Adding and Editing a Digital Switching Page

You can add and customize digital switching pages to the chartplotter.
1 Select A/V, Gauges, Controls > Switching > MENU > Setup.
2 Select Add Page or Edit Page.
3 Set up the page as needed:
• To enter a name for the page, select Name.
• To set up the switches, select Edit Switches.
• To add an image of the boat, select Add BoatView Image.
NOTE: You can load an image of your vessel into the device to use for the image, or use a default image.
You can also adjust the view and placement of the image.
When connected to a compatible Optimus system, the chartplotter allows you to access and control the
system. You can enable the Optimus overlay to control the Optimus system
page 120).
When necessary, the Optimus system provides messages with information, instructions, and alerts about faults
and hazards.
A no swimming icon
modes, propeller control is automatic and could injure someone in the water.

Activating the Optimus Overlay Bar

1 From a chart, select MENU > Edit Overlays.
2 Select Top Bar or Bottom Bar.
3 Select Optimus Bar.

Optimus Overlay Bar Overview

To use the overlay bar, you must connect your Optimus system to your chartplotter and add the overlay bar to
the necessary screens (Activating the Optimus Overlay Bar, page
Control mode
Optimus control buttons
Rudder
Standby button
You must press a mode button on the overlay bar to engage or disengage the mode. When the mode is
engaged, the button is illuminated.
The overlay bar configuration and buttons vary, based on systems, modes, and equipment. Refer to your
Optimus documentation for more information.
120
Dometic Optimus
®
indicates that you should not swim when certain Optimus modes are active. In these
Features
®
(Activating the Optimus Overlay Bar,
120).
Dometic Optimus Features
® ®
