Loading the New Software on a Memory Card Using Garmin Express

You can copy the software update to a memory card using a computer with the Garmin Express app.
This device supports up to a 32 GB SD memory card, formatted to FAT32 with speed class 4 or higher. Use of
an 8 GB or higher memory card with speed class 10 is recommended.
Downloading the software update may take from a few minutes up to a few hours.
You should use a blank memory card for software updates. The update process erases the content on the card
and reformats the card.
1 Insert a memory card into the card slot on the computer.
2 Install the Garmin Express app
3 Select your vessel and device.
4 Select Software Updates > Continue.
5 Read and agree to the terms.
6 Select the drive for the memory card.
7 Review the reformat warning, and select Continue.
8 Wait while the software update is copied to the memory card.
NOTE: Copying the update file onto the card may take from a few minutes up to a few hours.
9 Close the Garmin Express app.
10 Eject the memory card from the computer.
After loading the update onto the memory card, install the software on the chartplotter
Software Using a Memory Card, page

Updating the Device Software Using a Memory Card

To update the software using a memory card, you must obtain a software-update memory card or load the
latest software onto a memory card using the Garmin Express app
Card Using Garmin Express, page
1 Turn on the chartplotter.
2 After the home screen appears, insert the memory card into the card slot.
NOTE: In order for the software update instructions to appear, the device must be fully booted before the
card is inserted.
3 Select Update Software > Yes.
4 Wait several minutes while the software update process completes.
5 When prompted, leave the memory card in place, and restart the chartplotter.
6 Remove the memory card.
NOTE: If the memory card is removed before the device restarts fully, the software update is not complete.

Pairing the GRID Device with the Chartplotter from the Chartplotter

NOTE: These steps are applicable to both the GRID device and the GRID 20 device.
Before you can pair the GRID 20 device with the chartplotter to make the data connection, you must supply
power using batteries, the included power cable, or a NMEA 2000 network connection.
Before you can pair the GRID device with the chartplotter, you must connect it to the Garmin Marine Network.
1 Select Settings > System > Station Information > GRID™ Pairing > Add.
2 Select an action:
• On the GRID remote input device, press SELECT.
• On the GRID 20 remote input device, press
160
(Installing the Garmin Express App on a Computer, page
160).
160).
and
(Loading the New Software on a Memory
until the remote control beeps three times.
158).
(Updating the Device
Appendix
