align the adapater with the
mounting holes.
Secure the panel adapter using three #6-32 screws.
Insert the device into the adapter. Make sure the device is secured between the
two metal clips.
Install the screw previously removed from the bottom of the panel adapter.
2.3.2 Mounting the Device to a Panel
5 4 2
4
Installing the Device
3
9
