1004151500/308824333/26MM30502-PO83
1004151442/308824343/26MM30502-PD23
USE AND CARE GUIDE
HIGHVIEW ELECTRIC FIREPLACE
QUESTIONS, PROBLEMS, MISSING PARTS? BEFORE RETURNING TO THE STORE,
CALL HOME DECORATORS COLLECTION CUSTOMER SERVICE
8 A.M. - 7 P.M., EST, MONDAY - FRIDAY, 9 A.M. - 6 P.M., EST, SATURDAY
1-800-986-3460
HOMEDEPOT.COM/HOMEDECORATORS
THANK YOU
We appreciate the trust and confidence you have placed in Home Decorators through the purchase of this electric fireplace. We strive to
continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home
improvement needs. Thank you for choosing Home Decorators!
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Home Decorators Collection 1004151500-PO83
Summary of Contents for Home Decorators Collection 1004151500-PO83
- Page 1 USE AND CARE GUIDE HIGHVIEW ELECTRIC FIREPLACE QUESTIONS, PROBLEMS, MISSING PARTS? BEFORE RETURNING TO THE STORE, CALL HOME DECORATORS COLLECTION CUSTOMER SERVICE 8 A.M. - 7 P.M., EST, MONDAY - FRIDAY, 9 A.M. - 6 P.M., EST, SATURDAY 1-800-986-3460 HOMEDEPOT.COM/HOMEDECORATORS THANK YOU We appreciate the trust and confidence you have placed in Home Decorators through the purchase of this electric fireplace.
-
Page 2: Table Of Contents
Table of Contents Maximum Load Warning ........... 2 Package Contents .............. 7 Safety Information ............. 3 Assembly ..............8 Warranty ..............5 Operation ..............19 Pre-Assembly ............. 6 FCC/IC Information ............21 Hardware Included ........... 6 Care & Cleaning ............21 Product Specifications ............ -
Page 3: Safety Information
Safety Information Safety Information Please read and understand this entire manual before WARNING: This appliance is hot when in use. To avoid attempting to assemble, operate or install the product. If you burns, do not touch hot surfaces with bare skin. If provided, have any question regarding the product, please call customer use handles when moving this appliance. - Page 4 Safety Information (continued) NOTE: Use care in assembling your new fireplace. Take your time and use the hardware provided and a quality Phillips head screwdriver. Never overtighten bolts. • Do not sit on any part of the mantel. • It is recommended to work on a soft surface like a rug or to lay out a blanket to protect the furniture from getting scratched during the assembly process NOTE:...
-
Page 5: Warranty
Warranty 1 Year Limited Warranty: The manufacturer warrants that your new Electric Fireplace is free from manufacturing and material defects for a period of one year from date of purchase, subject to the following conditions and limitations. Install and operate this appliance in accordance with the installation and operating instructions furnished with the product at all times. -
Page 6: Pre-Assembly
Pre-Assembly HARDWARE INCLUDED Part Description Part Number Quantity Shelf Pin PH-SPNPCSPLB2 Cam Lock Screw PH-KDBZNC001 Cam Lock Connector PH-KDCZNC001 Screw 3 x 15 mm PH-SCRBLK010 Door Bumper PH-BMPBLK002 Wood Dowel PH-DWLNTL001 Euro Hinge PH-HNG2H35CR95 Screw 3.5 x 15 mm PH-SCRNKL008 Screw 4 x 50 mm PH-SCRBLK006 Bolt 6.3 x 12 mm... -
Page 7: Package Contents
Pre-Assembly (continued) PACKAGE CONTENTS NOTE: All panels are labeled left and right as viewed from the front of unit. Part Description Quantity Bottom Shelf Left Partition Right Partition Top Surround Rail Center Shelf Left Side Panel Top Panel Right Side Panel Base Back Rail Base Left Side Rail Base Right Side Rail... -
Page 8: Assembly
Assembly Attaching the door bumper Preparing the center assembly Locate the Left Partition (B). Locate the Top Surround Rail (D). Attach the Door Bumpers (EE) to the Left Partition as Insert Wood Dowels (FF) into each end of the indicated using the provided Screws (DD). Top Surround Rail (D) as indicated. - Page 9 Assembly (continued) Preparing the center shelf Preparing the center assembly Locate the Center Shelf (E) and place it on Align the cam lock screws and wood dowels on the a flat surface. Center Shelf (E) with the pre-drilled holes along the Insert Cam Lock Screws (BB) into the edges of the center assembly.
- Page 10 Assembly (continued) Attaching the surround bracket Attaching the door hinges Insert Wood Dowels (FF) into the edges of the Center Locate the Left Side Panel (F) and Right Side Panel (H). Shelf (E) as indicated. Locate the Euro Hinge (GG) and secure both the upper and lower hinge as indicated to the Left Side Panel (F) using the pre-attached screws.
- Page 11 Assembly (continued) Attaching the side panels Preparing for the bottom assembly Align the cam lock screws on the center assembly Insert Wood Dowels (FF) into the bottom edges of the with the pre-drilled holes on the Left Side Panel (F). center assembly as indicated.
- Page 12 Assembly (continued) Preparing the base panel Attaching the base panels Place the Base Rails (I, J, K, L) on a flat surface. Align the Base Left Side Rail (J) with the Base Back Rail Insert Bolts (JJ) through the 2 Hole Plastic Connector (I) and push together.
- Page 13 Assembly (continued) Preparing the center shelf Attaching the base panels for assembly To attach the previously assembled aprons to the Insert Wood Dowels (FF) into the center of the bottom of the main assembly, insert Bolts (JJ) Center Shelf (E) on the main assembly as indicated through the Plastic Connector Blocks as indicated.
- Page 14 Assembly (continued) Preparing the top of the assembly Preparing the top panel Insert Wood Dowels (FF) into the pre-drilled holes in Place the Top Panel (G) onto a flat surface. the top edges of the main assembly. Insert the Cam Lock Screws (BB) into the pre-drilled holes in the bottom of the Top Panel (G).
- Page 15 Assembly (continued) Covering the screws Installing the back panels Push Plastic Covers (LL) into the screw hole Attach the Upper Back Panel (N) and the Side Back openings of areas that have already Panels (O) by inserting the Screws (MM) through the been assembled.
- Page 16 Assembly (continued) Attaching the handles Attaching the doors Locate the Door Handles (NN) and use pre-attached Slide the previously installed Euro Hinge (GG) on the screws to secure onto the Doors (P). Left Door (P) into the left side of the main assembly as shown.
- Page 17 Assembly (continued) Installing the fireplace insert into the mantel assembly Lift the Fireplace Insert (S) carefully into the back of the unit and center in the fireplace insert opening. Do not drag the fireplace insert across the Base (A) as it may scratch your unit. Securing the fireplace insert Align the Metal Brackets (QQ) behind the fireplace insert and above the pre-drilled holes.
- Page 18 Assembly (continued) Installing the tipping restraint hardware When the Tipping Restraint Hardware (OO) is properly Wall installed, it can provide protection against unexpected tipping of the Unit due to small tremors, bumps or climbing. Your Unit comes with two Tipping Restraint Hardware (OO).
-
Page 19: Operation
Operation Operation NOTE: The control panel can be accessed at the upper-right corner of the insert. Fig . 1 Powering the fireplace Adjusting the flame Push the Power button to supply power to all There are 6 brightness levels that can be selected: functions of the fireplace and put the insert in a standby mode. - Page 20 Operation (continued) Replacing the remote control battery Disposing of used batteries The battery may contain hazardous substances that When the remote control stops operating or its range could endanger the environment and human health. seems reduced, it is time to replace the batteries with new ones.
-
Page 21: Fcc/Ic Information
FCC/IC Information WARNING: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for Class B digital device, pursuant to part 15 of the FCC Rules. -
Page 22: Troubleshooting
Troubleshooting PROBLEM ROOT CAUSE CORRECTIVE ACTION Unplug the fireplace, remove the back panel of the fireplace and check that the thermo- The thermostat sensor is stat is plugged into the main circuit board. Display shows " " broken or disconnected. If this does not solve the problem contact customer service for a replacement thermo- stat sensor. - Page 23 Troubleshooting (continued) PROBLEM ROOT CAUSE CORRECTIVE ACTION Flame effect works but heater func- With the power on press and hold the POWER tion does not and the emberbed flashes button on the control panel for 10 seconds. The heater is disabled. when the Heater button is pressed.
-
Page 24: Replacement Parts
Replacement Parts For replacement parts, call our customer service department at 1-800-986-3460, 8 a.m.-7 p.m., EST, Monday-Friday, 9 a.m. - 6 p.m., EST, Saturday. Part Description Qty. Remote Control Flame Circuit Board Blue LED Circuit Board Flame Generator Drive Motor Thermostat Sensor Blower/ Heater Assembly Control Panel Circuit Board... - Page 25 HOMEDEPOT.COM/HOMEDECORATORS Please contact 1-800-986-3460 for further assistance.
- Page 26 HOMEDEPOT.COM/HOMEDECORATORS Please contact 1-800-986-3460 for further assistance.
- Page 27 HOMEDEPOT.COM/HOMEDECORATORS Please contact 1-800-986-3460 for further assistance.
- Page 28 Questions, problems, missing parts? Before returning to the store call Home Decorators Customer Service 8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday 1-800-986-3460 HOMEDEPOT.COM/HOMEDECORATORS RETAIN THIS MANUAL FOR FUTURE USE.
