Connector View

The connectors and locations vary based upon the model. Pictured is a GPSMAP 1212xsv model.
12-PIN XDCR*
POWER
CVBS IN
ETHERNET
NMEA 2000
*Not available on all models
Introduction
12-pin transducer
Power
Ground screw
Composite video in
Garmin Marine Network
NMEA 2000
®
network
3
