1.2 Description
•
Simple Plug and Play Operation
•
•
•
•
High Performance Ethernet Switching
•
•
•
1.2

Description

The RUGGEDCOM RMC40 features various ports, controls and indicator LEDs on
the display panel for connecting, configuring and troubleshooting the device. The
display panel can be located on the rear, front or top of the device, depending on the
mounting configuration.
1
2
3
4
5
2
21 AWG galvanized steel enclosure suitable for DIN or panel mounting provide
secure mechanical reliability
Automatic learning of up to 2048 MAC addresses
Auto-negotiation on 10/100Base-TX ports simplifies setup
Auto-MDI/MDIX on all 10/100Base-TX ports eliminates need for crossover cables
LED indicators for link, activity, and speeds LED aids in field trouble-shooting
Full compliance with IEEE 802.3 and IEEE 802.3u Ethernet standards for
universal interoperability
Non-blocking, store and forward switching with only 10 us latency means high
network throughput
Full duplex operation results in no collisions and deterministic network response
and flow control via IEEE 802.3x pause frames results in no collisions or dropped
packet
1
2
POWER LED
Copper Ethernet Port with LEDs
Fiber Optic Ethernet Port (ST Port Shown)
LINK/ACT LED
Power Terminal Block
4
3
5
RUGGEDCOM RMC40
