Pneumatic Arm Single Monitor Desk Mount with USB
Instruction Manual
SKU: STAND-V101BDU
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/stand-v101bdu
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303

Advertisement

loading
Need help?

Need help?

Do you have a question about the STAND-V101BDU and is the answer not in the manual?

Questions and answers

Summary of Contents for Vivo STAND-V101BDU

  • Page 1 Pneumatic Arm Single Monitor Desk Mount with USB Instruction Manual SKU: STAND-V101BDU Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/stand-v101bdu GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com...
  • Page 2: Package Contents

    WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual.
  • Page 3: Tools Needed

    TOOLS NEEDED DO NOT EXCEED WEIGHT CAPACITY. 17.6lbs Failure to do so may result in serious injury. (7.98kg) Phillips Screwdriver ASSEMBLY STEPS STEP 1 OPTION A: Clamp Installation Insert 6mm Allen wrench (L) into socket on top of base (A) and turn screw counter-clockwise to lower clamp.
  • Page 4 STEP 2 Screw pole (D) into base, and tighten the grub screw using the 3mm Allen wrench (K). STEP 3 Attach cable clip (H) to pole. STEP 4 Slide arm support (J) onto pole and tighten the knob to secure.
  • Page 5 STEP 5 Place lower arm (B) onto arm support, and secure by turning the screw on the support with 3mm Allen wrench (K). STEP 6 Place spring arm (C) onto lower arm, and secure by turning the screw on the lower arm with 3mm Allen wrench (K).
  • Page 6 STEP 8 Pull back the release lever on the support bracket, then place the monitor with VESA plate into the support. STEP 9 If needed, adjust spring arm to support the monitor using the 6mm Allen wrench. Turn the screw in back clockwise to increase support, and counter-clockwise to decrease.
  • Page 7 STEP 10 Slide cable cover on lower arm forward to remove. STEP 11 Install lower cable clip (I) to base. Organize cables, then reinstall cable cover to lower arm. Adjust as Desired...
  • Page 8 - 92% within < 3hr www.vivo-us.com AVG. RESOLUTION TIME : < 15 M (within office hrs) Chat live with an agent! 309-278-5303 AVG. RESOLUTION TIME : 5M 4S (within office hrs) FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
