Customizing the Startup Screen

You personalize the image that is displayed when the chartplotter is turning on. For the best fit, the image
should be 50 MB or less and conform to the recommended dimensions
Dimensions, page 8).
1 Insert a memory card that contains the image you want to use.
2 Select Settings > System > Sounds and Display > Startup Image > Select Image.
3 Select the memory card slot.
4 Select the image.
5 Select Set as Startup Image.
The new image is shown then turning on the chartplotter.

Recommended Startup Image Dimensions

For the best fit for the startup images, use an image that has the following dimensions, in pixels.
Display resolution
WVGA
WSVGA
WXGA
HD
WUXGA

Adding a SmartMode Layout

You can add SmartMode layouts to suit your needs. Each customization made to one SmartMode layout for the
home screen in a station appears on all displays in the station.
1 From the home screen, select SmartMode™ > MENU > Add Layout.
2 Select an option:
• To change the name, select Name & Symbol > Name, enter a new name, and select Done.
• To change the SmartMode symbol, select Name & Symbol > Symbol, and select a new symbol.
• To change the number of functions shown and the layout of the screen, select Layout, and select an
option.
• To change the function of a portion of the screen, select the window to change, and select a function
from the list on the right.
• To change how the screens are split, use the arrow keys to select a new location.
• To change the data shown on the page and additional data bars, select Overlays, and select an option.
• To assign a preset to a portion of the SmartMode screen, select Presets > Include, and select a preset
from the list on the right.
8
Image width
680
880
1080
1240
1700
(Recommended Startup Image
Image height
200
270
350
450
650
