Pneumatic Arm Single Monitor Desk Mount
Instruction Manual
SKU: STAND-V101G1/W
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/stand-v101g1
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303

Advertisement

loading
Need help?

Need help?

Do you have a question about the STAND-V101G1/W and is the answer not in the manual?

Questions and answers

Related Manuals for Vivo STAND-V101G1/W

Summary of Contents for Vivo STAND-V101G1/W

  • Page 1 Pneumatic Arm Single Monitor Desk Mount Instruction Manual SKU: STAND-V101G1/W Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/stand-v101g1 GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com...

  • Page 2: Package Contents

    WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual.

  • Page 3: Assembly Steps

    ASSEMBLY STEPS STEP 1 (Option A) Clamp Installation Attach Clamp Brace (I) to Base (A) using M6x12mm Screws (S-A) and 4mm Allen Wrench (T-B). Apply Soft Pad (G) to underside of Base (A). Loosen screws on the back of Clamp (J), leaving 6mm of thread exposed. Assemble Clamp (J) to Clamp Brace (I) in the correct position to fit the thickness of your desktop, and retighten screws using 4mm Allen Wrench (T-B).
  • Page 4 STEP 1 (Option B) Grommet Base Installation Attach Grommet Plate (F) to Base (A) using M6x12mm Screws (S-A) and tighten with 4mm Allen Wrench (T-B). Apply Soft Pad (G) to underside of Base (A). Position Base (A) over grommet hole in desktop, or drill a 3/8”...
  • Page 5 STEP 4 Connect VESA Plate (D) to Gas Spring Arm (C) using Spacer (S-B), M8x25mm Screw (S-C), and 6mm Allen Wrench (T-C). Ensure that hexagon side of Spacer (S-B) is facing upward towards VESA Plate (D). Remove Thumbscrew (D1) from back of VESA Plate (D). Separate Front VESA Plate (D2) from Back VESA Plate (D3).
  • Page 6 STEP 6 To mount the monitor, begin by lining up the tabs on Front VESA Plate (D2) with the slots on Back VESA Plate (D3). Insert tabs into slots and re-install Thumbscrew (D1) into Back VESA Plate (D3) to secure. STEP 7 If needed, adjust gas spring arm to support the monitor using the 6mm Allen Wench (T-C).
  • Page 7 STEP 9 For safety, please do not extend the monitor behind the desk. This may cause instability and tip the desk over. Adjust the tilt using the 6mm Allen Wrench (T-C). Allen Wrenches (T-A, T-B, T-C) can be stored in slots for future adjustments.
  • Page 8 : 1HR 8M (within office hrs) - 23% within < 15m - 38% within < 30m - 61% within < 1hr - 83% within < 2hr - 92% within < 3hr FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
