Configuring the Video Appearance

NOTE: Not all options are available on all camera models and chartplotter models.
1 From the video screen, select MENU > Video Setup.
2 Select an option:
• To show the video using a stretched aspect ratio, select Aspect > Stretch. The video cannot be stretched
beyond the dimensions provided by the connected video device, and it may not fill the entire screen.
• To show the video using a standard aspect ratio, select Aspect > Standard.
• To adjust the brightness, select Brightness, and select Up, Down, or Auto.
• To adjust the color saturation, select Saturation, and select Up, Down, or Auto.
• To adjust the contrast, select Contrast, and select Up, Down, or Auto.
• To allow the chartplotter to automatically select the source format, select Standard > Auto.
Garmin VIRB Action Cameras
®
Do not view video or photos while operating the vessel. Failure to pay attention to the conditions on the water
can result in vessel damage, personal injury, or death.
Most VIRB action cameras connect to the chartplotter from the camera menu
Camera, page 138).
The VIRB 360 camera connects using WPS
In this manual, the term "VIRB action camera" refers to all models, except in the instructions on how to connect.
In that case, as listed above, the term "VIRB 360 camera" refers to only the 360 model.

Connecting a VIRB 360 Action Camera

You can connect a VIRB 360 action camera to the chartplotter using WPS. If you are connecting a VIRB camera,
connect through the camera settings
1 Set up the chartplotter's Wi‑Fi network
2 Bring the camera near the chartplotter.
3 On the VIRB 360 camera main menu, select Wireless > Wi-Fi.
4 If necessary, select the Wi-Fi toggle switch to enable the Wi‑Fi technology.
5 Press to select WPS, and press OK.
6 On the chartplotter, select A/V, Gauges, Controls > VIRB® >
The camera searches for the Wi‑Fi network and connects.
You can control the camera using the chartplotter.

Connecting a VIRB Action Camera

You connect a VIRB action camera to the chartplotter using the camera settings. If you are connecting a VIRB
360 camera, connect through the VIRB app
1 Set up the chartplotter's Wi‑Fi network
2 From the VIRB camera main menu, select Wireless > Wi-Fi > Status to turn on Wi‑Fi wireless technology.
3 Select Mode > Connect.
4 Select Add New.
The camera searches for nearby Wi‑Fi networks.
5 Select the chartplotter's Wi‑Fi network, and enter the network password.
The app and the camera connect to the chartplotter's Wi‑Fi network.
You can control the camera using the chartplotter.
138
WARNING
(Connecting a VIRB 360 Action Camera, page
(Connecting a VIRB Action Camera, page
(Setting Up the Wi‑Fi Wireless Network, page
(Connecting a VIRB 360 Action Camera, page
(Setting Up the Wi‑Fi Wireless Network, page
(Connecting a VIRB Action
138).
138).
16).
.
138).
16).
