Item #1005202794
Model #1457FM-33-201
ASSEMBLY INSTRUCTIONS
ALANA 52 IN. INFRARED MEDIA
ELECTRIC FIREPLACE
Questions, problems, missing parts?
Before returning to the store, call Home Decorators Collection Customer Service
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
1-800-986-3460
HOMEDEPOT.COM/HOMEDECORATORS
THANK YOU
We appreciate the trust and confidence you have placed in Home Decorators Collection through the purchase of this fireplace console. We strive
to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home
improvement needs. Thank you for choosing Home Decorators Collection!
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Home Decorators Collection Alana 1457FM-33-201
Summary of Contents for Home Decorators Collection Alana 1457FM-33-201
- Page 1 THANK YOU We appreciate the trust and confidence you have placed in Home Decorators Collection through the purchase of this fireplace console. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home...
-
Page 2: Table Of Contents
Table of Contents Table of Contents ........2 Hardware Included . - Page 3 Safety Information (continued) CAUTION: □ If possible, ALWAYS unplug this appliance when not in use. □ DO NOT operate any heater with a damaged cord or plug or after the heater malfunctions. DO NOT operate any heater if it has been dropped or damaged in any manner.
-
Page 4: Warranty
Warranty The manufacturer warrants that your new electric fireplace is free from manufacturing and material defects for a period of one year from date of purchase, subject to the following conditions and limitations. Install and operate this electric fireplace in accordance with the installation and operating instructions furnished with the product at all times. -
Page 5: Pre-Installation
Pre-Installation PLANNING INSTALLATION Before beginning assembly of product, make sure all parts are present. Compare parts with package contents list and hardware contents list. If any part is missing or damaged, do not attempt to assemble the product. Estimated Assembly Time: 50 minutes. Tools Required for Assembly (not included): Phillips screwdriver. -
Page 6: Package Contents
Pre-Installation (continued) PACKAGE CONTENTS Part Description Quantity Outer Wall Center Panel Base Left Front Panel Right Front Panel Wood Door Panel Insert Remote Control Battery... -
Page 7: Installation
Installation Install front panel □ From behind the assembly, align the holes on left front panel (E) with the corresponding holes on outer wall (B), securing with two washers (BB) and two long bolts (AA). Repeat for right front panel (F). Install right outer wall □... - Page 8 Installation (continued) Install left outer wall □ Insert two wooden dowels (CC) into holes on the left outer side of base (D). Attach outer wall (B). NOTE: Do not secure the left assembly yet until the center panel (C) is attached at step 5. Install center panel □...
- Page 9 Installation (continued) Install center panel □ Carefully position the center panel (C) into place between L/R front panels. Secure each side with one washer (BB) and one long bolt (AA), and use three washers (BB) and three long bolts (AA) to secure the left side panel assembly. Install top □...
- Page 10 Installation (continued) Remove insert brackets □ From behind the assembly, remove the preassembled insert brackets from the opening area. Save brackets and screws for future use. Install insert NOTE: Before proceeding to the next step, with the help of another person, move the mantel close to the final desired location. DO NOT plug insert (H) into power outlet yet.
- Page 11 Installation (continued) Re-install insert brackets □ Re-attach insert brackets with previously removed screws to secure insert (H). Assembly is now complete. With the help of another person, move the assembly to the final desired location. Once in final position, you may plug the insert (H) into the power outlet. Adjust the levelers NOTE: Use the pre-assembled levelers on the base of the fireplace to level the unit.
-
Page 12: Change Door Panels (Optional)
Change Door Panels (optional) Change door panels NOTE: The pre-installed glass door panels can be switched out with the included wood door panel (G). □ Remove the silicone trim along the outer edges of the glass panel on the inside of the flip down door. Start at a corner and pull to remove the four pieces. -
Page 13: Operating Instructions
Operating Instructions Control Panel Remote Control AAA 1.5V AAA 1.5V To use the remote control, first insert two AAA batteries (included) into the remote control. Ensure the polarities of the batteries match the inside of the battery compartment. NOTE: The control panel is a touch screen. It will appear black. Touch the control panel once to “wake up” the controls. This will cause the controls to light up. - Page 14 Operating Instructions (continued) Increase/Decrease Button NOTE: This option is only available if using the remote control. □ Press the INCREASE/DECREASE button to adjust the heater’s thermostat setting. □ Press the INCREASE/DECREASE button again to scroll up through the pre-set temperature settings: The thermostat setting range is 65°F (18,3°C) to 90ºF (32,2°C), HI (High).
-
Page 15: Care And Maintenance
Care and Maintenance □ Make sure the unit is turned OFF and unplugged, and that the heating elements of heater are cool whenever you are cleaning the heater or fireplace. □ Clean the metal trim using a water-dampened soft, clean cloth. DO NOT use brass polish or household cleaners as these products will damage the metal trim. -
Page 16: Troubleshooting
Troubleshooting Problem Possible cause Solution The error E1 displays on The overheat sensor has been Unplug unit, wait 15-20 minutes, then the sensor will reset itself. Plug the the control panel. engaged. unit back in and turn on the heater. If the problem persists, call customer service. -
Page 17: Service Parts
Service Parts MODEL TYPE Part Description Part # Part Description Part # 1457FM-33-201-TOP KD Hardware Pack PH-1457FM-33-201 PF-1457FM-33-201- Flip-Down Door Hardware Set PU17-1267FM-II/JJ/LL Outer Wall OUTER WALL Flip-Down Door Handle 1457FM-33-HANDLE-WHT Center Panel Leveler T-1007 1457FM-33-201 INSERT Left Front Panel Insert Mounting Bracket (with SURROUND SET INSERT-SIDE-MB... - Page 18 Questions, problems, missing parts? Before returning to the store, call Home Decorators Collection Customer Service 8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday 1-800-986-3460 HOMEDEPOT.COM/HOMEDECORATORS Retain this manual for future use.
