6.4.1 Main menue
The main menue has the following entries:
Menue entry
Quick setup
Adjustment
Display
Measurement
Current output
Diagnosis
Simulation
Communication
System
6.4.2 "Quick Setup" menue
In Quick Setup, basic configuration options are combined to make it possible to quickly
configure key functions. All functions of the quick setup can also be found at another
position in the menue tree.
The following functions are available in the Quick Setup menue:
Menue entry
Sprache/Language
Unit Pressure
Unit Temperature
Lower Range Value
Upper Range Value
Damping
Device ID
BA_072 Rev 1J3 Pressure transmitter PASCAL Ci4
Description
Selection of the most important settings
Adjustment functions for pressure measurement and current
output
Functions for configuring the display
Configuration of the pressure measurement
Configuration of the current output
Diagnostic information such as trailing pointers, etc.
Simulation of pressure and current for function check of the
measurement chain
Information and settings regarding HART communication
Device data and function such as factory reset
Table 6: The main menue
Description
Select menue language (German or English)
Select unit for measured pressure (see 6.4.4.1)
Select unit for sensor temperature (see 6.4.4.2)
Setting of the pressure value that should correspond to 4 mA
(start of range) (see 6.4.5.1)
Setting of the pressure value that should correspond to 20 mA
(end of range) (see 6.4.5.1)
Setting the damping of the output signal (see 6.4.5.2)
Setting the device ID (see 6.4.10.1)
Table 7: "Quick Setup" menue
