1004151439/308824347/23MM33685-TPB01
1004151326/308824427/23MM33685-TPG03
USE AND CARE GUIDE
CANTERIDGE ELECTRIC FIREPLACE MEDIA MANTEL
QUESTIONS, PROBLEMS, MISSING PARTS? BEFORE RETURNING TO THE STORE,
CALL HOME DECORATORS COLLECTION CUSTOMER SERVICE
8 A.M. - 7 P.M., EST, MONDAY - FRIDAY, 9 A.M. - 6 P.M., EST, SATURDAY
1-800-986-3460
HOMEDEPOT.COM/HOMEDECORATORS
THANK YOU
We appreciate the trust and confidence you have placed in Home Decorators through the purchase of this electric fireplace. We strive to
continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home
improvement needs. Thank you for choosing Home Decorators!

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1004151439 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Home Decorators Collection 1004151439

Summary of Contents for Home Decorators Collection 1004151439

  • Page 1 USE AND CARE GUIDE CANTERIDGE ELECTRIC FIREPLACE MEDIA MANTEL QUESTIONS, PROBLEMS, MISSING PARTS? BEFORE RETURNING TO THE STORE, CALL HOME DECORATORS COLLECTION CUSTOMER SERVICE 8 A.M. - 7 P.M., EST, MONDAY - FRIDAY, 9 A.M. - 6 P.M., EST, SATURDAY 1-800-986-3460 HOMEDEPOT.COM/HOMEDECORATORS...

  • Page 2: Table Of Contents

    Table of Contents Maximum Load Warning ........... 2 Package Contents .............. 7 Safety Information ............. 3 Assembly ..............8 Warranty ..............5 Operation ..............19 Pre-Assembly ............. 6 FCC/IC Information ............21 Hardware Included ........... 6 Care & Cleaning ............21 Product Specifications ............

  • Page 3: Safety Information

    Safety Information Please read and understand this entire manual before attempting to assemble, operate or install the product. If you have any question regarding the product, please call customer service at 1-800-986-3460, 8 a.m.-7 p.m., EST, Monday-Friday, WARNING: Under no circumstances should this fireplace be 9 a.m.
  • Page 4 Safety Information (continued) NOTE: Use care in assembling your new fireplace. Take your time and use the hardware provided and a quality Phillips head screwdriver. Never overtighten bolts. • Do not sit on any part of the mantel. NOTE: To avoid injury from unexpected starting or electrical shock, do not plug the power cord into a source of power during unpacking and assembly.

  • Page 5: Warranty

    Warranty Warranty 1 Year Limited Warranty: The manufacturer warrants that your new Electric Fireplace is free from manufacturing and material defects for a period of one year from date of purchase, subject to the following conditions and limitations. Install and operate this appliance in accordance with the installation and operating instructions furnished with the product at all times.

  • Page 6: Pre-Assembly

    Pre-Assembly HARDWARE INCLUDED Part Description Part Number Quantity Wood Dowel PH-DWLNTL001 Cam Lock Screw PH-KDBZNC001 Cam Lock Connector PH-KDCZNC001 Shelf Pin PH-SPNPCSPLB2 Screw 3.5 x 15 mm PH-SCRNKL008 Euro Hinge PH-HNG2H35AR95 Screw 3 x 12 mm PH-SCRBLK007 Screw 4 x 50 mm PH-SCRBLK006 Plastic Cover PH-KDPWHT001 / PH-KDPBLK001...

  • Page 7: Package Contents

    Pre-Assembly (continued) PACKAGE CONTENTS NOTE: All panels are labeled left and right as viewed from the front of unit. Part Description Quantity Bottom Shelf Left Partition Right Partition Left Surround Rail Right Surround Rail Top Surround Rail Top Panel Left Side Panel Right Side Panel Base Back Rail Base Left Side Rail...

  • Page 8: Assembly

    Assembly Preparing the decorative Preparing the center panels front panels Place the Left Partition (B) and Right Partition (C) on a Place the Left Surround Rail (D) and Right Surround Rail (E) on a flat surface. flat surface. Insert Cam Lock Screws (BB) into the pre-drilled holes Insert Wood Dowels (AA) into the pre-drilled holes along in the Left Surround Rail (D).
  • Page 9 Assembly (continued) Preparing the base Attaching the base to center panels Place the Bottom Shelf (A) on a flat surface. Align the Wood Dowels (AA) that were inserted into the Insert Cam Lock Screws (BB) into the pre-drilled holes Left Partition (B) and Right Partition (C) with the in the Bottom Shelf (A).
  • Page 10 Assembly (continued) Securing the base panel Preparing the side panels Insert Screws (HH) through the Bottom Shelf (A) and Insert Wood Dowels (AA) into the pre-drilled holes in the securely tighten using a Phillips screwdriver. Left Side Panel (H). Repeat for the Right Side Panel (I). Attaching the Euro Hinges Securing the side panels Flip over the Right and Left Side Panel (H,I) assem-...
  • Page 11 Assembly (continued) Preparing the base back rail Preparing the base side rails Locate the Base Back Rail (J). Locate the Base Left Side Rail (K) and Base Right Side Insert Wood Dowels (AA) into the pre-drilled holes on Rail (L). the edges of the Base Back Rail (J) as indicated.
  • Page 12 Assembly (continued) Preparing the base front rail Attaching the base front rail Locate the Base Front Rail (M). Align the Base Front Rail (M) with the previously Insert Cam Lock Screws (BB) into the pre-drilled holes assembled base rails (J,K,L). of the Base Front Rail (M) where indicated.
  • Page 13 Assembly (continued) Attaching the surround bracket Preparing the top assembly Insert Wood Dowels (AA) into the pre-drilled holes in the Find the Metal Plate (OO) on the back of the Top Surround Rail (F). top edge of the Base/Center assembly as shown. Rotate the Metal Plate (OO) to span the joint and secure with a Screw (GG) on the Left Surround Rail (D).
  • Page 14 Assembly (continued) Preparing the top panel Preparing the Upper Surround Rail Insert Cam Lock Screws (BB) into the Upper Surround Insert Cam Lock Screws (BB) into the Fixed Shelf (N) as indicated in the diagram. Tighten using a Phillips Rail (V, W) as indicated in the diagram. Tighten using a Screwdriver.
  • Page 15 Assembly (continued) Attaching the upper partition Preparing the top of the assembly Align the Upper Partition (P) with the previously Insert Wood Dowels (AA) into the pre-drilled installed wooden dowel and cam lock screws on the holes in the top edges of the main assembly Center Shelf (N).
  • Page 16 Assembly (continued) Cover screws Installing the back panels Push Plastic Covers (II) into the screw hole openings Attach the Upper Back Panel (Q) and Back Pan- of areas that have already been assembled. els (R) to the assembly by inserting the Screws (GG) through the pre-drilled holes in the Upper Back Panel (Q) and the Back Panels (R) and into the assembly.
  • Page 17 Assembly (continued) Attaching the doors Slide the installed Euro Hinge on the Left Door (S) into the left side of the main assembly on the Left Side Panel as shown. Secure the hinge with the pre- attached screw. Repeat for the Right Door (T) on the right side of the main assembly on the Right Side Panel.
  • Page 18 Assembly (continued) Installing the fireplace insert Lift the Fireplace Insert (V) carefully into the back of the unit and center in the fireplace insert opening. Do not drag the fireplace insert across the Bottom Shelf (A), as it may scratch your unit. Securing the fireplace insert Align the Metal Brackets (MM) behind the Fireplace Insert (V) and above the pre-drilled holes.
  • Page 19 Assembly (continued) Installing the tipping restraint hardware When the Tipping Restraint Hardware (NN) is properly installed, it can provide protection against unexpected tipping of the Unit due to small tremors, bumps or climbing. Wall Your Unit comes with two Tipping Restraint Hardware (NN).
  • Page 20 Operation Operation NOTE: The control panel can be accessed at the upper-right corner of the insert. Powering the fireplace Adjusting the flame Push the Power button to supply power to all There are 6 brightness levels that can be selected: functions of the fireplace and put the insert in a standby mode.

  • Page 21: Operation

    Operation (continued) Replacing the remote control battery Disposing of used batteries The battery may contain hazardous substances that When the remote control stops operating or its range could endanger the environment and human health. seems reduced, it is time to replace the battery with new ones.

  • Page 22: Fcc/Ic Information

    FCC/IC Information WARNING: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for Class B digital device, pursuant to part 15 of the FCC Rules.

  • Page 23: Troubleshooting

    Troubleshooting PROBLEM ROOT CAUSE CORRECTIVE ACTION Unplug the fireplace, remove the back panel of the fireplace and check that the The thermostat sensor is thermostat is plugged into the main circuit Display shows " " broken or disconnected. board. If this does not solve the problem contact customer service for a replacement thermostat sensor.
  • Page 24 Troubleshooting (continued) PROBLEM ROOT CAUSE CORRECTIVE ACTION Flame effect works but heater With the power on press and hold the POWER function does not and the emberbed button on the control panel for 10 seconds. The heater is disabled. flashes when the Heater button is Once re-enabled the emberbed lights will pressed.

  • Page 25: Replacement Parts

    Replacement Parts For replacement parts, call our customer service department at 1-800-986-3460, 8 a.m.-7 p.m., EST, Monday-Friday, 9 a.m. - 6 p.m., EST, Saturday. Part Description Qty. Remote Control Flame Circuit Board Blue LED Circuit Board Flame Generator Drive Motor Thermostat Sensor Blower/ Heater Assembly Control Panel Circuit Board...
  • Page 26 HOMEDEPOT.COM/HOMEDECORATORS Please contact 1-800-986-3460 for further assistance.
  • Page 27 HOMEDEPOT.COM/HOMEDECORATORS Please contact 1-800-986-3460 for further assistance.
  • Page 28 Questions, problems, missing parts? Before returning to the store call Home Decorators Customer Service 8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday 1-800-986-3460 HOMEDEPOT.COM/HOMEDECORATORS RETAIN THIS MANUAL FOR FUTURE USE.
