Operating Modes (Functional Sequences); Legend; Automatic Cut-Out - EWM Picomig 180 Synergic TKG Operating Instructions Manual

5.4.6

Operating modes (functional sequences)

5.4.6.1

Legend

Symbol Meaning
Press torch trigger
Release torch trigger
I Welding current
Gas pre-flows
Gas post-flows
Non-latched
Latched
t Time
t Upslope time
Up
t Downslope time
Down
I Ignition current
start
I End-crater current
end
5.4.6.2

Automatic cut-out

Once the fault periods have elapsed, the automatic cut-out stops the welding process when it has been
triggered by one of two states:
• During ignition
5 s after the start of the welding process, no welding current flows (ignition error).
• During welding
The arc is interrupted for more than 5 s (arc interruption).
